MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
INSTRUCTION MANUAL
LED MAGNETIC TABLE LAMP
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL VT-7413
SKU 23041, 23042, 23043
RATED POWER 3W
(12x0.2W/LED mould)
RATED INPUT 5V
LUMENS 300 Lm
BEAM ANGLE 120°
CRI ≥70
PROTECTION RATING IP20
LIFE SPAN 25,000 Hours
MATERIAL ABS+PC+Metal
BATTERY CAPACITY CHARGING TIME WORKING TIME
1500 mAH 2-3 Hours
Maximum Light 2 to 3 Hours
Minimum Dark ≥ 15 Hours
Magnetic ball head
Charging port
Charging indicator
Lampshade
Metal bracket
ABS holder
Glue base
Magnetic
ball head
Magnetic
ball head
Switch Three
gears dimming
This marking indicates that this
product should not be disposed of
with other household wastes.
PRODUCT STRUCTURE
PERFORMANCE
WARNING
1. Please make sure to turn o the power
before starting the installation.
2. The light source of this luminaire is not
replaceable, when the light source reaches
its end of life the whole luminaire should be
replaced.
3. For indoor use only.
• Simple touch switch
• Three levels of brightness adjustable
• Patent Magnetic ball head design
• Built-In rechargeable battery
Touch
switch
Three levels
of brightness
adjustable
Built in
battery
Magnetic
design
PACKAGE CONTENTS
OPERATION CAUTIONS
1. Don’t connect with dimming sensing device
2. Don’t use the lamp in a humid or flammable environment.
3. Don’t pull the power plug when your hands are wet to prevent electric shock
4. Don’t cover the lamp with objects to prevent the lamp from being damaged
5. or causing danger.
Continuously touch the key, the main light changes in turn” on -> low -> medium -> high
-> o” cycle selection.
Power hint: red light when charging, green light when full.
INSTALLATION INSTRUCTION
1. Strong magnetic ball head design (adjust
more angles, illuminate more places)
. 2 Screw the metal
bracket into the base
Table Lamp
LED Lamp
Metal
Bracket
Clip Glue Base
Type-C
Line
Instruction
Clip Lamp Wall Lamp
1. Put the lamp close to the ball head and
automatically absorb
2. Find the clamping position,clamp and use
1. Clean the wall,paste the glue base
2. Put the lamp close to the ball head and
automatically absorb
