LEGACY MODEL - 42" CLASSIC FRENCH DOOR REFRIGERATOR/FREEZER
BI-42UFD/S
FEATURES
Monitor and control remotely with Wi-Fi connectivity
Preserves refrigerated foods with cool, moist air and frozen foods with
frigid, dry air
Fight spoilage and odors with a NASA-inspired air purification system
Locks in cold air to ensure freshness with magnetic door seals
Keeps produce fresher with high-humidity, sealed crisper and deli drawers
Controls temperature within one degree of setpoint
Filters ice, removing contaminants, chlorine taste, and odor
Yields ice automatically and "max ice" for additional production
Ensures excellent visibility with bright lights
Refer to freshness cards for tips on food preservation, use, and care
ACCESSORIES
90° Door Stop
Air Purification Cartridge
Egg Container
Legacy 42" Stainless Steel Kickplate
Legacy Grille Frame - 84"
Legacy Pro Handle
Legacy Stainless Steel Pro Louvered Grille - 84"
Legacy Stainless Steel Side Panel
Legacy Tubular Handle
Stainless Steel Pro Louvered Grille - 83"
Stainless Steel Pro Louvered Grille - 88"
Water Filter
Water Filter
White Side Panel
Accessories are available through an authorized dealer.
For local dealer information, visit subzero-wolf.com/locator.
HANDLE OPTIONS
PRODUCT DETAILS
REFRIGERATOR
• 1 refrigerator storage drawers with adjustable dividers
• 1 high-humidity crisper drawer with adjustable dividers
• 2 adjustable dairy compartments
• 4 glass refrigerator shelves (3 adjustable; 1
stationary)
• 5 refrigerator door bins (3 adjustable; 2 stationary)
• LED refrigerator and freezer lights
FREEZER
• 1 full-extension roll-out freezer drawer
• Automatic ice maker with removable ice container
Specifications are subject to change without notice. This information was generated on December 8, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.
LEGACY MODEL - 42" CLASSIC FRENCH DOOR REFRIGERATOR/FREEZER
PRODUCT SPECIFICATIONS
Model BI-42UFD/S
Dimensions 42"W x 84"H x 24"D
Refrigerator Capacity 17.9 cu. ft.
Freezer Capacity 6.3 cu. ft.
Electrical Supply 115 VAC, 60 Hz
Electrical Service 15 amp dedicated circuit
Plumbing Supply 1/4" OD copper, braided stainless steel
or PEX tubing
Plumbing Pressure 35–120 psi
Receptacle 3-prong grounding-type
ELECTRICAL PLUMBING
NOTE: Dimensions in parenthesis are in millimeters unless otherwise specified
INTERIOR VIEW
This illustration is intended for interior reference only and may not represent the
exterior of the model being specified.
DIMENSIONS
STANDARD INSTALLATION
3
/
4
"
(
19)
TYPICAL
FRAMED
CABINETRY
41
1
/
2
"
(1054)
FILLER
3
1
/
2
"
(89)
FINISHED
RETURN
FRAMELESS
CABINETRY
41
1
/
2
"
(1054)
3
/
4
"
(
19)
TYPICAL
3
1
/
2
"
(89)
FINISHED
RETURN
NOTE:
3
1
/
2
"
(89)
finished returns will be visible and should be finished to match cabinetry
.
Shaded line represents profile of unit.
8
3
3
/
4
"
(2127)
OPENING
HEIGHT
24"
(610)
OPENING
DEPTH
FRONT VIEW
SIDE VIEW
TOP VIEW
41
1
/
2
"
(1054)
OPENING WIDTH
Specifications are subject to change without notice. This information was generated on December 8, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.
