THE DEWALT RAFTER SQUARE
The DEWALT Rafter Square is designed to provide a quick, accurate,
and repeatable means for laying out and cutting the various cuts on
common, hip, valley and jack rafters used in root construction.
Description
Features
1) Common/Jack and Hip/Valley rafter scales-Defined by inch rise
per foot of run.
2) Protractor Scale-Graduated in degrees.
3) Inch Scale - 6-¾" long graduated every 1/8 inch.
4) Extra wide, fixed base
5) Extra thick body ideal for use as a saw guide
6) ¼” spaced notches for marking out scribing lines
7) Common rafter conversion chart
FIXED BASE
BACK OF RAFTER SQAURE
CONVERSION CHART
HIP-VAL
COMMON/JACK
PROTRACTORSGALE
INCH SCALE
