SD225562LF/08-14
Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com
Contractor: Contact #:
Job Name: Location:
Submittal Information:
SPECIFICATIONS
Warranty
Danze products are covered by a manufacturer’s
limited "lifetime" warranty for manufacturing defects.
Description
MID-TOWN™ SINGLE HANDLE LAVATORY FAUCET
MID-TOWN™ SINGLE HANDLE LAVATORY FAUCET
Finishes Available
Model
D225562LF
Standards
Flow Rate
0.5
1.0
20 40 60 80
PSI
GPM
• Chrome
• Other: Refer to Price List for
additional finish
• ADA Accessibility Guidelines for
Buildings and Facilities -
4.27.4 Controls and Mechanisms
• NSF/ANSI 372
NSF/ANSI 372
• ASME A112.18.1M/A112.18.1
3 7/8"
(97mm)
1 3/4"
(45mm)
5"
(127mm)
1 5/8"
(43mm)
1/16"~2 1/2"
(1~65mm)
5 1/8"
(128mm)
25°
2 7/8"
(75mm)
7°
45°
45°
25 7/8"
(655mm)
8 1/2"
(216mm)
Ø 1 1/4"
(Ø 32mm)
1 1/2"~2 1/4"
(38~57mm)
Ø 2 1/8"
(Ø 54mm)
Ø 1 5/8"Max
(Ø 40mm)
1/2"Min
13mm(Min)
2 5/8"
(68mm)
3/8"Compression
1 1/4"-18UNEF
1/2"~24UNEF
M40x1.5
• Ceramic disc cartridge DA507906N
• Laminar flow 1.0 gpm maximum aerator @ 60 psi
• Metal lever handle
• Metal touch-down drain assembly DA505918
• Single hole mount, 3 7/8" high spout, 5" spout length
• 4" deckplate DA607568 sold separately for 3 hole installation
• Square base DA607569 sold separately for single hole installation
DA607569
D225562LF D225562LF
DA607568
