Operation Guide ID-15S
1
MA1205-EA
ILLUSTRATION
©
2012 CASIO COMPUTER CO., LTD.
1cm
ALM/SNZ DEMO
MAX/MIN
ON
OFF
RESET SET
C/ F
SNZ
ALM/SNZ DEMO
MAX/MIN
ON
OFF
RESET SET
SNZ
ALM/SNZ DEMO
MAX/MIN
ON
OFF
RESET SET
C/ F
SNZ
A
L
M
/
S
N
Z
D
E
MO
M
A
X
/
M
I
N
O
N
O
F
F
R
E
S
E
T
S
E
T
C
/
F
S
N
Z
• A sticker is affixed to the glass of the clock when you purchase it. Be sure to remove the sticker before using the
clock.
• Depending on the clock model, its configuration may differ somewhat from that shown in the illustration.
Current time
(Hour, minutes,
seconds)
Day of the week
Current temperature
Date
(month - day)
PM
indicator
Alarm time
Alarm on
indicator
Snooze on
indicator
Alarm Off Snooze Alarm On
GENERAL GUIDE
11
11
1 ALM/SNZ button
Pressing this button while the alarm is sounding stops the alarm.
22
22
2 DEMO button
Press this button to test the alarm sound.
33
33
3 Alarm Mode selector
SNZ: Snooze alarm on
ON: Alarm on
OFF: Alarm off
44
44
4 MAX/MIN button
Press this button to display the high and low temperature values.
55
55
5
°C/°F button
Press this button to toggle the temperature units between Celsius and Fahrenheit.
66
66
6 + / – buttons
Use these buttons to change the alarm time or the setting that is flashing on the display.
77
77
7 RESET button
Press this button to reset the clock after replacing its batteries.
88
88
8 SET button
Use this button when setting the current time.
USING THE CLOCK
1. Press the SET button (8) to cycle through the setting screens as shown below.
12-hour/24-hour
Setting Screen
Time Setting ScreenMonth and Day
Setting Screen
Year Setting Screen
Normal Timekeeping Screen Contrast Setting Screen
2. While the screen you want is displayed, use the + and
– buttons (6) to change the flashing digits.
• Holding down + or – changes the flashing digits at
high speed.
• You can set the year in the range of 2000 to 2099.
The day of the week is set automatically in
accordance with the date setting.
• Pressing + or – while the Time Setting Screen is on
the display causes the seconds count to be reset to
00.
• Each press of + or – while the 12-hour/24-hour
Setting Screen is on the display toggles between
12-hour and 24-hour timekeeping.
• You can set the contrast level in the range of 1 to 10.
3. After making the settings you want, use the SET button (8) to display the Normal Timekeeping Screen.
• The clock automatically returns to the Normal Timekeeping Screen if you leave a setting screen on the display
for about three minutes without performing any operation.
ALM/SNZ DEMO
MAX/MIN
ON
OFF
RESET SET
C/ F
SNZ
Press
–
to
decrease
the flashing
digits.
Press
+
to
increase
the flashing
digits.
