Dewalt DXWP62383 1/3HP Automatic Submersible Sump Pump

INSTRUCTION MANUAL

For DXWP62383. Also, The document are for others Dewalt models: DXWP62381, DXWP62389, DXWP62583, DXWP62581, DXWP62783, DXWP62781, DXWP62183, DXWP62181

PDF File Manual, 12 pages, Read Online | Download pdf file

DXWP62383

DXWP62381

DXWP62389

DXWP62583

DXWP62581

DXWP62783

DXWP62781

DXWP62183

DWXP62181

Aluminum, Stainless Steel and Cast Iron Submersible Sump Pump

Instruction Manual

If you have questions or comments, contact us.

1-855-222-3841

customer.service@pedrollo-usa.com

Loading ...

File type: PDF

File name: 27196522_dxwp62383.pdf

File size: 1.61 MB

File Language: English

Pages: 12

Author: Dewalt

File created: 2022-08-31

Published: 2023-09-24

Updated: 2024-02-19

Verified by Connie Boehm on 2024-02-19

Download File

Specifications

Brand: Dewalt

Model: DXWP62383

Category: Tools - Home Improvement

Assembled Depth (in inches): 9.7

Assembled Height (in inches): 12.9

Assembled Width (in inches): 10.4

Assembled Weight (in lbs): 23.8

Packaged Depth (in inches): 10.6

Packaged Height (in inches): 13.2

Packaged Weight (In lbs): 26.4

Packaged Width (in inches): 11.7

Cord Length (ft.): 10 ft

Minimum Sump Basin Diameter: 11 to 14

Pack Size: 1

Product Weight (lb.): 24 lb

Amperage (A): 6.5 A

Discharge Flow @ 0 ft. (gallons/hour): 4500

Discharge Flow @ 0 ft. (gallons/min): 75

Discharge Flow @ 10 ft. (gallons/hour): 3800

Discharge Flow @ 10 ft. (gallons/min): 63

Discharge Flow @ 15 ft. (gallons/min): 56

Maximum Horsepower (hp): 1/3

Power Type Required: AC

Voltage: 120v

Maximum Pressure (PSI): 10.8 PSI

Maximum Working Temperature (F): 120

Minimum working temperature (F): 33

Pump Switch Type: Vertical

Outlet Diameter Connection (in.): 1-1/2 FPT

View in the file: Full Specifications

See other models: DXWP61779 DXWP61774 DXWP61379DXWP61374 DXWP61379 DCSNP2142Y2-CA
