Filter Installation

This is the main product document for model YY200. Additionally, the document applies to other Asko models: LP200, LP300, LP450

The file format is pdf, 2 pages, you can download this manual here .

background
NEW 7/20 1 YY200_YY350QSG_ES
Filter Installation (Applies to LP200, LP300, and LP450)
2. Filters must be installed in the following order:
First - True HEPA Filter
Second - Activated Carbon Filter
True HEPA
Activated
Carbon
1. Press the EZclick
Filter button to release the
cover for the filter compartment.
EZclick
Filter Button
3. Replace the Filter Door by pressing the EZclick
Filter button to the top of the unit.
*Note: The unit will not operate unless the rear cover is properly installed.
TYPE OF AIR PURIFICATION:
INCLUDED
IN PACKAGE
LIFE
TRUE HEPA FILTER*
Removes 99% of particles 0.3 microns and larger
1 12 Months/2800 hours
Activated Carbon Odor Filter 3 4 Months/960 hours
Filter Replacement Reminders
When the LED above the power button blinks RED it is time to replace the Acti-
vated Carbon Filter, the True HEPA Filter, or both. To reset the Filter Replacement
Reminder press the Power and Timer button together for 3 seconds. The LED
should blink 3 times and turn off. The unit run timer has now been reset.
background
NEW 7/20 2 YY200_YY350QSG_ES
Recordatorios de reemplazo del filtro
cuando el LED sobre el botón de encendido parpadea en ROJO, es hora de re-
emplazar el filtro de carbón activado, el filtro HEPA verdadero o ambos. Para
restablecer el recordatorio de reemplazo del filtro, presione el botón de encendido
y el temporizador juntos durante 3 segundos. El LED debe parpadear 3 veces y
apagarse. El temporizador de funcionamiento de la unidad ahora se ha restablecido.
Instalación del Filtro (Se aplica a LP200, LP300 y LP450)
2. Los filtros deben instalarse en el siguiente orden:
Primero: Verdadero Filtro HEPA
Segundo: Filtro de Carbón Activado
Verdadero
HEPA
Carbón
Activado
1. Presione el Botón del Filtro EZclick
para
liberar la tapa del compartimento del filtro.
Botón de ltro EZclick
3. Vuelva a colocar la puerta del filtro colocando la mano en un pequeño hueco del panel
y empujando hacia la unidad.
*Nota: La unidad no funcionará sin la cubierta trasera instalada correctamente.
TIPO DE PURIFICACIÓN DEL AIRE:
INCLUIDO EN
EL PAQUETE
VIDA ÚTIL
VERDADERO FILTRO HEPA*
Elimina el 99% de las partículas de 0.3 micrones y
más grandes
1 12 meses/2800 horas
Filtro de carbón activado para olores 3 4 meses/960 horas
