Installation Guide
Assembly
1 2
Cable Runway E-Bend
Model: SRL90BEND12
The SRL90BEND12 Cable Runway E-Bend creates a 90 degree gradual sweep for horizontal cable runway runs. Designed for
cabling in conformance with minimum bend radius requirements (typically 4x the cable diameter), the SRL90BEND12 is made
of lightweight 1-1/2 x 3/8 in. (38.1 x 9.53 mm) tubular aluminum to fit 12 in. (300 mm) cable runway widths.
• Conforms to Category 5e/6/6a requirements
• Easy installation when used with Tripp Lite SRLBUTTSPLICE kit
• Compatible with Tripp Lite SRCABLELADDER
Español 2 • Français 3 • Русский 4
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
27 in.
[688 mm]
Cable Runway Not Included
SRLBUTTSPLICE
(Sold Separately)
19-04-284 93-382A_RevB
