If you have any questions or comments,
please call the Snow Joe
®
+ Sun Joe
®
customer service department at:
1-866-SNOWJOE (1-866-766-9563)
SHOVELUTION
®
SNOW SHOVEL
20-INCH | STRAIN-REDUCING
Model SJ-SHLV20
© 2022 by Snow Joe
®
, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
EN
Form No. SJ-SJ-SHLV20-880E-MR1
FOR STORAGE:
Make a loop with the retaining strap around
the spring-loaded handle, and with the other
end, secure to knob on the upper pole.
m CAUTION!
HANDLE IS SPRING LOADED UNDER HEAVY TENSION.
To avoid injury, securely grasp handle before cutting zip ties.
Then, remove retaining strap and save for later storage.
TO DISASSEMBLE:
Follow instructions above in reverse order.
TO ASSEMBLE:
1. Depress the small button at the end of the lower
pole, push and insert the lower pole into the poly
blade unit until it snaps securely into place.
2. Remove the knob and the bolt from the upper pole.
3. Insert the top of the lower pole into the upper pole.
4. Align bolt holes, insert the bolt into the square hole,
through pole.
5. Tighten with the knob.
lower
pole
upper
pole
knob bolt
poly blade
unit
