Frigidaire GCRG3038AFA free standing gas range User Manual

Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352

808528114 A (November 2019)

use

care

GAS

RANGE

Introduction. . . . . . . . . . . . . . . . . .2

Important Safety Instructions. . . . . . . .3

Cooking Recommendations. . . . . . . . .11

Before Setting Surface Controls . . . . . 14

Setting Surface Controls. . . . . . . . . . 17

Before Setting Oven Controls. . . . . . .20

Setting Oven Controls . . . . . . . . . . . 21

Care and Cleaning . . . . . . . . . . . . . 34

Before You Call . . . . . . . . . . . . . . . 39

Warranty . . . . . . . . . . . . . . . . . . 43

INTRODUCTION

Doors

 Handles are secure and tight

 Door seals completely to cabinet on all sides

Leveling

 Range is level side-to-side and front-to-back.

 Cabinet is setting solid on all corners

Electrical Power

 House power turned on

 Range wired or plugged in

Final Checks

 Shipping material removed

 Registration card sent in

Installation Checklist



Welcome to our

family

Thank you for bringing Frigidaire into your home!

We see your purchase as the beginning of a long

relationship together.

This manual is your resource for the use and care

of your product. Please read it before using your

appliance. Keep it handy for quick reference. If

something doesn’t seem right, the troubleshooting

section will help you with common issues.

FAQs, helpful tips and videos, cleaning products, and

kitchen and home accessories are available at www.

frigidaire.com.

We are here for you! Visit our website, chat with an

agent, or call us if you need help. We may be able

to help you avoid a service visit. If you do need

service, we can get that started for you.

Let’s make it ocial! Be sure to register your prod-

uct.

Keep your product info here so it’s easy to ﬁnd.

Model Number

Serial Number

Purchase Date

Serial Number Location

IMPORTANT SAFETY INSTRUCTIONS

DEFINITIONS

This is the safety alert symbol. It is

used to alert of potential personal injury

hazards. Obey all safety messages that

follow this symbol to avoid possible injury

or death.

WARNING

Indicates a potentially hazardous

situation which, if not avoided, may

result in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous

situation which, if not avoided, may result in

minor or moderate injury.

IMPORTANT

IMPORTANT indicates installation,

operation or maintenance information

which is important but not hazard-

related.

Read all instructions before using this

appliance.

This manual contains important safety

symbols and instructions. Please pay

attention to these symbols and follow all

instructions given.

Do not attempt to install or operate your

appliance until you have read the safety

precautions in this manual. Safety items

throughout this manual are labeled with a

WARNING or CAUTION statement based

on the risk type.

Warnings and important instructions

appearing in this guide are not meant to

cover all possible conditions and situations

that may occur. Common sense, caution,

and care must be exercised with installing,

maintaining, or operating your appliance.

WARNING

If the information in this manual is not fol-

lowed exactly, a re or explosion may result

causing property damage, personal injury or

death.

FOR YOUR SAFETY: Do not store or use gas-

oline or other ammable vapors and liquids in

the vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS:

Do not try to light any appliance.

Do not touch any electrical switch.

Do not use any phone in your building.

Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

If you cannot reach your gas supplier, call the

re department.

Installation and service must be performed by

a qualied installer, servicer or the gas suppli-

e r.”

NOTE

NOTE indicates a short, informal

reference – something written down

to assist the memory or for future

reference.

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT INSTRUCTIONS FOR UN-

PACKING AND INSTALLATION

IMPORTANT

Read and follow the below instructions and

precautions for unpacking, installing, and ser-

vicing your appliance.

Remove all tape and packaging before using

the appliance. Destroy the carton and plastic

bags after unpacking the appliance. Never allow

children to play with packaging material. Do not

remove the wiring label and other literature at-

tached to the appliance. Do not remove model/

serial number plate.

Cold temperatures can damage the electronic

control. When using this appliance for the rst

time, or when the appliance has not been used

for an extended period of time, be sure the

appliance has been in temperatures above 32ºF

(0ºC) for at least 3 hours before turning on the

power to the appliance.

Never modify or alter the construction of the

appliance by removing the leveling legs, panels,

wire covers, anti-tip brackets/screws, or any

other part of the appliance.

Be sure to have an appropriate foam-type re

extinguisher available, visible, and easily acces-

sible located near the appliance.

WARNING

Air curtain or other overhead range hoods

which operate that operate by blowing a

downward air ow onto a range or cooktop,

shall not be used in conjunction with gas

ranges or cooktops other than when the range

or cooktop and hood have been designed,

tested, and listed by an independent test

laboratory for use in combination with each

other.

WARNING

Tip Over Hazard

• A child or adult can tip

the range and be killed.

• Verify the anti-tip device

has been installed to floor

or wall.

• Ensure the anti-tip device is

re-engaged to floor or wall when the

range is moved.

• Do not operate the range without the

anti-tip device in place and engaged.

• Failure to follow these instructions can

result in death or serious burns to

children and adults.

Range

leveling

leg

Anti-tip

bracke

To check if the anti-tip bracket is installed

properly, use both arms to grasp the rear edge

of the range back. Carefully attempt to tilt

range forward. When properly installed, the

range should not tilt forward.

Refer to the anti-tip br

acket installation instruc-

tions supplied with your range for proper

installation.

Save these instruction for future reference

IMPORTANT SAFETY INSTRUCTIONS

GROUNDING INSTRUCTIONS

WARNING

Avoid re hazard or electrical shock. Failure to

follow this warning may cause serious injury,

re, or death.

Avoid re hazard or electrical shock. Do not

use an adapter plug, use an extension cord,

or remove grounding prong from the power

cord. Failure to follow this warning may cause

serious injury, re, or death.

Proper Installation—Be sure your appliance is

properly installed and grounded by a qualied

technician. In the United States, install in ac-

cordance with the National Fuel Gas Code ANSI

Z223.1/NPFA No. 54, latest edition and National

Electrical Code NFPA No. 70 latest edition, and

local electrical code requirements. In Canada,

install in accordance with CAN/CGA B149.1 and

CAN/CGA B149.2 and CSA Standard C22.1,

Canadian Electrical code, Part 1-latest editions

and local electrical code requirements. Install

only per installation instructions provided in the

literature package for this appliance.

For personal safety, this appliance must be

properly grounded. For maximum safety, the

power cord must be securely connected to an

electrical outlet or junction box that is the cor-

rect voltage, is correctly polarized and properly

grounded, and protected by a circuit breaker in

accordance with local codes.

It is the personal responsibility of the consumer

to have the appropriate outlet or junction box

with the correct, properly grounded wall recep-

tacle installed by a qualied electrician.

This appliance is equipped with a 3-prong

grounding plug for your protection against

shock hazard and should be plugged directly

into a properly grounded receptacle. Do not cut

or remove the grounding prong from this plug.

For personal safety, the appliance must be

properly grounded. For maximum safety, the

power cord must be plugged into an electrical

outlet that is correctly polarized and properly

grounded.

If a 2-prong wall receptacle is the only available

outlet, it is the personal responsibility of the

consumer to have it replaced with a properly

grounded 3-prong wall receptacle, installed by a

qualied technician.

See the installation instructions packaged with

this appliance for complete installation and

grounding instructions.

Do not cut, remove, or

bypass the grounding

plug under any

circumstances.

Grounding type

wall receptacle

Power supply cord

with 3-prong

grounding plug

Save these instruction for future reference

Conversion to (L.P.) Gas

This appliance allows for conversion to

Liqueﬁed Petroleum (L.P.) Gas.

WARNING

Personal injury or death from electrical

shock may occur if the conversion to L.P.

gas is not made by a qualiﬁed installer

or electrician. Any additions, changes or

conversions required in order for this ap-

pliance to satisfactorily meet the applica-

tion needs must be made by a qualiﬁed

technician.

If L.P. conversion is needed, contact your

local L.P. Gas provider for assistance.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

Stepping, leaning, or sitting on the door or

drawers of this appliance can result in serious

injuries and also cause damage to the appli-

ance.

Never cover any slots, holes, or passages in

the oven bottom or cover an entire oven rack

with any materials, such as aluminum foil or

aftermarket oven liners. -Doing so blocks air

ow through the oven and may cause car-

bon monoxide poison oning. Aluminum foil

and other liners may trap heat, causing a re

hazard.

Do not use oven or warmer drawer (if

equipped) for storage.

Never use your appliance as a space heater to

heat or warm the room. Doing so may result

in carbon monoxide poisoning and overheat-

ing of the appliance.

CAUTION

When heating fat or grease, watch it closely.

Grease may catch re if it becomes too hot.

Do not use water or our on grease res.

Smother re or ame or use dry chemical or

foam-type extinguisher. Cover the re with a

pan lid or use baking soda.

Use dry potholders. Moist or damp pothold-

ers on hot surfaces may result in burns from

steam. Do not let potholders touch hot cook-

ing areas. Do not use towels or other bulky

cloths.

Do not heat unopened food containers - Build-

up of pressure may cause container to burst

and result in injury.

IMPORTANT INSTRUCTIONS FOR USING

THE APPLIANCE

WARNING

Storage In or On Appliance—Flammable mate-

rials should not be stored in an oven or micro-

wave, near surface burners or elements, or in

the storage or warmer drawer (if equipped).

This includes paper, plastic, and cloth items,

such as cookbooks, plastic ware, and towels,

as well as ammable liquids. Do not store

explosives, such as aerosol cans, on or near

the appliance.

Do not leave children alone - Children should

not be left alone or unattended in the area

where appliance is in use. They should never

be allowed to sit or stand on any part of the

appliance, including the storage drawer, lower

broiler drawer, warmer drawer, or lower dou-

ble oven.

Do not store items of interest to children in

the cabinets above the appliance or on the

backguards of ranges. Children climbing on

or near the appliance to reach items could be

seriously injured.

Do not allow children to climb or play around

the appliance. The weight of a child on an

open oven door may cause the appliance to

tip, resulting in serious burns or other injury.

An open drawer when hot may cause burns.

Save these instruction for future reference

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

Wear proper apparel - Loose-tting or hanging

garments should never be worn while using

the appliance. Do not let clothing or other

ammable materials contact hot surfaces.

Do not touch surface burners or elements,

areas near these burners or elements, interior

surfaces of the oven, or the warmer drawer

(if equipped). Surface burners and elements

may be hot even though they appear cool.

Areas near surface burners and elements may

become hot enough to cause burns. During

and after use, do not touch, or let clothing or

other ammable materials touch these areas

until they are cool. These areas may include

the cooktop, surfaces facing the cooktop,

oven vent areas, oven door, and oven window.

Do not attempt to operate the appliance

during a power failure. If the power fails, al-

ways turn o the appliance. If the appliance is

not turned o and the power resumes, electric

surface elements may resume operation when

power is restored. Once the power resumes,

reset the clock and the oven function.

IMPORTANT INSTRUCTIONS FOR USING

YOUR GAS COOKTOP

CAUTION

Use Proper Flame Size — Adjust ame size

so it does not extend beyond the edge of the

utensil. The use of undersized utensils will

expose a portion of the burner ame to direct

contact and may result in ignition of clothing.

Proper relationship of utensil to ame will also

improve eciency

Know which knob or key controls each surface

heating area. Place cookware with food on the

cooking area before turning it on. Turn the

cooking area o before removing the cookware.

Use proper pan size. This appliance is equipped

with one or more surface units of dierent

sizes. Select cookware with at bottoms that

match the surface unit heating element. The

use of undersized cookware may expose a

portion of the ame to direct contact and may

result in the ignition of clothing or other items.

Using the proper cookware on the cooking

areas will improve eciency.

Always turn knob to the full LITE position when

igniting top burners. Visually check that burner

has lit. Then adjust the ame so it does not

extend beyond the edge of the utensil.

When you are aming foods under a ventilating

hood, turn the fan on.

Save these instruction for future reference

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT INSTRUCTIONS FOR USING

YOUR OVEN

Protective liners—Do not use aluminum

foil, aftermarket oven liners, or any other

materials or devices to line oven bottom,

oven racks, or any other part of the appli-

ance. Only use aluminum as recommend-

ed for baking, such as lining cookware or

as a cover placed on food. Any other use

of protective liners or aluminum foil may

result in a risk of electric shock or ﬁre or a

short circuit.

Use care when opening oven door, lower

oven door, or warmer drawer (some mod-

els). Stand to the side of the appliance

when opening the door of a hot oven. Let

hot air or steam escape before you remove

or replace food in the oven.

Keep oven vent ducts unobstructed.

Touching surfaces in this area when the

oven is on may cause severe burns. Do not

place plastic or heat-sensitive items on or

near the oven vent. These items can melt

or ignite.

Placement of oven racks - Always place

oven racks in desired location while oven

is cool. If rack must be moved while oven

is hot, do not let potholder contact hot

burner or element in oven. Use potholders

and grasp the rack with both hands to re-

position. Remove all cookware and utensils

before moving the rack.

Do not use a broiler pan without its insert.

Broiler pans and inserts allow dripping fat

to drain away from the high heat of the

broiler. Do not cover the broiler insert with

aluminum foil; exposed fat and grease

could ignite.

Do not cook food on the oven bottom. Al-

ways cook in proper cookware and always

use the oven racks.

Save these instruction for future reference

To reduce the risk of burns, ignition of

ammable materials, and spillage due to

unintentional contact with the utensil, the

handle of the utensil should be positioned so

that it is turned inward, and does not extend

over adjacent surface burners

Never leave surface burners unattended at

high heat settings — Boil overs cause smoking

and greasy spill overs that may ignite, or a

pan that has boiled dry may melt.

Glazed cooking utensils — Only certain types

of glass, glass/ceramic, ceramic,earthenware,

or other glazed utensils are suitable for cook

top service without breaking due to the

sudden change in temperature. Check the

manufacturer’s recommendations for cook top

use.

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT INSTRUCTIONS FOR CLEAN-

ING YOUR APPLIANCE

CAUTION

Before manually cleaning any part of the ap-

pliance, be sure all controls are turned o and

the appliance is cool. Cleaning a hot appliance

can cause burns.

Clean the appliance regularly to keep all parts

free of grease that could catch re. Do not

allow grease to accumulate. Greasy deposits in

the fan could catch re.

Always follow the manufacturer’s recommended

directions for use of kitchen cleaners and aero-

sols. Be aware that excess residue from clean-

ers and aerosols may ignite causing damage

and injury.

Clean venitlating hoods frequently - Grease

should not be allowed to accumulate on hood

or lter. Follow the manufacturer’s instructions

for cleaning vent hoods.

IMPORTANT INSTRUCTIONS FOR SELF

CLEANING OVENS

CAUTION

Before using self clean, remove the broiler

pan, any food, utensils, and cookware from

the oven, storage drawer or warming drawer

(if equipped). Remove oven racks unless oth-

erwise instructed.

Do not clean the oven door gasket. The door

gasket is essential for a good seal. Care should

be taken not to rub, damage, or move the

gasket.

Do not use oven cleaners. No commercial oven

cleaner or oven liner protective coating of any

kind should be used in or around any part of

the appliance.

Use the self clean cycle to clean only the parts

listed in this manual.

Some birds are extremely sensitive to the

fumes given o during the self clean cycle of

any oven. Move birds to another well-ventilated

room.

Save these instruction for future reference

IMPORTANT SAFETY INSTRUCTIONS

WARNING

California Residents: for cancer and reproduc-

tive harm information, visit

www.P65Warnings.ca.gov

IMPORTANT INSTRUCTIONS FOR SER-

VICE AND MAINTENANCE

Do not repair or replace any part of the appli-

ance unless specically recommended in the

manuals. All other servicing should be done

only by a qualied technician. This reduces the

risk of personal injury and damage to the appli-

ance.

Always contact your dealer, distributor, service

agent, or manufacturer about problems or con-

ditions you do not understand.

Ask your dealer to recommend a qualied tech-

nician and an authorized repair service. Know

how to disconnect the power to the appliance

at the circuit breaker or fuse box in case of an

emergency.

Remove the oven door from any unused oven if

it is to be stored or discarded.

Do not touch a hot oven light bulb with a damp

cloth. Doing so could cause the bulb to break.

Handle halogen lights (if equipped) with paper

towels or soft gloves. Disconnect the appliance

or shut o the power to the appliance before

removing and replacing the bulb.

COOKING RECOMMENDATIONS

Bakeware

The material of bakeware aects how evenly and quickly it transfers heat from the pan to the food.

Material Attributes Recommendation

Shiny metal bakeware

Shiny, aluminum, and non-coat-

ed bakeware is the best for even

heating. It is suitable for all baked

goods.

Recommended cooking temperatures

and times are based on shiny metal

bakeware.

Dark metal bakeware

Dark bakeware cooks hotter than

shiny bakeware.

Reduce the cooking temperature by

25° F

(13-14° C) when using dark bakeware.

Glass bakeware

Glass bakeware cooks hotter

than shiny bakeware.

Glass is convenient, as the same

piece of bakeware can be used

for cooking, serving, and storing

food.

Reduce the cooking temperature by

25° F

(13-14° C) when using glass bakeware.

Insulated bakeware

Insulated bakeware cooks cooler

than shiny bakeware.

Insulated bakeware is designed

for baking in gas ovens.

Reduce the cooking temperature by

25° F

(13-14° C) when using glass bakeware.

COOKING RECOMMENDATIONS

Cooking Conditions

Conditions in your kitchen can aect the performance of your appliance when cooking food.

Conditions

Attributes Recommendation

Aging cookware As pans age and become

discolored, cooking times may

need to be reduced slightly.

If food is too dark or overcooked, use the

minimum cook time in the recipe or packag-

ing.

If food is too light or undercooked, use the

middle to maximum cook time in the recipe

or packaging.

High altitude Air is drier and air pressure is

lower.

Water boils at a lower tem-

perature, and liquids evapo-

rate faster.

Foods may take longer to

bake.

Doughs may rise faster.

Adjust cooking temperature, cooking time, or

recipes as needed.

Increase amount of liquid in baking recipes.

Increase cook time on cooktop. Cover dishes

to reduce evaporation.

Increase bake time or oven temperature.

Reduce amount of baking soda or baking

powder in recipe. Reduce rising time or

punch down dough and allow it to rise twice.

Cooking Results

Small adjustments may ﬁx a problem with food not being as done as you like or more done than you like.

Problems

Recommendation

Food too light Use the middle to maximum cook time recommended on packaging or recipe.

Food too dark Use the minimum cook time recommended on packaging or recipe.

Cooking Tips

Use these additional tips to get the best results from your appliance.

Cooking

Recommendation

Baking

Rack placement Follow the instructions in “Setting Oven Controls” on starting on page 13.

When using only one rack, place the rack so the food is in the center of the

oven.

Preheat Fully preheat the oven before baking items like cookies, cakes, biscuits and

breads. Insert food immediately after the beep.

Checking food Use the window and oven light when checking food. Opening the door may

reduce baking performance.

Quick Bake Quick bake is the best function to use for baking on multiple racks. For best

performance, see “Convection Bake” on page 18.

Food placement Allow at least 2 inches (5 cm) of space between bakeware for proper air cir-

culation.

COOKING RECOMMENDATIONS

Cooking

Recommendation

Broiling / Roasting

Broiling pan For best results when broiling, use a broil pan with a broil pan insert de-

signed to drain the fat from the food, help avoid spatter, and reduce smok-

ing. The broiler pan will catch grease spills, and the insert helps prevent

grease splatters.

If a broiler pan and insert are not supplied with this appliance, they may be

purchased from Frigidaire.com.

Convection Cooking

Convection attributes Convection cooking uses a fan to circulate hot air around the oven and

food. It browns food more evenly and reduces hot spots in the oven.

Convection saves time when using multiple racks or cooking several food

items at once.

Quick bake Reduce cooking temperature by 25° F (13-14° C) from the recipe unless the

recipe is written for convection baking.

Preheat the oven for best results.

BEFORE SETTING SURFACE CONTROLS

Assembly of the Burner Caps

Make sure that all of the surface burner caps and

surface burner grates are installed correctly and at

the correct locations.

1. Remove all packing material from the cooktop

area.

2. Make sure burner caps are properly placed on

the surface burners.

3. Unpack the burner grates and position them on

the cooktop.

4. Discard all packing material..

On round-style burners, the burner cap lip (Figure

1) should ﬁt snug into the center of the burner head

and rest level. Refer to Figure 1 for correct and in-

correct burner cap placement.

Burner cap lip

Burner cap

Burner head

Burner cap

Burner head

Figure 1: Burner caps and burner heads

Figure 1: Cap placement

CAUTION

• Do not allow spills, food, cleaning agents, or

any other material to enter the gas oriﬁce

holder opening.

• Always keep the burner caps and burner

heads in place whenever the surface burners

are in use.

• Never place ﬂammable items on the cooktop.

Once in place, you may check the ﬁt by gently slid-

ing the burner cap from side to side (Figure 2) to

be sure it is centered and ﬁrmly seated. When the

burner cap lip makes contact inside the center of

the burner head you will be able to hear the burner

cap click

Figure 2: Gently move cap for proper placement

IMPORTANT

Please note that the burner cap should not move

o the center of the burner head when sliding

from side to side.

• Check and be sure that all oval-style burner

caps (some models) are correctly in place on

oval burner heads.

• Do not use the surface burners without the

burner caps properly installed. Improperly

seated burner caps may prevent burners from

lighting or cause uneven ﬂame and heating.

• Missing pieces or improper installation may

lead to spills, burns, or damage to your range

and cookware.

• Never place ﬂammable items on the cooktop.

Gas surface burner types

The cooktop is equipped with gas surface burners

with dierent BTU ratings. The ability to heat food

quickly and in large amounts increases as the burn-

er size increases.

• Small burners are best used for low-ﬂame heat-

ing of small amounts of food.

• Standard burners can be used for most surface

cooking needs.

• The largest burner is best used for bringing

large quantities of liquid rapidly up to tem-

perature or when preparing larger quantities

of food. The large burner is located at the right

front position on the cooktop.

Regardless of size, always select cookware that

is suitable for the amount and type of food being

prepared. Select a burner and set the ﬂame size

appropriately for the pan. Never allow ﬂames to

extend beyond the outer edge of the pan.

BEFORE SETTING SURFACE CONTROLS

Using Proper Cookware

The size and type of cookware used will inﬂuence

the heat setting needed for best cooking results.

Be sure to follow the recommendations for using

proper cookware as illustrated in “Figure 3: Testing

cookware” and “Figure 4: Proper cookware”.

Figure 3: Testing cookware

Check for ﬂatness by ro-

tating a ruler across the

bottom of the cookware

(see “Figure 3: Testing

cookware”). Cookware

should have ﬂat bot-

toms that make good

contact with the entire

surface of the heating

element.

•F

lat bottom and straight

sides.

•T

ight fitting lids.

•W

eight of handle does

not tilt pan. Pan is well

balanced

•P

an sizes match the

amount of food to be

prepared and the size

of the surface element.

•M

ade of material that

conducts heat well.

•E

asy to clean.

•A

lways match pot

diameter to element

size.

•C

urved and warped pans.

•Cookware larger than

element by more than

one-half inch or 12mm.

•Heavy handle tilts pan.

•Pan is much smaller

than the element.

Cookware Material Types

The cookware material determines how evenly and

quickly heat is transferred from the surface ele-

ment to the pan bottom. The most popular materi-

als available are:

• Aluminum - Excellent heat conductor. Some

types of food will cause it to darken (Anodized

aluminum cookware resists staining and pit-

ting).

• Copper - Excellent heat conductor but discol-

ors easily (see Aluminum).

• Stainless - Slow heat conductor with uneven

cooking results. Durable, easy to clean, and

resists staining.

• Cast Iron - A slow heat conductor, but will re-

tain heat very well. Cooks evenly once cooking

temperature is reached.

• Porcelain-enamel on metal - Heating character-

istics will vary depending on base material.

• Glass - Slow heat conductor.

IMPORTANT

Do not place empty aluminum, glass, or porce-

lain-enamel coated cookware on the element.

The melting point of cookware made with these

materials may be reached quickly, especially if left

empty. If the cookware melts it will damage the

cooktop. Follow all the cookware manufacturer’s

recommendations for use and care of cookware.

IMPORTANT

NEVER place or straddle a cooking utensil over

two dierent surface cooking areas at the same

time. Incorrect use may damage the cooktop.

Figure 4: Proper cookware

BEFORE SETTING SURFACE CONTROLS

Install Burner Grates

To install burner grates, place the grates ﬂat-side

down and align them into the cooktop recess..

Figure 5: Gently move cap for proper placement

Gas surface burner types

The cooktop is equipped with gas surface burners

with dierent BTU ratings. The ability to heat food

quickly and in large amounts increases as the burn-

er size increases.

• Small burners are best used for low-ﬂame heat-

ing of small amounts of food.

• Standard burners can be used for most surface

cooking needs.

• The largest burner is best used for bringing

large quantities of liquid rapidly up to tem-

perature or when preparing larger quantities

of food. The large burner is located at the right

front position on the cooktop.

Regardless of size, always select cookware that

is suitable for the amount and type of food being

prepared. Select a burner and set the ﬂame size

appropriately for the pan. Never allow ﬂames to

extend beyond the outer edge of the pan.

IMPORTANT

• Make sure the burner grates are properly

placed on the cooktop before using the sur-

face burners (Figure 5). The grates are de-

signed to rest inside the recess on the cook-

top.

• Grates should rest ﬂush against each other

and against the sides of the recess.

• Do not line the area underneath the grates or

any part of the cooktop with aluminum foil or

with any other lining.

SETTING SURFACE CONTROLS

Setting surface controls

The ability to heat food quickly and in large vol-

umes increases as the burner size increases. Your

gas appliance may be equipped with many dier-

ent sized surface burners.

It is important to select cookware that is suitable

for the amount and type of food being prepared.

Select a burner and ﬂame size appropriate for the

cookware size.

• The standard size burner or burners may be

used for most surface cooking needs.

• Small burners are best used for low-ﬂame heat-

ing of small amounts of food.

• Large burners are best for bringing large quan-

tities of liquid to temperature or heating larger

quantities of food.

Setting a surface burner:

1. Place cooking utensil on center of surface

burner grate. Be sure the cooking utensil rests

stable on the burner grate.

2. Push the burner’s surface control knob in and

turn counterclockwise out of the OFF position

(Figure 6).

3. Release the surface control knob and rotate to

the LITE position ( ). Visually check that the

burner has a steady gas ﬂame.

4. Once the surface burner has a ﬂame, push the

surface control knob in and turn counterclock-

wise to the desired ﬂame size setting. Adjust

the ﬂame as needed using the knob markings.

Figure 6: Surface control knob

CAUTION

Do not place ﬂammable items such as plastic

wrappings, spoon holders, or plastic salt and

pepper shakers on the cooktop when it is in use.

These items could melt or ignite. Potholders, tow-

els, or wooden spoons could catch ﬁre if placed

too close to the surface burners.

NOTE

When setting a surface control knob to the lite

position, all of the electronic surface ignitors will

spark at the same time. However, only the surface

burner you are setting will ignite.

In the event of an electrical power outage, the

surface burners may be lit manually. To light a

surface burner, hold a lit match to the burner

head, then slowly turn the surface control knob

to lite. Once the burner ignites, push in and turn

knob out of lite then to the desired ﬂame setting.

Use caution when lighting surface burners man-

ually.

SETTING SURFACE CONTROLS

Set proper burner ﬂame size

The color of the ﬂame is the key to proper burner

adjustment. A good ﬂame is clear, blue and hardly

visible in a well-lighted room. Each cone of ﬂame

should be steady and sharp. Adjust or clean the

burner if ﬂame is yellow-orange.

For most cooking: start on the highest setting and

then turn to a lower setting to complete the pro-

cess. Use the recommendations below as a guide

for determining proper ﬂame size for various types

of cooking (Table 1).

For deep fat frying: use a thermometer and adjust

the surface knob accordingly. If the fat is too cool,

the food will absorb the fat and be greasy. If the

fat is too hot, the food will brown so quickly that

the center will be under-cooked. Do not attempt to

deep fat fry too much food at once as the food will

neither brown nor cook properly.

Flame size Type of cooking

High ﬂame Start most foods; bring water

to a boil; pan broiling

Medium ﬂame Maintain a slow boil; thicken

sauces, gravies; steaming

Low ﬂame Keep foods cooking; poaching;

stewing

These settings are based on medium-weight met-

al or aluminum pans with lids. Settings may vary

when using other types of pans.

Table 1: Recommended flame settings for cook-

ing

CAUTION

Never extend the ﬂame beyond the outer edge of

the cooking utensil. A higher ﬂame wastes en-

ergy, and increases your risk of being burned by

the ﬂame (Figure 2).

Figure 7: Proper burner flame

SETTING SURFACE CONTROLS

Cooking with a griddle (some models)

Figure 8: Griddle

The griddle is a versatile accessory that is perfect

for cooking foods that require large ﬂat surfaces

such as pancakes, French toast, grilled sandwiches,

bacon, and also for cooking dierent foods at the

same time.

After use, let the griddle cool before washing. Hand

wash with hot soapy water. Do not soak. Dry thor-

oughly. Do not put a griddle in a dishwasher.

If you would like to purchase a griddle, you can

order one from Frigidaire.com.

Using the griddle:

Place the griddle securely on top of the burner

grates. Preheat the griddle for 5 minutes on medi-

um to medium low setting. Slow preheat ensures

even heat distribution during the cooking process.

DO NOT preheat the griddle on HI setting. Preheat-

ing on HI may warp the griddle and prevent even

heat distribution.

Home Canning

Be sure to read and observe all the following points

when home canning with your appliance. Check

with the USDA (United States Department of Agri-

culture) Web site and be sure to read all the infor-

mation they have available as well as follow their

recommendations for home canning procedures.

• Use only a completely ﬂat bottom canner with

no ridges that radiate from the bottom cen-

ter when home canning. Heat is spread more

evenly when the bottom surface is ﬂat. Use a

straight-edge to check canner bottom.

• Make sure the diameter of the canner does

not exceed 1 inch beyond the surface element

markings or burner.

• It is recommended to use smaller diameter can-

ners on electric coil and ceramic glass cooktops

and to center canners on the burner grates.

• Start with hot tap water to bring water to boil

more quickly.

• Use the highest heat setting when ﬁrst bringing

the water to a boil. Once boiling is achieved,

reduce heat to lowest possible setting to main-

tain that boil.

• Use tested recipes and follow instructions care-

fully. Check with your local Cooperative Agri-

cultural Extension Service or a manufacturer of

glass jars for the latest canning information.

• It is best to can small amounts and light loads.

• Do not leave water bath or pressure canners on

high heat for an extended amount of time.

BEFORE SETTING OVEN CONTROLS

Types of Oven Rack

Figure 9: Oven vent

• Flat oven racks may be used for most cooking

needs and may be placed in most oven rack

positions.

at

oven rack

Removing, Replacing, and Arranging Flat

or Offset Oven Racks

Always arrange the oven racks when the oven is

cool.

To remove - Pull the oven rack straight forward un-

til it reaches the stop position. Lift up front of oven

rack slightly and slide out.

To replace - Place the oven rack on the rack guides

on both sides of oven walls. Tilt the front of oven

rack upward slightly and slide the oven rack back

into place. Be sure oven racks are level before us-

ing.

Oven Vent Location

The oven is vented as shown below. When the oven is

on, warm air is released through the vent. This venting is

necessary for proper air circulation in the oven and good

baking results. Do not block oven vent. Never close o

the openings with aluminium foil or any other material.

Steam or moisture may appear near the oven vent. This

is normal.

Figure 10: Oven rack types

CAUTION

Always use pot holders or oven mitts when using

the oven. When cooking, the oven interior, oven

exterior, oven racks, and cooktop will become

very hot which can cause burns.

Remove all oven racks before starting a self clean

cycle. If oven racks are left inside the oven during

a cleaning cycle, the slide ability of the oven

racks may be damaged and all of the oven racks

will lose their shiny ﬁnish.

To prevent possible damage to the oven, do not

attempt to close the oven door until all the oven

racks are fully positioned back inside the oven

cavity.

WARNING

Protective Liners — Do not use aluminum foil

or any other material or liners to line the oven

bottom, walls, racks or any other part of the

range. Doing so will alter the heat distribution,

produce poor baking results, and possibly cause

permanent damage to the oven interior. Improp-

er installation of these liners may result in risk of

electric shock or ﬁre. During self clean, tempera-

tures in the oven will be hot enough to melt foil.

SETTING OVEN CONTROLS

Bake

Time

Self

Clean

Bake Broil

Steam

Clean

Set

Clock

Quick

Bake

Timer

Oven

Preheat

Door Locked

OFF

Hold

Oven Control Features

1. Bake - Use to select bake feature.

2. Quick Bake - Quick Bake uses a fan to circu-

late the oven's heat uniformly and continuously

around the oven.

3. Broil - Use to set Broil feature.

4. Oven Light - Use to turn on internal light when

checking on food. Also will turn on when the

oven door is open.

5. Steam Clean - The Steam Clean feature oers

a time saving method for cleaning of small and

light soils.

6. Self Clean - Use to with arrow keys to set self

clean cycle of 2 or 3 hours.

7. Oven on indicator light - The oven light will

glow each time the oven turns on to maintain

the set oven temperature.

8. Preheat light - The preheat light will glow when

the oven is preheating or if the desired tem-

perature is reset higher than the actual oven

temperature.

9. Door locked - The door locked light will ﬂash

when the oven door locks and unlocks, when

the oven door lockout is active, or when the self

clean cycle feature is active.

10. Up and Down arrows - Use with the feature or

function keys to set oven temperature, bake

time, start time, clean time, and setting or ad-

justing the clock and minute timer.

11. Timer on-off - Use to set or cancel the minute

timer. The minute timer does not start or stop

any cooking function. Timer on-o is used to

set the continuous bake function.

12. Bake Time - Enters the length of baking time

desired.

13. OFF - Use to clear any feature except the time

of day and minute timer and to activate oven

lockout feature.

14. Set Clock - Use with arrow keys to set the time

of day

Table 2: Minimum and maximum control settings

Feature Mode Min Temp/

Time

Max Temp/

Time

Bake 170°F (77°C) 550°F (288°C)

Quick

Bake

170°F (77°C) 550°F (288°C)

Broil LO 400°F

(205°C)

HI 550°F

(288°C)

Timer 12 Hr.

24 Hr.

0:01 Min.

0:01 Min

11:59 Hr./Min.

Clock

Time

12 Hr.

24 Hr.

1:00 Hr./Min.

0:00 Min

12:59 Hr./Min.

23:59 Hr./Min.

Bake

Time

12 Hr.

24 Hr.

0:01 Min.

0:01 Min

11:59 Hr./Min.

Self

Clean

Time

2 hours 3 hours

Note: An entry acceptance tone (1beep) will

sound each time a key is touched (the oven lock

key is delayed 3 seconds). An entry error tone (3

short beeps) will sound if the entry of the tem-

perature or time is below the minimum or above

the maximum settings for the feature.

SETTING OVEN CONTROLS

Setting the Clock

When the appliance is ﬁrst plugged in or when the

power supply to the appliance has been interrupt-

ed, the display will ﬂash 12:00. It is recommended

to always set the clock for the correct time of day

before using the appliance.

To set the clock:

1. Press Set Clock once (do not hold Set Clock

key down).

2. Within 5 seconds, press and hold

until the correct time of day appears in the

display.

Temperature display (Fahrenheit/Celsius)

The electronic oven control is set to operate in

Fahrenheit (°F) at the factory. The oven may be

programmed for any temperature from 170°F to

550°F (77°C to 288°C).

To change the temperature to Celsius (°C) or from

°C to °F:

1. Press broil. — — appears in the display.

2. Press and hold

until HI appears in the

display.

3. Press and hold broil until °F or °C appears in

the display.

4. Press

or to change °F to °C or °C to

°F. To accept the change, wait 6 seconds.

Changing between continuous bake set-

ting or 12-hour energy saving feature

The oven control has a built-in 12-hour energy sav-

ing feature that will shut o the oven if the oven is

left on for more than 12 hours. The oven control can

be programmed to override this feature for contin-

uous baking.

To change the continuous bake setting:

1. Press and hold timer on-off for 6 seconds until

a tone sounds. — — hr will appear in the display

for continuous cooking. The current time of day

will return to the display.

2. To cancel the continuous bake setting, press

timer on-off and hold for 6 seconds until a tone

sounds. 12 hr will appear in display indicating

that the control has returned to the 12-hour

energy saving feature.

Setting oven lockout

The control can be programmed to lock the oven

door and lockout the oven control keypad.

To set the oven lockout feature:

1. Press OFF and hold for 3 seconds. Loc will

appear in display, the door locked indicator

light will ﬂash, and the motor driven door lock

will begin to close. Allow about 15 seconds for

the oven door to lock. Once the oven door is

locked, the current time of day will appear in

the display.

2. To cancel the Oven Lockout feature, press OFF

and hold for 3 seconds. The control will unlock

the oven door and resume normal operation.

NOTE

The clock cannot be changed when the oven is

set for cooking.

IMPORTANT

Changing to continuous bake or 12 hour mode does

not change how the cooktop controls operate.

NOTE

If any control key is pressed with the oven lock-

out feature active, Loc will appear in the display

until the control key is released. But it does not

disable the clock, kitchen timer, or the interior

oven lights.

SETTING OVEN CONTROLS

Operating oven light

The interior oven light will automatically turn on

when the oven door is opened. Press

. to turn the

interior oven lights on and o whenever the oven

door is closed.

The interior oven light is located at the upper left

rear wall of the oven interior. To change the interi-

or oven light, see “Changing the oven light” in the

Care & Cleaning section.

Setting the minute timer

1. Press timer on-off.

2. Press

to increase time in one-minute

increments. Press and hold

to increase

time in 10-minute increments. The timer can be

set for any amount of time from 1 minute to 11

hours and 59 minutes.

3. When the set time ends, the timer will beep

three times and will continue to beep three

times every minute until timer on-off is

pressed.

To change the timer while it is in use:

While the timer is active and shows in the display,

press and hold

or to increase or de-

crease the time remaining.

To cancel the minute timer before the set time has

run out:

Press timer on-off once.

NOTE

The minute timer will not start or stop the cook-

ing process. The minute timer can be used alone

or while using any of the other oven features. If

another feature is active when the minute timer is

active, the minute timer will show in the display.

To view information about other active features,

press the key for that feature

SETTING OVEN CONTROLS

Setting Bake

Bake cooks with heat that rises from the oven

bottom. The heat and air circulate naturally in the

oven. The oven indicator light above the BAKE

key will remain on until oven is preheated. During

baking the oven indicator light will turn on and o

as the oven cycles to maintain set temperature.

Follow baking recommendations for best results.

The oven can be programmed to bake at any

temperature from 170°F to 550°F (77°C to 288°C).

The factory preset automatic bake temperature is

350°F (177°C).

Baking Tips

For best bake results:

• Fully preheat the oven before baking.

• When baking items like cookies, cakes, biscuits,

and breads using a single rack place rack in

position 4.

• When using any single rack for items like frozen

pies, angel food cake, breads, and casseroles,

use rack position 3.

• For best results when baking cakes using two

oven racks, place racks in positions 3 and 5

(Figure 11).

• When baking using two oven racks, position

cookware as shown in Figure 1.

• Allow at least 2 inches (5 cm) of space between

cookware for proper air circulation.

• Do not open the oven door often. Doing so will

extend baking time.

• Leave oven light o while baking.

To set Bake:

1. Press Bake. — — — appears in the display.

2. Within 5 seconds, press

or . The dis-

play will show 350°F (177°C). The temperature

can then be adjusted in 5°F (1°C) increments.

3. When a key is released, the oven will begin

heating to the selected temperature. When the

oven reaches the set temperature, the preheat

indicator light will turn o and the control will

beep three times.

To cancel the baking function, press OFF.

To change oven temperature after Bake has start-

ed:

1. Press Bake.

2. Press

or to increase or decrease to

a new temperature. The oven indicator light on

the electronic display will turn on and o when

using the bake feature and during preheat. This

is normal and indicates that the oven is cycling

to maintain the selected baking temperature.

To cancel baking press OFF.

Figure 11: Rack positions; pan positions for two

rack baking.

SETTING OVEN CONTROLS

Setting Quick Bake

Quick Bake uses a fan to circulate the oven's heat

uniformly and continuously around the oven. This

improved heat distribution allows for fast, even

cooking and browning results. Meats cooked with

Quick Bake are crisp on the outside while staying

tender and moist on the inside. Breads and pastry

brown more evenly. Most foods can be cooked fast-

er and more evenly with Quick Bake.

The oven may be programmed to Quick Bake at

any temperature from 170°F to 550°F (77°C to

288°C). The factory preset Quick Bake temperature

is 350°F (177°C).

Benefits of the Quick Bake feature:

• Foods may cook up to 25 to 30% faster, saving

time and energy.

• Multiple rack baking.

Baking Tips

• For optimum cooking results it is recommend-

ed to preheat the oven when baking foods such

as cookies, biscuits and breads.

• Reduce oven temperature 25°F from recipe's

recommended oven temperature. Follow the

remainder of the recipe's instructions using the

minimum recommended cook time.

• When using 2 oven racks place racks in posi-

tions 3 and 5 and position cookware as shown

in Figure 12.

• For single rack baking use rack position 4.

Roasting Tips

• Preheating is not necessary when roasting

foods using Quick Bake. Do not cover foods

when dry roasting.

• For Turkey, roasts and hams, use rack position

• For small cuts of meat or poultry use rack posi-

tions 2 or 3.

To set Quick Bake:

1. Press Quick Bake. — — — ° appears in the dis-

play.

2. Within 5 seconds, press

or . The dis-

play will show 350°F (177°C). The temperature

can then be adjusted in 5°F (1°C) increments

using the up or down arrow keys.

3. When a key is released, the oven will begin

heating to the selected temperature.

4. When the oven reaches the set temperature,

the preheat indicator light will turn o and the

control will beep three times.

To cancel Quick Bake, press OFF.

To change oven temperature after Bake has

started:

1. Press Quick Bake.

2. Press

or to increase or decrease to

a new temperature. The oven indicator light on

the electronic display will turn on and o when

using the bake feature and during preheat. This

is normal and indicates that the oven is cycling

to maintain the selected baking temperature.

3. To cancel baking press OFF.

Figure 12: Rack and pan positions

SETTING OVEN CONTROLS

Setting Broil

Broiling is direct heat cooking and will produce

some smoke. If smoke is excessive, place food fur-

ther away from the element. Watch food to prevent

burning.

When broiling, always remember to arrange the

oven racks while oven is still cool. Position the rack

as suggested in Table 3.

WARNING

Should an oven ﬁre occur, close the oven door

and turn the oven o. If the ﬁre continues, use a

ﬁre extinguisher. Do not put water or ﬂour on the

ﬁre. Flour may be explosive.

To set Broil:

1. Arrange the oven rack while oven is still cool.

2. Press broil. — — will appear in display.

3. Press

for HI broil or for LO broil.

Most foods may be broiled at the HI broil set-

ting. Select the LO broil setting to avoid excess

browning or drying of foods that should be

cooked to the well-done stage.

4. For optimum results, preheat broil for 2 to 5

minutes before adding food.

5. If using a broil pan and insert, place insert on

the broil pan. Place food on the insert

6. Place the broiler pan and insert on the oven

rack.

7. Broil on one side until food is browned. Turn

and broil food on second side.

8. When broiling is ﬁnished press OFF.

Figure 13: Rack positions

CAUTION

Always use oven mitts. Oven racks will become

very hot which can cause burns.

NOTE

The broiler pan and the insert (some models)

allow grease to drain and be kept away from the

high heat of the broiler. Do not use the pan with-

out the insert. Do not cover the insert with alumi-

num foil; the exposed grease could ignite.

To purchase a broiling pan and insert, visit frigid-

aire.com

NOTE

Always pull the oven rack out to the stop position

before turning or removing food.

Figure 14: Broil pan and insert

SETTING OVEN CONTROLS

Table 3: Broil recommendations

Food item

Rack

Position

Temp Cook time in minutes Internal

Temperature

Doneness

1st side 2nd side

Steak 1” thick 6 HI(550°F) 6:00 5:00 135°F (57°C) Rare**

Steak 1” thick 6 HI(550°F) 7:00 5:00 145ºF (63ºC) Medium-well

Steak 1” thick 6 HI(550°F) 8:00 7:00 170°F (77ºC) Well

Pork Chops 3/4 “thick 6 HI(550°F) 8:00 6:00 170°F (77ºC) Well

Chicken - Bone In 5 LO(400°F) 20:00 10:00 170°F (77ºC) Well

Chicken Boneless 6 LO(400°F) 8:00 6:00 170°F (77ºC) Well

Fish 6 HI(550°F) 13:00 -- 170°F (77ºC) Well

Shrimp 5 HI(550°F) 5:00 -- 170°F (77ºC) Well

Hamburger 1” thick 6 HI(550°F) 6:00 5:00 135°F (57°C) Rare**

Hamburger 1” thick 6 HI(550°F) 9:00 7:00 145ºF (63ºC) Medium

Hamburger 1” thick 6 HI(550°F) 10:00 8:00 170°F (77ºC) Well

The U.S. Department of Agriculture states, **Rare fresh beef is popular, but you should know that cooking it to only

140°F (60°C) means some food poisoning organisms may survive.” (Source: Safe Food Book, Your Kitchen Guide,

USDA Rev. June 1985.) The lowest temperature recommended by the USDA is 145°F (63°C) for medium rare fresh

beef. For well done 170°F (77ºC). All cook times shown are after 2 minutes of preheating.

SETTING OVEN CONTROLS

Setting Bake Time

The Bake Time key sets the amount of time needed

for baking. The oven will turn on immediately and

stop automatically after the set bake time ends.

To program the oven to begin baking immediately

and to shut off automatically (timed bake):

1. Be sure the clock is set to the correct time of

day.

2. Place the food in the oven.

3. Press Bake. — — — ° appears in the display.

4. Within 5 seconds, press

or .

The display will show 350°F (177°C). The tem-

perature can then be adjusted in 5°F (1°C)

increments,

5. Press Bake Time. 0:00 will appear in the dis-

play.

6. Press

or until the desired baking

time appears in the display.

7. The oven will turn on and begin heating.

When the set bake time runs out:

End will appear in the display, and the oven will

shut o automatically.

The control will beep three times every 60 seconds

as a reminder until OFF is pressed.

NOTE

Bake Time will not operate when using the broil

feature.

Once the controls are set, the oven will come on

and begin heating to the selected baking tem-

perature. The oven temperature (or time of day)

will show in the display.

Adjusting the oven temperature

Your appliance has been factory calibrated and

tested to ensure an accurate baking temperature.

For the ﬁrst few uses, follow your recipe times and

temperature recommendations carefully. If you

think the oven is cooking too hot or too cool for

your recipe times, you can adjust the control so

the oven cooks hotter or cooler than the tempera-

ture displayed.

CAUTION

Do not use oven thermometers such as those

found in grocery stores to check the temperature

settings inside your oven. These oven thermome-

ters may vary as much as 20 to 40 degrees from

actual temperatures.

Oven temperature adjustments made will not

aect the broil or self cleaning feature tempera-

tures.

If the display is set for Celsius, adjustments made

will be in 1°C increments with each press of arrow

keys

To adjust oven temperature:

1. Press Bake.

2. Set the temperature to 550°F (288°C) by

pressing and holding

3. Within 3 seconds, press and hold Bake until

numeric digit(s) appear. Release Bake key. The

display now indicates the amount of degrees

oset between the original factory tempera-

ture setting and the current temperature set-

ting. If the oven control has the original factory

calibration, the display will read 00.

4. The temperature can now be adjusted up or

down 35°F (19°C), in 5°F increments. Press and

hold

to adjust the temperature higher un-

til the desired amount of oset appears in the

display. When lowering the oven temperature

using

, a minus sign (-) will appear before

the number to indicate that the oven will be

cooler by the displayed amount of degrees.

5. When you have made the desired adjustment,

press OFF to go back to the time of day dis-

play.

SETTING OVEN CONTROLS

Setting the Sabbath Feature for the Jew-

ish Sabbath and Holidays (some models)

For further assistance, guidelines for

proper usage, and a complete list

of models with the Sabbath feature,

please visit the web at www.star-k.org.

This appliance provides special set-

tings for use when observing the Jewish Sabbath/

Holidays. Sabbath mode disables all audible tones

or visual display changes on the oven control. Bake

heating is the only cooking feature available while

in the Sabbath mode. Oven controls are locked

during Sabbath mode.

You must ﬁrst set the Bake feature and tempera-

ture and, if needed, Bake Time. Any settings made

prior to setting the Sabbath mode will be visible

in the displays. The Bake Time option, if set prior

to the Sabbath mode, will give one audible alert at

the end of Bake Time.

Important: The Sabbath mode will override the

factory preset 6 hour energy saving mode, and the

appliance will stay on until the cooking features are

cancelled. If any of the cooking features are can-

celled when the appliance is in the Sabbath mode,

no audible or visual indicators will be available to

verify the cancellation.

If the oven interior lights are needed, be sure to

activate them prior to setting the Sabbath mode.

Once the oven light is turned on and the Sabbath

mode is active, the oven light will remain on until

the Sabbath mode is turned o and the oven lights

are turned o. The oven door will not activate the

interior oven lights when the oven door is opened

or closed.

It is recommended that any oven temperature

modiﬁcation made within an active Sabbath mode

press the up or down arrow key.

The temperature will increase or decrease with

each press by 5°F or 1°C and the change will be

accepted automatically.

If the oven temperature is set outside of the tem-

perature range, the oven will default to the nearest

available temperature. Try to set the desired oven

temperature again.

CAUTION

Food poisoning hazard. Do not let food sit for

more than one hour before or after cooking.

Doing so can result in food poisoning or sickness.

Foods that can easily spoil such as milk, eggs,

ﬁsh, meat or poultry, should be chilled in the

refrigerator ﬁrst. Even when chilled, they should

not stand in the oven for more than 1 hour before

cooking begins, and should be removed promptly

when ﬁnished cooking.

Important:

• Do not attempt to activate any other oven

function except Bake while the Sabbath fea-

ture is active. The following keys will function

correctly when the Sabbath feature is active:

Up and Down arrow keys, Bake, and OFF. ALL

OTHER KEYS should not be used once the Sab-

bath feature is active.

• You may change the oven temperature once

baking has started. Press Bake, use the arrow

keys to raise or lower the oven temperature.

Each press of an arrow key will raise or lower

the temperature by 5°F (1°C).

• Remember that the oven control will no longer

provide audible tones or display any further

changes when the Sabbath feature is active.

• The oven will shut-o automatically after com-

pleting a bake time and therefore may only be

used once during the Sabbath/Jewish Holidays.

SETTING OVEN CONTROLS

To program oven to Bake with default oven tem-

perature of 350°F and activate the Sabbath fea-

ture:

1. Be sure the clock is set with correct time of day

and place food in oven.

2. Press Bake. — — — appears in the display.

3. Within 5 seconds press or. The display will

show 350°F (177°C). By holding the up or down

arrow key the temperature can be adjusted in

5° increments (1°C).

4. If a bake time is desired enter the time at this

point. See “Setting Bake Time” on page 20 for

detailed instructions. If not, skip this step.

NOTE: The oven will shut o after using Bake Time

and may only be used once during Sabbath mode.

5. Press and hold the Bake Time key and Set

Clock key simultaneously for about 3 seconds.

SAb will appear in the display indicating the

oven is properly set for the Sabbath feature

(Figure 15).

Once SAb appears in the display the oven control

will no longer beep or display any further changes.

To turn the oven off and keep the Sabbath feature

active:

Press OFF.

Figure 15: Oven set for Sabbath baking

To turn off the Sabbath feature:

Press and hold both Bake Time key and Set Clock

key simultaneously for at least 3 seconds to turn

the Sabbath feature o. The control will provide an

acceptance tone, and SAb will disappear from the

display. The oven is no longer programmed for the

Sabbath feature.

What to do during a power failure or power inter-

ruption after the Sabbath feature was activated:

Should you experience a power failure or interrup-

tion, the oven will shut-o. When power is restored

the oven will not turn back on automatically. The

oven will remember that it is set for the Sabbath,

and the oven display will show the message SF for

Sabbath failure (Figure 16).

The food may be safely removed from the oven

while still in the Sabbath feature, however the oven

cannot be turned back on until after the Sabbath/

Holidays. After the Sabbath observance turn OFF

the Sabbath feature.

Press and hold both Bake Time key and Set Clock

key for at least 3 seconds simultaneously to turn

the Sabbath feature o. SF will disappear from the

display, and the oven may be used with all normal

functions.

Figure 16: Display showing Sabbath failure

SETTING OVEN CONTROLS

Self Clean

A self cleaning oven cleans itself with temperatures

well above normal cooking temperatures which

eliminate soils completely or reduces them to a

ﬁne powdered ash you can wipe away with a damp

cloth.

While the oven is in operation, the oven heats to

temperature much higher than those used in nor-

mal cooking. Sounds of metal expansion and con-

traction are normal. Oder is also normal because

the food soil is being removed. Smoke may appear

through the oven vent.

CAUTION

During the self cleaning cycle, the outside of the

range can become very hot to the touch. Do not

leave small children unattended near the appli-

ance.

The health of some birds is extremely sensitive to

the fumes given o during the self cleaning cycle

of any range. Move birds to another well-ventilat-

ed room.

Do not force the oven door open. This can dam-

age the automatic door locking system. Use

caution when opening the door after the self

cleaning cycle is complete. The oven may still be

VERY HOT.

Do not line the oven walls, racks, bottom, or any

other part of the range with aluminum foil. Doing

so will destroy heat distribution, produce poor

baking results, and cause permanent damage to

the oven interior (aluminum foil will melt to the

interior surface of the oven).

IMPORTANT

Adhere to the following self clean precautions:

• Do not use oven cleaners or oven protective

coatings in or around any part of the oven

interior.

• Do not clean the oven door gasket (Figure

17). The woven material of the oven door gas-

ket is essential for a good seal. Care should

be taken not to rub, damage, or remove the

gasket.

• Do not use any cleaning materials on the oven

door gasket. Doing so could cause damage.

• Remove the broiler pan and insert, all uten-

sils, and ANY ALUMINUM FOIL. These items

cannot withstand high cleaning temperatures

and will melt.

• Completely remove ALL OVEN RACKS and

ANY ACCESSORIES. If the oven racks are not

removed, they will lose their special coating

properties and no longer slide in and out of

the oven cavity easily.

• Remove any excessive spills. Any spills on the

oven bottom should be wiped-up and re-

moved before starting the self cleaning cycle.

To clean, use hot, soapy water and a cloth.

Large spills can cause heavy smoke or ﬁre

when subjected to high temperatures.

• Do not allow food spills with a high sugar or

acid content (such as milk, tomatoes, sauer-

kraut, fruit juices, or pie ﬁlling) to remain on

the surface as they may leave a dull spot even

after cleaning.

• Clean any soil from the oven frame, the door

liner outside the oven door gasket, and the

small area at the front center of the oven bot-

tom. These areas heat suciently to burn soil

on. Clean with soap and water. These areas

are shown in white.

Figure 17: Door Gasket

SETTING OVEN CONTROLS

To set a self clean cycle

1. Press Self Clean. --- appears in the display.

2. Press

until 3:00 appears in the display for

a 3 hour self clean process, or push

until

2:00 appears in the display for a 2 hour self

clean process.

3. As soon as the controls are set, the motor driv-

en lock will begin to close automatically and

the door locked indicator light will ﬂash. Do not

open the oven door while the light is ﬂashing

(allow about 15 seconds for the oven door to

lock).

4. CLn will appear in the display during the self

clean cycle, and the door locked light will glow

until the self cleaning cycle is complete or can-

celled and the oven temperature has cooled.

When the self clean cycle has completed:

1. The time of day will appear in the display win-

dow, and the Self Clean indicator light and Door

Locked light will continue to glow.

2. Once the oven has cooled down for about 1

hour and the Door Locked light has gone out,

the oven door may be opened.

3. To avoid possible burns, use care when open-

ing the oven door after the self cleaning cycle.

Stand to the side of the oven when opening the

door to allow hot air or steam to escape.

To stop or interrupt a self clean cycle (once it has

been activated):

1. Press OFF.

2. Once the oven has cooled down for about 1

hour and the door locked light has turned o,

the oven door can be opened.

3. Restart the self clean cycle once all conditions

have been corrected.

NOTE

Whenever the self clean feature is active, you

may check the amount of time remaining in the

self clean cycle by pressing the clean key. Re-

member the range door cannot be opened until

the range has cooled suciently. You will need

to add about 1 hour to the time displayed before

you can use the range for cooking.

When the oven is cool, wipe away any residue or

powdered ash with a damp cloth or paper towel.

SETTING OVEN CONTROLS

Steam Clean

The Steam Clean feature oers a chemical free and

time saving method to assist in the routine clean-

ing of small and light soils.

Figure 18: Add 1 cup of tap watter to bottom of

oven

Figure 19: Clean around the oven door gasket

CAUTION

• Do not add bleach, ammonia, oven cleaner, or

any other abrasive household cleaners to the

water used for Steam Clean.

• Before cleaning any part of the oven, be sure

all controls are turned o and the oven is cool.

The oven may be hot and can cause burns.

Be sure the oven is level and cool before starting

Steam Clean. If the oven temperature is above

room temperature a triple beep will be heard and

the function will not start. Steam Clean produces

best results when started with a cool oven.

To set a Steam Clean cycle:

1. Remove all racks and oven accessories.

2. Scrape or wipe loose debris and grease from

the oven bottom.

3. Pour 1 cup of tap water onto the oven bottom.

(Figure 19) Close oven door.

Notes:

• Opening the oven door during the steam clean

cycle prevents the water from reaching the

temperature needed to clean.

• For best results, clean oven immediately after

the cycle is complete. Steam clean works best

for soils on the oven bottom.

• A non-abrasive scouring pad, stainless steel

sponge, plastic scraper, or eraser style cleaning

pad (without cleaner) can be used for dicult

soils. Moisten pads with water before use.

• Place a paper towel or cloth in front of the

oven to capture any water that may spill while

wiping out.

• Do not leave the residual water in the oven for

any length of time.

• Some condensation or water vapor may appear

close to the oven vent and the oven door glass.

This is normal. The oven gasket may become

damp; do not wipe dry.

• Local water sources often contain minerals

(hard water). If hard water deposits occur, wipe

cavity with a 50/50 solution of water and vine-

gar or 50/50 solution of lemon juice and water.

4. Press steam clean.

5. Press

or to activate. St Cn will ap-

pear in the display.

6. The oven will start automatically and the dis-

play will show the time remaining in the Steam

Clean cycle. Do not open the door during this

time. If door is open while in steam clean (d-O)

will appear in the display.

7. When the steam clean cycle is complete an

alert will sound and the END message will

show in the display. Press OFF to return to

the clock. Press OFF at any time to cancel the

Steam Clean.

8. Take care opening the door when the steam

clean is ﬁnished. Stand to the side of the oven

out of the way of escaping vapor.

9. Wipe oven cavity and bottom. Do not clean

oven door gasket (Figure 18). Avoid leaning or

resting on the oven door glass while cleaning

cavity.

CARE AND CLEANING

Remove spills and any heavy soiling as soon as

possible. Regular cleaning will reduce the diculty

of major cleaning later.

Figure 20: Use cleaners with caution

Surface or Area Cleaning Recommendation

Aluminum and vinyl Using a soft cloth, clean with mild dish detergent and water. Rinse

with clean water, dry and polish with a soft, clean cloth.

Painted and plastic control knobs

Painted body parts

Painted decorative trims

Using a soft cloth, clean with mild dish detergent and water or a

50/50 solution of vinegar and water. Rinse with clean water, dry and

polish with a soft, clean cloth. Glass cleaners may be used, but do

not apply directly to surface; spray onto cloth and wipe.

Control panel Using a soft cloth, clean with mild dish detergent and water or a

50/50 solution of vinegar and water. Do not spray liquids directly on

the oven control and display area. Do not use large amounts of water

on the control panel - excess water on the control area may cause

damage to the appliance. Do not use other liquid cleaners, abrasive

cleaners, scouring pads, or paper towels - they will damage the ﬁn-

ish.

Control knobs Using a soft cloth, clean with mild dish detergent and water or a

50/50 solution of vinegar and water. To remove control knobs: turn

to the OFF position, grasp ﬁrmly, and pull o the shaft. To replace

knobs after cleaning, line up the OFF markings and push the knobs

into place.

Stainless Steel Using a soft cloth, clean with mild dish detergent and water or a

50/50 solution of vinegar and water. Rinse with clean water, dry with

a soft clean cloth. Do not use cleaners containing abrasives, chlo-

rides, chlorine, or ammonia.

Smudge Proof™ Stainless Steel

Black Stainless Steel

Using a soft cloth, clean with mild dish detergent and water or a

50/50 solution of vinegar and water. Rinse with clean water, dry with

a soft clean cloth. Do not use appliance cleaner, stainless steel clean-

er, or cleaner containing abrasives, chlorides, chlorine, or ammonia.

These cleaners may damage the ﬁnish.

CAUTION

Before cleaning any part of the appliance, be sure

all controls are turned o and the appliance is

cool.

If ammonia or appliance cleaners are used, they

must be removed and the appliance must be

thoroughly rinsed before operating. Follow man-

ufacturer’s instructions and provide adequate

ventilation.

CARE AND CLEANING

Surface or Area Cleaning Recommendation

Porcelain-enameled broiler pan

and insert

Porcelain door liner

Porcelain body parts

Rinse with clean water and a damp cloth. Scrub gently with a soapy,

non-abrasive scouring pad to remove most spots. Rinse with a 50/50

solution of clean water and ammonia. If necessary, cover dicult

spots with an ammonia-soaked paper towel for 30 to 40 minutes.

Rinse and wipe dry with a clean cloth. Remove all cleaners or future

heating could damage the porcelain. Do not allow food spills with a

high sugar or acid content (milk, tomatoes, sauerkraut, fruit juices or

pie ﬁlling) to remain on porcelain surfaces. These spills may cause a

dull spot even after cleaning.

Manual clean oven interior The oven interior is porcelain coated and safe to clean using oven

cleaners. Always follow manufacturer's instructions for cleaners. Af-

ter cleaning, remove any oven cleaner or the porcelain may become

damaged during future heating. Do not spray oven cleaner on any

electrical controls or switches. Do not spray or allow oven cleaner to

build up on the oven temperature sensing probe. Do not spray clean-

er on oven door trim, door gasket, plastic drawer glides, handles or

any exterior surfaces of the appliance.

Self-cleaning oven interior Before setting a self-clean cycle, clean soils from the oven frame,

areas outside the oven door gasket, and the small area at the front

center of the oven bottom. “Self Clean” on page 31.

Oven door Use mild dish detergent and water or a 50/50 solution of vinegar

and water to clean the top, sides, and front of the oven door. Rinse

well. Glass cleaner may be used on the outside glass of the door. Ce-

ramic smoothtop cleaner or polish may be used on the interior door

glass. Do not immerse the door in water. Do not spray or allow water

or cleaners to enter the door vents. Do not use oven cleaners, clean-

ing powders, or any harsh abrasive cleaning materials on the outside

of the oven door.

Do not clean the oven door gasket. The oven door gasket is made of

a woven material which is essential for a good seal. Do not rub, dam-

age, or remove this gasket.

Gas cooktop surface burners See “When replacing the burner caps, be sure the burner caps are

seated ﬁrmly on top of the burner heads.” on page 36.

Gas cooktop surface grates

Gas cooktop burner caps

Use a non-abrasive plastic scrubbing pad and mild abrasive cleanser.

Do not allow food spills with a high sugar or acid content (milk, to-

matoes, sauerkraut, fruit juices or pie ﬁlling) to remain on the burner

grates or burner caps. These spills may cause a dull spot even after

cleaning. Clean these spills as soon as surfaces are cool. Thoroughly

dry immediately following cleaning.

CARE AND CLEANING

Cleaning the sealed burners

To avoid possible burns, do not attempt cleaning

before turning o all surface burners and allowing

them to cool.

Any additions, changes, or conversions required in

order for this appliance to satisfactorily meet the

application needs must be made by an authorized

qualiﬁed Agency. Routinely clean the cooktop.

Wipe with a clean, damp cloth and wipe dry to

avoid scratches. Keeping the surface burner head

ports and slots clean will prevent improper ignition

and an uneven ﬂame.

To clean recessed and contoured areas of cooktop:

• If a spill occurs on or in the recessed or con-

toured areas, blot up spill with an absorbent

cloth.

• Rinse with a clean, damp cloth and wipe dry.

Burner Cap

Burner Head

Correct Burner Cap

Placement

Incorrect Burner Cap

Placement

Burner Cap Lip

Figure 21: Burner Cap

To clean burner heads:

1. Remove the burner cap from the burner head

(see Figure 21). Clean the cap with hot soapy

water and dry thoroughly

orifice port

slots

ignition port

ignitor

Figure 22: Cooktop cleaning

2. For burned-on and dried spills, apply hot soapy

water to the burner head. Allow time for the

soils to soften.

3. Use a toothbrush to clean all over the burner

head (see Figure 22).

4. Use the toothbrush to clean the slots and holes

in the burner (see Figure 3).

5. Use a needle or ﬁne wire to clean out the igni-

tion port.

6. Wipe the burner head clean with a soft, clean

cloth, sponge, or scratch-free cleaning pad.

7. Before using the cooktop again, make sure the

burner caps are properly placed and seated on

the burner heads. When placed correctly, the

burner cap is centered on the burner head and

will click into place on the burner head. You can

wiggle the cap to test placement, it should not

move o the burner head (see “Assembly of the

Burner Caps” on page 14

Important notes:

• The surface burner heads are secured to the

cooktop and must be cleaned in place on the

cooktop.

• Always keep the surface burner caps in place

whenever a surface burner is in use.

• When replacing the burner caps, be sure the

burner caps are seated ﬁrmly on top of the

burner heads.

• For proper ﬂow of gas and ignition of burners

do not allow spills, food, cleaning agents, or

any other material to enter the gas oriﬁce port

opening.

CAUTION

To avoid possible burns do not attempt to oper-

ate the surface burners without the burner caps.

Do not use spray oven cleaner on the cooktop.

CARE AND CLEANING

Replacing the Oven Light

Replacing the oven interior light bulb:

The interior oven light is located at the rear of the

oven cavity and covered with a glass shield. The

glass shield must be in place whenever the oven is

in use (Figure 23).

1. Turn electrical power o at the main source or

unplug the appliance.

2. Remove the interior oven light shield after re-

moving the wire holder by carefully moving the

wire to the side of the glass shield. The tension

from the wire holds the glass shield in place.

3. Pull the shield straight out. Do not twist or turn.

4. Replace the bulb with a new appliance bulb.

5. Replace the glass oven light shield. Replace

wire holder.

6. Turn the power back on again at the main

source (or plug the appliance back in).

7. Be sure to reset the time of day on the clock.

wire

holder

glass

shield

Figure 23: Oven light protected by glass shield

Use the storage drawer for storing cooking utensils.

The drawer can be removed to facilitate cleaning

under the range. Use care when handling the drawer.

Removing the Storage Drawer

Figure 24: Open storage drawer

Figure 25: Closed storage drawer

CAUTION

Be sure the oven is unplugged and all parts are

cool before replacing the oven light.

CARE AND CLEANING

Removing and Replacing the Oven Door

To remove the oven door:

1. Open oven door completely, horizontal with

ﬂoor (See Figure 26).

2. Pull the door hinge locks on both left and right

door hinges down from the oven frame com-

pletely towards the oven door (Figure 27). A

tool such as a small ﬂat-blade screwdriver may

be required.

3. Firmly grasp both sides of oven door along the

door sides. Do not use the oven door handle

(See Figure 28).

4. Close the door to approximately 10 degrees

from the door frame (See Figure 28).

5. Lift the oven door hinge arms over the roller

pins located on each side of the oven frame

(See Figure 29).

To replace the oven door:

1. Firmly grasp both sides of oven door along the

door sides. Do not use the oven door handle

(See Figure 28).

2. Holding the oven door at the same angle as the

removal position, seat the hook of the hinge

arm over the roller pins located on each side of

the oven door frame (See Figure 29). The hook

of the hinge arms must be fully seated onto the

roller pins.

3. Fully open the oven door, horizontal with ﬂoor

(See Figure 26).

4. Push the door hinge locks up towards and into

the oven frame on both left and right oven door

hinges to the locked position (See Figure 27).

5. Close the oven door.

Oven door

hinge

locations

Figure 26: Door hinge location

Figure 27: Door hinge Locks

about

10°

hinge

oven

door

Figure 28: Holding door for removal

roller

hinge

arm

Figure 29: Replacement and location of hinge

arm and roller pin

CAUTION

Be sure the oven is unplugged and all parts are

cool before replacing the oven light.

IMPORTANT

Special door care instructions - Most oven doors

contain glass that can break. Do not hit the glass

with pots, pans, or any other object. Scratching,

hitting, jarring, or stressing the glass may weaken

its structure, causing an increased risk of break-

age at a later time. Do not close the oven door

until all of the oven racks are fully in place.

BEFORE YOU CALL

Oven Baking

For best cooking results, preheat the oven before baking cookies, breads, cakes, pies, pastries, etc. There

is no need to preheat the oven for roasting meat or baking casseroles. The cooking times and tempera-

tures needed to bake a product may vary slightly from your previously owned appliance.

Baking Problems and Solutions Baking Problems

Baking Problems Causes Corrections

Cookies and bis-

cuits burn on the

bottom.

Cookies and biscuits put

into oven before oven is

preheated.

Allow oven to preheat to desired temperature before

placing food in oven.

Choose pan sizes that will permit at least 2” of air

space

Cakes too dark on

top or bottom

Cakes put in oven before

oven is preheated.

Rack position too high or

too low.

Oven too hot.

Allow oven to preheat to the selected temperature

before placing food in the oven.

Use proper rack position for baking needs.

Set oven temperature 25°F (13°C) lower than recom-

mended.

Cakes not done in

center

Oven too hot.

Incorrect pan size.

Pan not centered iIn oven.

Glass cookware slow heat

conductor.

Set oven temperature 25°F (13°C) lower than recom-

mended.

Use pan size suggested in recipe.

Use proper rack position and place pan so there are

at least 2” (5.1 cm) of space on all sides of pan.

Reduce temperature and increase cook time or use

shiny bakeware.

Cakes not level.

Oven not level.

Pan too close to oven wall

or rack overcrowded.

Pan warped.

Oven light left on while

baking.

Place a marked glass measuring cup ﬁlled with water

on the center of the oven rack. If the water level is

uneven, refer to the installation instructions for level-

ing the oven.

Use proper rack posiReltion and place pan so there

are at least 2” (5.1 cm) of space on all sides of pan.

Do not use pans that are dented or warped.

Do not leave the oven light on while baking.

Foods not done

when cooking time

is over.

Oven too cool.

Oven overcrowded.

Oven door opened too

frequently.

Set oven temperature 25°F (13°C) higher than sug-

gested and bake for the recommended time.

Be sure to remove all pans from the oven except the

ones to be used for baking.

Open oven door only after the shortest recommend-

ed baking time.

BEFORE YOU CALL

1-800-265-8352 (Canada)

Frigidaire.ca

1-800-374-4432 (United States)

Frigidaire.com

Let us help you troubleshoot your concern! This section will help you with common issues. If you need us,

visit our website, chat with an agent, or call us. We may be able to help you avoid a service visit. If you do

need service, we can get that started for you!

Problem Cause / Solution

Entire appliance does not

operate

Appliance not connected. Make sure power cord is plugged properly into

outlet. Check your fuse box or breaker box to make sure the circuit is active.

Electrical power outage. Check house lights to be sure. Call your local elec-

tric company for service outage information.

Oven Problems

Problem Cause / Solution

Poor baking results. Many factors aect baking results. Use proper oven rack position. Center

food in the oven and space pans to allow air to circulate. Preheat the oven

to the set temperature before placing food in the oven. Try adjusting the

recipe's recommended temperature or baking time. See “Adjusting the

Oven Temperature” on page 26 if you feel the oven is too hot or too cool.

Flames inside oven or

smoking from oven vent.

Excessive spills in oven. Grease or food spilled onto the oven bottom or

oven cavity. Wipe up excessive spills before starting the oven. If ﬂames or

excessive smoke are present when using broil, see “Setting Broil” on page

26.

Oven smokes excessively

when broiling.

Incorrect setting. Follow the “Setting Broil” on page 26.

Meat too close to the broil element or burner. Reposition the broil pan to

provide proper clearance between the meat and broil element or burner.

Remove excess fat from meat. Cut remaining fatty edges to prevent curling,

but do not cut into lean.

Grease build up on oven surfaces. Regular cleaning is necessary when broil-

ing frequently. Grease or food splatters will cause excessive smoking.

Oven control panel beeps

and displays any F or E

code error.

Oven control has detected a fault or error condition. To clear the error, press

the OFF key on the control panel. Once the error code is cleared, try the

bake or broil function. If the F or E code error repeats, turn o the power

to appliance, wait 5 minutes, and then repower the appliance. Set the clock

with correct time of day. Try the bake or broil function again. If the fault

recurs, press the OFF key to clear.

Oven portion of appliance

does not operate.

Be sure the regulator gas valve is turned to ON. See installation instructions.

The time of day is not set. The clock must be set in order to operate the

oven. See “Setting the Clock” on page 22.

Be sure the oven controls are set properly for the desired function. See

“Oven Control Features” starting on page 14 and review instructions for the

desired cooking function in this manual or see “Entire appliance does not

operate.” in this checklist.

Convection fan does not

rotate.

Oven door is open. The convection fan will turn o if the oven door is

opened when convection is active. Close the oven door.

On gas models, the convection fan will begin to rotate about 6 minutes into

the preheating process.

BEFORE YOU CALL

Cooktop Problems

Problem Cause / Solution

Surface burners do not

ignite.

Surface control knob was not completely turned to LITE (). Push in and turn

the surface control knob to LITE until the burner ignites and then turn the

control knob to the desired ﬂame size.

Burner ports are clogged. With the burner OFF and cool, use a small-gauge

wire or needle to clean the burner head slots and ignition ports. See“Clean-

ing the Cooktop and Surface Burners” in the Care & Cleaning section on

page 25 for additional cleaning instructions.

Range power cord is disconnected from outlet (electric ignition models

only). Be sure the power cord is securely plugged into the power outlet.

Circuit is broken. Check breaker box or fuse box.

Electrical power outage. Burners may be lit manually. See”Setting surface

controls” on page 17

Surface burner ﬂame

uneven or only part way

around burner cap.

Burner slots or ports are clogged. With the surface burner OFF and cool,

clean ports with a small-gauge wire or needle. If moisture is present after

cleaning, lightly fan the ﬂame and allow the burner to operate until ﬂame is

full.

Burner caps are not seated properly. Check that all burner caps are level

and seated correctly on the burner heads. See“Cleaning the Cooktop and

Surface Burners” in the Care & Cleaning section on “Cleaning the sealed

burners” on page 36 for additional cleaning instructions.

Surface burner ﬂame is

too high.

Surface control knob is set too high. Adjust to a lower ﬂame setting.

Burner caps are not seated properly. Check that all surface burner caps are

level and seated correctly on the surface burner heads. See“Cleaning the

Cooktop and Surface Burners” in the Care & Cleaning section on page 25

for additional cleaning instructions.

Incorrect L.P. conversion. Refer to L.P. conversion kit instructions to correct.

Surface burner ﬂame is

orange.

Dust particles in main gas line. Allow the burner to operate a few minutes

until ﬂame turns blue. In coastal areas, a slightly orange ﬂame is unavoid-

able due to salt content in the air.

Incorrect L.P. conversion. Refer to L.P. conversion kit instructions to correct.

BEFORE YOU CALL

Frigidaire GCRG3038AFA free standing gas range

Product's Documents

User Manual

Specifications

Frigidaire GCRG3038AFA Questions and Answers

Related Products

Frigidaire FFGF3056TSD free standing gas range

Frigidaire FFGF3054TBD free standing gas range

Frigidaire FGGF3036TDE free standing gas range

Frigidaire FFGH3054USC free standing gas range

Frigidaire LFGF3054TFC free standing gas range

Frigidaire FGGF3059TFE free standing gas range
