CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they are supervised or have been given instruction
concerning the use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING: You must not cover this heater. Covering this heater presents
fire risk and will activate the safety fuse; permanently disabling the unit.
WARNING: Do not use this heater in small rooms when they are occupied
by persons not capable of leaving the room on their own, unless constant
supervision is provided.
WARNING: To reduce the risk of fire, keep textiles, curtains, or any
flammable material a minimum distance of 1 metre from the air outlet.
General Care and Safety Guide
• Use only the voltage specified on the rating label of the appliance.
• The heater must not be located immediately below a socket outlet.
• Keep all objects at least 1 metre from the front, sides and rear of the appliance.
• This appliance is intended for household use only and not for commercial or industrial use.
• Indoor use only.
• Use this appliance only as described in this manual. Any other use is not recommended by
the manufacturer and may cause fire, electric shock or injury.
• Do not use the heater if it has been dropped or damaged.
• The common cause of overheating is deposits of dust or fluff in the appliance. Ensure these
deposits are removed regularly by unplugging the appliance and vacuum cleaning the air
vents and grills.
• Always unplug appliance when not in use.
• When the appliance has been unpacked, check it for transport damage and ensure all parts
have been delivered. If parts are missing or the appliance has been damaged, contact the
Customer Services Team.
• Do not use if there are visible signs of damage to the heater.
YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE
INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.
• Never use the appliance to dry clothes.
• Do not connect the appliance to mains supply until completely assembled and adjusted.
• Ensure hands are dry before handling the plug or main unit.
• Ensure heater is on a flat, stable, heat-resistant surface.
• Do not operate with cord set coiled up as a heat build up is likely, which could be sufficient to
become a hazard.
• Carry out regular checks of the supply cord to ensure no damage is evident
• Do not operate this appliance with a damaged cord, plug or after the appliance malfunctions
or has been dropped or damaged in any manner. Return to a qualified electrical person for
examination, electrical service or repair.
• Do not twist, kink or wrap the cord around the appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord has been removed from any cord storage area
and is unrolled before use.
• It is recommended that this heater is plugged directly into the wall socket. Power boards are
not rated to supply power to high wattage appliances.
• A correctly specified, undamaged extension cord may be used with this heater provided it is
used in a safe manner.
• Do not remove plug from power socket until the appliance has been switched off.
• Do not remove plug from power socket by pulling cord; always grip plug.
• Do not place cord under carpet or cover with rugs or furniture. Arrange the cord so it cannot
be tripped over.
• Don’t place appliance on bedding or on thick & long carpet where the openings may get
blocked.
• Switch off and use handle provided when moving
• Do not place appliance close to radiant heat source.
• Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may
cause an electric shock, fire or damage to the appliance.
• Do not sit on the appliance.
• Do not use abrasive cleaning products on this appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always remove plug from the mains supply before cleaning.
• Do not operate in areas where petrol, paint or other flammable liquids are used or stored.
• Do not use this appliance in the immediate surrounds of a bath, a shower, or a swimming
pool or other liquids.
• The appliance must not be immersed in any liquids.
• There are no user serviceable parts installed in the unit.
• Do not place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.
• This unit is not supposed to be used in or around locations where foodstuffs, works of art or
delicate articles of science, etc. are stored.
• If your appliance does not work, or is not working properly, contact the place of purchase or
the Customer Services Team.
General Care and Safety Guide
WARNING!
DANGER IF SWALLOWED
Keep batteries out of reach of
children. Swallowing may lead to
serious injury or death in as little
as 2 hours due to internal burns.
If swallowed, go straight to a
hospital emergency room.
Dispose of used batteries
immediately.
General Care and Safety Guide
The remote control supplied with this heater uses a CR2025 coin type battery
(Included).
DANGER IF SWALLOWED
Keep batteries out of reach of children. Swallowing may lead to serious injury or
death in as little as 2 hours due to internal burns.
If swallowed, go straight to a hospital emergency room.
Dispose of used batteries immediately.
Components
ASSEMBLY
Before using the heater, the feet (supplied
separately in the carton), must be fitted to the unit.
The screw pack to attach the feet to your heater will
be taped to either one of the feet for your heater, or
taped to the plug.
Carefully turn the Main Body upside-down on a
scratch-free and stable surface. Be careful to prevent
damage to the cosmetic finish or your floor surfacing.
Each foot requires two screws to attach them
securely to the heater. Two holes are pre-drilled in
each foot and in the base of the heater. Align the feet
with the holes, insert the screws and use a
screwdriver to secure the feet to the base of the
heater. Return to upright position.
WARNING: Operate the heater in the
normal upright position only with the feet
attached to the bottom. Any other
position could create a hazardous situation.
Feet x2
Screws x4
Main Body x1
Operating Your Heater
Always choose a safe location for the heater, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. Please follow
the below instructions.
WARNING: In order to avoid overheating or fire, do not cover the heater.
WARNING: Keep all objects at least 1 metre from the front, sides and rear
of the appliance.
WARNING: Do not use this heater with a programmer, separate timer,
remote-control system or any other device that switches the heater on
automatically, since a fire risk exists if the heater is covered or positioned
incorrectly.
WARNING:Never leave this heater unattended.
Ensure heater is on a flat, stable, heat-resistant surface.
Once the heater is in a safe operating position and all switches are in the off position,
insert the power plug into the mains outlet.
CAUTION: Ensure the power cord is not tight because if pulled it may
partially pull the plug from the socket. A partially inserted plug will overheat
the plug and socket and could result in fire.
Note: When the appliance is turned on for the first time, it may release a
slight odour or smoke. This odour or smoke is a normal occurrence caused by
the initial heating of the internal heating elements and should not occur
again.
Fahrenheit/Celsius
On/Off
Timer
Turbo Fan
Increase Temperature
Working Mode
CONTROL PANEL
Decrease Temperature
Operating Your Heater
HEAT CONTROL SWITCH
Check that the Power Switch on the side of the heater is set to the Off position
before plugging the heater in and turning on the mains supply. Turn the Power
Switch at the side of the heater to the “I” position. You will hear a beep.
CONTROL PANEL
Press the On/Off button on the Control Panel to turn the heater on.
The LCD will display the current room temperature and the set temperature.
Select the desired temperature by pressing the Increase or Decrease
Temperature buttons.
The heater operates between 5°C and 37°C. (The Working Mode button must be
pressed to display 1000W/1300W or 2300W to generate heat.) Please note:
Once the ‘room’ temperature is equal to or greater than the ‘set’ temperature,
the heater will stop generating heat.
Press the Working Mode button to select either 1000W, 1300W, 2300W or
Prevent Frost.
Prevent Frost is for cooler climates where the temperature may drop below 2°C.
Once this temperature is reached, if Prevent Frost is selected, the heater will start
generating heat until it reaches the Set Temperature at which time it will stop
generating heat.
Press the Turbo Fan button to increase heat output. The fan remains at the same
speed; only the element changes to create the greater/lesser heat output. Press
again to turn off.
Press the Fahrenheit/Celsius button to display the preferred temperature scale.
SUPPORT AND TECHNICAL ADVICE
Goldair – New Zealand
Monday – Friday 8am-5pm
Phone +64 (0)9 917 4000
Phone 0800 232 633
Goldair – Australia
Monday – Friday 8am-5pm
Phone +61 (0)3 9365 5100
Phone 1300 465 324
Operating Your Heater
The Timer button allows a time to be set between 1 to 24 hours. Press the
Timer button until the desired time is shown on the display (e.g. 01h 00m). Each
press of the Timer button will increase the length of time in 1 hour increments.
The heater will countdown and once the selected time has elapsed the heater
will switch off automatically.
To turn the heater off, press the On/Off button on the Control Panel again. Then
turn the Power Switch at the side of the heater to “O” position.
REMOTE CONTROL
The remote control buttons perform the same functions as those on the Control
Panel of the unit.
For best results, aim the remote directly at the display screen on the front of the
heater. The remote has a 3 metre range of operation.
The remote control requires one "CR2032" type battery (Included). Remove the
plastic tab from the battery and battery terminal prior to first use of the remote
control.
SUPPORT AND TECHNICAL ADVICE
Goldair – New Zealand
Monday – Friday 8am-5pm
Phone +64 (0)9 917 4000
Phone 0800 232 633
Goldair – Australia
Monday – Friday 8am-5pm
Phone +61 (0)3 9365 5100
Phone 1300 465 324
TECHNICAL SPECIFICATION
Model No: GCV340
Supply: 220-240VAC 50/60Hz
Wattage: 2300W
Operating Your Heater
SAFETY DEVICES
This appliance has two protection devices:
• Resettable Thermal Link - this will automatically disconnect the power to the
appliance at a pre-set overheat temperature. After cooling down it will reset and
power on again. If this occurs, investigate what is causing the appliance to overheat.
• Thermal Fuse - this disconnects the appliance permanently in case of overheating. (It
is non resettable).
CAUTION: The heater generates heat during use. Proper precautions must
be taken to prevent the risk of burns, scalds, fires or other damage to persons.
CARE AND CLEANING
• The heater requires regular cleaning to ensure trouble free operation:
• Unplug the heater from the mains supply before cleaning.
• Ensure that the heater has been allowed to cool down completely before cleaning.
• The common cause of overheating is deposits of dust or fluff in the appliance. Ensure
these deposits are removed regularly by unplugging the appliance and vacuum
cleaning the air vents and grills.
• Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and
dirt.
• Never use solutions such as petrol, thinners or polishing agents.
• Ensure the heater is dry before plugging back into the mains supply.
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase.
Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in normal
domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the
warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone
other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in relation to the
goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Two Year Warranty
Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Goldair – New Zealand
CDB Goldair
PO Box 100-707
N.S.M.C
Auckland
Phone +64 (0)9 917 4000
Phone 0800 232 633
www.goldair.co.nz
Goldair – Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone +61 (0)3 9365 5100
Phone 1300 GOLDAIR (1300 465 324)
www.goldair.com.au
