73015
Advanced One-Zone Electronic Water Timer
User Instructions
n
English
73015_INS_ENG_00
OK
O
N
/
O
F
F
M
A
N
U
A
L
C
Y
C
L
E
A
B
C
D
CYCLE
HRS
DAY
MIN
RESET
MANUAL
AM
PM
TODAY
TIME
WATER EVERY
SU
FR
SATH
WE
TUMO
A
B
C D
DAY
NEXTSTART
DELAY
CODE
:
WATER DAYSTART WATER
OFF
HOW LONG AUTO
SET CLOCK
RAIN DELAY, HOLD
Manual Watering Button
Cycle Button
Battery Indicator
Toggle Button
+/- Buttons
OK Button
OK
O
N
/
O
F
F
M
A
N
U
A
L
C
Y
C
L
E
A
B
C
D
CYCLE
HRS
DAY
MIN
RESET
MANUAL
AM
PM
TODAY
TIME
WATER EVERY
SU
FR
SATH
WE
TUMO
A
B
C D
DAY
NEXTSTART
DELAY
CODE
:
WATER DAYSTART WATER
OFF
HOW LONG AUTO
SET CLOCK
RAIN DELAY, HOLD
1
Battery Installation & Assembly
■n Remove the battery holder from the back of the Timer
Control Unit. Insert two AA alkaline batteries (Do not
use rechargeable batteries) as indicated on the battery
holder. Replace the battery holder, making sure that it is
firmly and securely placed in the Timer Control Unit.
■n NOTE: Do not use your timer when the air temperature
is below 40°F (4.5° C). When storing your timer, be sure
it is in a dry place and protected from frost.
Installation of the Timer
■n Attach the timer to an outside faucet and turn on the water. The water must be left on while the
timer is attached to the faucet for your timer to operate.
■n NOTE: You may choose to program your timer before or after attaching it to the faucet.
2
SET CLOCK: “Set Current Time and Day”
■n The Water Timer default setting is a 12-hour mode (AM/PM). To ensure correct timing,
look for either AM or PM to the left of the time. To switch between 12-hour (AM/PM) and
24-hour (military time), hold the button for 5 seconds. 12-hour mode shows AM or PM
while 24-hour mode does not. Note: Changing time mode will erase all programs.
■n Before setting your watering times, you must first set the current time and day of the week.
When the batteries are first installed, the arrow in the screen will point to CLOCK. If it is not in
that position, press the button until the arrow is pointing to CLOCK.
■n On your screen, a flashing box will appear around the SU. Simply set the timer to the current
day by pressing the and buttons on the touchpad
until the square is on the correct day. Once the correct
day has been indicated, press the button.
■n To set the time, press the and buttons until the
correct time appears on the screen, and then press .
■n Press the button (at the top of the touch pad) to
move to WATER DAY.
3
WATER DAY: “What days do you want to water?”
■n Check to be sure that the arrow on the screen is pointing to WATER DAY. With this setting, you
can select specific days to water or an interval period of the day when watering will occur.
■n To set the watering day, use the and buttons to select the day-of-the-week you wish to
water. Press the button when the desired day-of-the-week is highlighted on the screen. You
can select as many days as you like. The days selected will have a square around them.
■n To water at preset intervals, press the button on the buttonpad to navigate past the days of
the week. Press the and buttons to set the time period (EVERY 1 DAY through EVERY
7 DAY(s) ).
■n Press the button to move to START WATER.
4
START WATER: “What time-of-day do you want to water?”
■n You can select up to four independant start times (CYCLE A, B, C, D). With the arrow pointing
to Start Water on your screen, CYCLE A should be highlighted, use the and buttons to
select the first watering time.
■n If you want to set another START WATER time, press to move to CYCLE B. Repeat the
process above to set the next START WATER time. You may select up to four START WATER
times.
■n When you have set all desired START WATER times, press
the
button to move to HOW LONG.
5
HOW LONG: “Set the length of each watering cycle.”
■n With the arrow pointing to HOW LONG, use the and buttons to select the length of each
watering cycle. After setting HOW LONG you want to water during a selected cycle, press
to move to the next cycle. Repeat until HOW LONG has been set for each cycle.
■n HOW LONG can be set for up to 360 minutes (6 hours) for each watering cycle. The Cycle
length cannot overlap the next START WATER time.
■n Note: You can only select Watering Cycles if you have set a start time in Step 4 above.
■n When you have set all desired START WATER times, press the
button to
enter AUTO Mode.
6
AUTO MODE: “Your timer is ready to go.”
■n In AUTO Mode, your timer will run the watering program you have entered.
■n The screen display will alternate between showing the Current Time and the
Next Watering Cycle.
We recommend replacing batteries when the indicator reaches
CYCLE
HRS
DAY
MIN
RESET
MANUAL
AM
PM
TODAY
TIME
WATER EVERY
SU
FR
SATH
WE
TUMO
A
B
C D
DAY
NEXT START
DELAY
CODE
:
WATER DAYSTART WATER
OFF
HOW LONG AUTO
CLOCK
RAIN DELAY, HOLD
CYCLE
HRS
DAY
MIN
RESET
MANUAL
WATER
SU
FR
SATH
WE
TUMO
A
B
C D
DAY
NEXT START
DELAY
CODE
:
WATER DAYSTART WATER
OFF
HOW LONG AUTO
CLOCK
RAIN DELAY, HOLD
CYCLE
HRS
DAY
MIN
RESET
MANUAL
AM
PM
TODAY
TIME
WATER EVERY
SU
FR
SATH
WE
TUMO
A
B
C D
DAY
NEXT START
DELAY
CODE
:
WATER DAY START WATER
OFF
HOW LONG AUTO
SET CLOCK
RAIN DELAY, HOLD
WATER DAY START WATER
OFF
HOW LONG AUTO
SET CLOCK
RAIN DELAY, HOLD
CYCLE
HRS
DAY
MIN
RESET
MANUAL
AM
PM
TODAY
TIME
WATER EVERY
SU
FR
SATH
WE
TUMO
A
B
C D
DAY
NEXT START
DELAY
CODE
:
Hold the or buttons to advance settings more quickly.
