ISSUED: 04-11-06 SHEET #: 055-9458-8 07-24-2015
Visit the Peerless Web Site at www.peerlessmounts.com
1 of 9
For customer care call 1-800-729-0307 or 708-865-8870.
Read instruction sheet before you start installation and assembly.
Maximum Load Capacity: 50 lb (22.7 kg)
IMPORTANT! Be sure not to touch the projector while tightening the set screw on the
ball and socket mount. This may cause the image to be unaligned when you let go.
IMPORTANT! Turn to the appropriate page for your ceiling installation.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached hard-
ware and components.
WARNING
Model: NP01UCM
Installation and Assembly - Universal
Ceiling Mount
Table of Contents
Parts List.................................................................................................................................................................................2
To Wood Joist Finished Ceilings, Exposed Wood Joists or Wood Beam Ceilings .................................................................4
To Concrete Ceilings ..............................................................................................................................................................5
Flush Mount ............................................................................................................................................................................6
Extension Column ..................................................................................................................................................................7
Attaching Universal Adapter Plate to Projector.......................................................................................................................8
