EN
Original Instructions
Version 1 – March 2022
RECHARGEABLE
FOLDING
SITE LIGHT
These are the original product instructions. This document is part of the product; retain it for the life of the product, passing it on to subsequent holders. Read
this manual in full before attempting to assemble, operate, or maintain this product. Always use the latest version of the product manual. The latest version can
be downloaded from drapertools.com/manuals
1. Specication
Stock No. Part No. Bulb wattage (W) Lumens (lm) USB output Beam angle (°) Colour temperature (K)
03182 RC/FSL/10W 10
1,100
5V, 1.5A
100 6,000~6,500
03183 RC/FSL/20W 20
2,200
5V, 1.5A
100 6,000~6,500
03185 RC/FSL/30W 30
3,300
5V, 1.5A
100 6,000~6,500
EU 04347 RC/FSL/20WFOB 20
2,200
5V, 1.5A
100 6,000~6,500
This light is rated IP65. It is fully protected against dust and is protected
against low pressure jets of water from all directions (limited ingress
permitted). This does not include the attached plug.
2. Health and Safety Information
Important: Read all Health and Safety instructions before attempting to
operate, maintain or repair this product. Non-compliance with these
instructions may result in injury or damage to the user or the product.
Draper Tools accepts no responsibility for improper use of this device.
• Inspect the product and electrical connections for signs of damage or
battery leakage before every use.
WARNING! Do not use the product if defects are present and
withdraw it from service until it has been repaired. If the external
power cable is damaged, it must be replaced by suitably qualied
personnel or returned to Draper Tools for repair.
• ONLY the supplied adaptor should be used to charge this product; DO
NOT use the adaptor to charge other products or batteries.
• DO NOT use the charging adaptor if wet.
• Always ensure that the voltage rating on the charging adaptor is
appropriate for the power supply to be used.
• Remove all packaging and wrapping before use.
• Position the product appropriately.
− Use only on level surfaces.
− Ensure that the product is stable and unlikely to tip over.
− Where necessary, apply weights to the stand or secure it.
− Ensure that all joints are securely fastened when the product is in
use or stored.
− This is a Class III appliance and should only be used with the
charging adaptor supplied.
• WARNING! This product gets hot when in use.
− NEVER place objects on the lamp area or hang objects on any part
of this product.
− NEVER use the light near ammable or combustible substances or
equipment.
− ALWAYS disconnect the power supply and allow at least ten minutes
for the product to cool before attempting any maintenance or
adjustment.
• WARNING! Do not stare at the operating light source.
• ALWAYS ensure that the light is switched o during charging.
− Keep trailing cables and extension leads tidy and secured to avoid
trip hazards.
− This product is certied for use in ambient temperatures of 0 to
+40°C.
− Replace any cracked protective shield.
− This product includes a 4mm glass shield rated IK08.
3. Maintenance and Troubleshooting
Important: Maintenance and repair, including replacement of the light
source, must only be performed by qualied personnel with sucient
knowledge of the electrical circuits used in this device.
• Charge the product for at least six hours before rst use.
• Always disconnect the power supply and allow the lamp to cool before
cleaning.
• Clean the lamp using a dry cloth ONLY.
CAUTION! Do not immerse this product in water.
• Store the product in a clean and dry environment, out of reach of
children, with all joints rmly secured.
• Charge the light fully before storing and at least every three months
between uses to maintain the battery life.
If the light does not illuminate when switched on, check the charge level.
Ensure that charge is retained when disconnected from mains power.
Risk of electric shock
Class III product, use only with the
charging adaptor supplied
Replace any cracked
protective shield
4. What’s in The Box?
Carefully remove the product from the packaging and examine it for any
signs of damage that may have occurred during shipment.
A. Rechargeable folding site light B. Power adaptor
(A)
(B)
Stock No. 03182 shown
