Instruction Manual and Installation Instructions
Washer dryer
WNA14400TH
Loading ...
Loading ...
Loading ...
1
2
3
4
5
6
>
Summary of Contents for Bosch WNA14400TH:
en Instruction Manual and Installation Instructions
1
Washer dryer
1
Your new washer dryer
2
Display rules
2
: Warning!
2
Caution!
2
Note/tip
2
1. 2. 3. / a) b) c)
2
Contentsen Instruction Manual and Installation Instructions
3
8 Intended use 4
3
( Safety instructions 5
3
7 Environmental protection 12
3
5 Positioning and connecting 13
3
* Getting to know the appliance 22
3
Z Laundry 26
3
/ Overview of programmes 28
3
0 Changing programme default settings 33
3
\ Selecting additional functions 34
3
1 Operating the appliance 35
3
Q Appliance settings 40
3
H Sensors 40
3
2 Cleaning and maintenance 41
3
3 Faults and what to do about them 44
4
4 After-sales service 49
4
[ Consumption values 50
4
J Technical data 51
4
r Aqua-Stop warranty 51
4
8 Intended use
4
Intended use
4
( Safety instructions
5
Safety instructions
5
Children/people/pets
5
: Warning
5
Risk of death!
5
: Warning
5
Risk of death!
5
: Warning
5
Risk of suffocation!
5
: Warning
6
Risk of poisoning!
6
: Warning
6
Eye/skin irritation!
6
Installation
6
: Warning
6
Risk of electric shock/fire/ material damage/damage to the appliance!
6
: Warning
6
Risk of electric shock/fire/ material damage/damage to the appliance!
6
: Warning
7
Risk of fire/material damage/ damage to the appliance!
7
: Warning
7
Risk of injury/material damage/damage to the appliance!
7
: Warning
7
Risk of injury!
7
Caution!
7
Material damage/damage to the appliance
7
Operation
8
: Warning
8
Risk of explosions/fire!
8
: Warning
8
Risk of explosions/fire!
8
: Warning
9
Risk of fire/material damage/ damage to the appliance!
9
: Warning
9
Risk of poisoning!
9
: Warning
9
Risk of injury!
9
: Warning
9
Risk of scalding!
9
: Warning
10
Eye/skin irritation!
10
Caution!
10
Material damage/damage to the appliance
10
Cleaning/Maintenance
10
: Warning
10
Risk of death!
10
: Warning
11
Risk of poisoning!
11
: Warning
11
Risk of electric shock/material damage/damage to the appliance!
11
: Warning
11
Risk of injury/material damage/damage to the appliance!
11
Caution!
11
Material damage/damage to the appliance
11
7 Environmental protection
12
Environmental protection
12
Packaging/used appliance
12
Tips on economical use
12
5 Positioning and connecting
13
Positioning and connecting
13
Standard accessories
13
Note:
13
– WAF13 for loosening the transport braces and
13
– WAF17 for aligning the appliance feet
13
Safety instructions
13
: Warning
13
Risk of injury!
13
Caution!
14
Damage to the appliance
14
Caution!
14
Water damage
14
Notes
14
Installation surface
14
Note:
14
Installation on a base or a wooden joist floor
14
Caution!
14
Damage to the appliance
14
Note:
14
Installing the appliance in a kitchenette
14
: Warning
14
Risk of death!
14
Notes
14
Removing the transport locks
14
Caution!
14
Damage to the appliance
14
Note:
15
1. Take the hoses out of the holders.
15
2. Unscrew and remove all four transport brace screws.
15
a) Remove the mains cable from the holders.
15
b) Remove the sleeves.
15
3. Fit the covers.
15
4. Lock the covers firmly in place by applying pressure to the snap-in hooks.
15
Removing the support struts
16
1. Unscrew and remove all screws in the vertical transport struts.
16
2. Remove the transport struts.
16
Hose and cable lengths
16
Note:
16
Water inlet
16
: Warning
16
Risk of death!
16
Notes
16
1. Connect the water supply hose to the water tap (¾" = 26.4 mm) and to the appliance:
17
– Model: Standard
17
– Model: AquaSecure
17
– Model: Aqua-Stop
17
Tip:
17
2. Open the water tap carefully, checking the leak tightness of the connection points. The screw connection is under mains water pressure.
17
Water outlet
17
: Warning
17
Risk of scalding!
17
Caution!
17
Water damage
17
Caution!
18
Damage to the appliance/fabrics
18
Note:
18
Note:
18
Alignment
18
1. Loosen the lock nuts using a wrench, by turning it in a clockwise direction.
18
2. Check the alignment of the appliance with a spirit level, and adjust it if necessary. Change the height by turning the appliance feet.
19
3. Tighten the lock nut against the housing.
19
Electrical connection
19
: Warning
19
Risk of death!
19
Notes
19
Before washing for the first time
19
Note:
19
1. Insert mains plug.
20
2. Turn the water tap on.
20
3. Close the door. Do not load any laundry.
20
4. Select the Drum Clean Û 90°C programme.
20
5. Open the detergent drawer.
20
6. Pour approx. 1 litre of water into dispenser II.
20
7. Add standard detergent to dispenser II according to manufacturer’s instructions for light soiling.
20
Note:
20
8. Close the detergent drawer.
20
9. Select Start/Pause A .
20
10. When the programme ends, turn the programme selector to Off.
20
Transportation
20
Preparatory work:
20
1. Turn off the water tap.
20
2. Reduce the water pressure in the supply hose. ~ Page 43
20
3. Drain any residual water. ~ Page 42
20
4. Disconnect the appliance from the mains.
20
5. Remove the hoses.
20
6. Empty the dispensers.
20
Caution!
20
Risk of damage to the appliance caused by detergent/fabric softener leaking from the dispensers
20
Installing the transport locks:
20
1. Remove the covers and keep them in a safe place.
20
Note:
20
2. Insert all four sleeves.
20
a) Clip the mains cable securely in the holders.
20
b) Insert and tighten the screws.
21
c) Clip the hoses securely in the holders.
21
Notes
21
* Getting to know the appliance
22
Getting to know the appliance
22
Appliance
22
Control panel
23
Display panel
24
Displays for the programme
24
Z Laundry
26
Laundry
26
Preparing laundry for washing
26
Protecting your laundry and appliance
26
Caution!
26
Damage to the appliance/textiles
26
Sorting laundry
26
Note:
26
– Light: No need to pretreat, adjust the Speed G setting if necessary.
26
– Normal
26
– Heavy: Load less laundry, need to pretreat or soak laundry firstly.
26
– Stains: Remove/pretreat stains while they are fresh. First dab with soapy water; do not rub. Then wash the items of laundry with the appropriate programme. Stubborn or dried-in stains can sometimes only be removed by washing several times.
26
Preparing laundry for drying
27
Note:
27
Notes
27
/ Overview of programmes
28
Overview of programmes
28
Selectable programme
28
Programme/Type of laundry
28
Options/Information
28
Note:
29
Note:
29
Notes
29
Note:
29
Note:
30
Note:
30
Note:
31
Note:
31
Drying table
32
Soaking
32
1. Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions.
32
2. Set the programme selector to Cottons i 60°C and select Start/ Pause A
32
3. After approximately 10 minutes select Start/Pause A to pause the programme.
32
4. After the required soaking time, reselect Start/Pause A if the programme is to be continued or change the programme.
32
Note:
32
0 Changing programme default settings
33
Changing programme default settings
33
Temp.°C 6
33
Spin 0
33
Ready In ñ
33
Note:
33
1. Touch the Start/Pause A button.
33
2. Touch the Ready In ñbutton and change the Finish in time.
33
3. Touch the Start/Pause A button.
33
Dry 5
33
Notes
34
1. Touch button Dry 5 and activate the function » (Cupboard dry) or · (Cupboard dry plus).
34
2. Do not exceed the maximum loads for drying.
34
3. Maximum spin speed for the washing programme will be selected automatically to obtain a good drying result.
34
\ Selecting additional functions
34
Selecting additional functions
34
Speed G
34
Note:
34
Eco F
34
Extra Rinse Ï
34
1 Operating the appliance
35
Operating the appliance
35
Preparing the appliance
35
Notes
35
1. Insert mains plug.
35
: Warning
35
Risk of death from electric shock!
35
2. Turn the water tap on.
35
3. Open the appliance door.
35
Select programme/switch on the appliance
35
Note:
35
Adjusting the selected programme
35
Note:
35
Notes
36
Notes
36
Placing laundry into the drum
36
Notes
36
Dosing and adding detergent and care products
37
Caution!
37
Damage to the appliance
37
1. Pull out the detergent drawer.
37
: Warning
37
Eye / skin irritation!
37
2. Pour in detergent and/or cleaning product.
37
Notes
37
Starting the programme
37
Note:
38
Childproof lock
38
Note:
38
Adding/removing laundry
38
Notes
38
Changing the programme
38
If you have started the wrong programme by mistake, you can change the programme as follows:
38
1. Touch the Start/Pause A button.
38
2. Select another programme.
38
3. And touch the Start/Pause A button again. The new programme starts from the beginning.
38
Note:
38
Interrupting or ending the programme
38
1. Touch Start/Pause A button.
38
2. To cool down laundry: select à Rinse.
38
3. Touch Start/Pause A button.
38
1. Touch Start/Pause A button.
39
2. Select 0 Spin.
39
3. Touch Start/Pause A button.
39
1. Select 5 Intensive Dry or ‰ Gentle Dry .
39
2. Touch Dry 5 button, and set drying time to 15 minutes.
39
3. Touch Start/Pause A button.
39
End of the programme
39
Notes
39
Removing laundry/switching off the appliance
39
1. Set programme selector to Off.
39
2. Open the door and remove the laundry.
39
3. Turn off the water tap.
39
Note:
39
Notes
39
Q Appliance settings
40
Appliance settings
40
Activate setting mode:
40
1. Set the programme selector to position 1. The appliance is switched on.
40
2. Touch and hold the Start/Pause A button and, at the same time, turn the programme selector clockwise to position 2. Release the Start/Pause A button.
40
Changing the volume
40
H Sensors
40
Sensors
40
Unbalanced load detection system
40
Note:
40
2 Cleaning and maintenance
41
Cleaning and maintenance
41
: Warning
41
Risk of death!
41
Caution!
41
Fire and explosion hazard!
41
Caution!
41
The appliance may be damaged!
41
Appliance housing/control panel
41
Drum
41
: Warning
41
Risk of injury/material damage/ damage to the appliance!
41
Descaling
41
Emptying the detergent draw, cleaning the detergent drawer and its housing
41
If the appliance contains detergent or fabric softener residues:
41
1. Pull out the detergent drawer. Press down the insert and fully remove the drawer.
41
2. To remove the insert: Push the insert upwards from below with your finger.
42
3. Clean the detergent dispenser tray and insert with water and a brush, and dry it. Clean the inside of the housing as well.
42
4. Fit the insert and lock it in place (push the cylinder onto the guide pin).
42
5. Push in the detergent drawer.
42
Note:
42
Drain pump is blocked
42
Note:
42
: Warning
42
Risk of scalding!
42
1. Turn the programme selector to Off. Pull out the mains plug.
42
2. Open the service flap.
42
3. Take the drain hose out of the retainer.
42
4. Carefully unscrew the pump cover; residual water may leak out.
43
5. Refit and screw on the pump cover. The handle must be in a vertical position.
43
6. Close the service flap.
43
Note:
43
The drain hose at the siphon is blocked
43
1. Turn the programme selector to Off. Pull out the mains plug.
43
2. Loosen the hose clamp. Carefully remove the drain hose; residual water may leak out.
43
3. Clean the drain hose and siphon connecting piece.
43
4. Re-attach the drain hose and secure the connection point using the hose clamp.
43
Filter in the water supply is blocked
43
1. Turn off the water tap.
43
2. Select any programme (except à Rinse and 0 Spin programmes).
43
3. Select the Start/Pause A button. Allow the programme to run for approx. 40 seconds.
43
4. Turn the programme selector to Off.
43
5. Pull out the mains plug.
43
1. Disconnect the hose from the rear of the appliance.
44
2. Use pliers to remove the filter.
44
3. Clean the filter with a small brush.
44
4. Connect the hose and check for leaks.
44
3 Faults and what to do about them
44
Faults and what to do about them
44
Emergency release
44
However, if the laundry has to be removed, the appliance door can be opened as follows:
44
: Warning
44
Risk of scalding!
44
: Warning
44
Risk of injury!
44
Caution!
44
Water damage!
44
1. Turn the programme selector to Off. Pull out the mains plug.
44
2. Open the service flap.
44
3. Drain the water. ~ Page 42
45
4. Pull the emergency release downwards with a tool and release.
45
Information on the display panel
45
Display
45
Cause/Remedy
45
Faults and what to do about them
46
Faults
46
Cause/Remedy
46
Note:
46
Note:
48
4 After-sales service
49
After-sales service
49
[ Consumption values
50
Consumption values
50
Energy and water consumption, programme duration and residual moisture for the main washing programmes (approximate values)
50
Programme
50
Rated capacity [kg]
50
Energy consumption [kWh/cycle]*
50
Water consumption [l/cycle]*
50
Program duration [h:min]*
50
J Technical data
51
Technical data
51
r Aqua-Stop warranty
51
Aqua-Stop warranty
51
In addition to warranty claims against the vendor based on the purchase agreement and to our appliance warranty, we will provide compensation under the following conditions:
51
1. If water damage is caused due to a fault in our Aqua-Stop system, we will compensate domestic customers for the damage caused.
51
2. The liability guarantee is valid for the service life of the appliance.
51
3. It is a prerequisite of all warranty claims that the appliance with Aqua- Stop must have been installed and connected correctly in accordance with our instructions; this also includes a correctly fitted Aqua-Stop extension (genuine accessories).
51
4. Appliances with Aqua-Stop do not need to be supervised during operation, nor secured afterwards by turning off the tap.
51
*9001588013*
52
Thank you for buying a Bosch Home Appliance!
52
Looking for help? You´ll find it here.
52
File type: PDF
File name: 53337263_wna14400th.pdf
File size: 2.45 MB
File Language: English
Pages: 52
Author: Bosch
File created: 2020-09-29
Published: 2023-09-08
Updated: 2023-09-08
Download File
Specifications
Brand:
Bosch
Model: WNA14400TH
View in the file:
Full Specifications
See other models:
SMS2HAI12E
BCH3P2300
BGS21WHYG
BGS7POW1
SKS51E32EU
Photos
Download User Manual
Bosch in United States
1-800-944-2904
Twitter
Website
Related Products
Bosch WNA14400EU
Bosch WNA14490GB
Bosch WNA14420NL
Bosch WNA13400EU
Bosch WNA13400NL
Bosch WNA144V9GB
Bosch WNA144V9NL
Bosch WNG24490
Bosch WNG24440
Bosch WNA13490
Bosch WNA13440
Bosch WNG24430NL
Bosch WNA13490NL
Bosch WNA134U8GB
Bosch WNA254U0TH
Table of Contents
×
en Instruction Manual and Installation Instructions
1
Washer dryer
1
Your new washer dryer
2
Display rules
2
: Warning!
2
Caution!
2
Note/tip
2
1. 2. 3. / a) b) c)
2
Contentsen Instruction Manual and Installation Instructions
3
8 Intended use 4
3
( Safety instructions 5
3
7 Environmental protection 12
3
5 Positioning and connecting 13
3
* Getting to know the appliance 22
3
Z Laundry 26
3
/ Overview of programmes 28
3
0 Changing programme default settings 33
3
\ Selecting additional functions 34
3
1 Operating the appliance 35
3
Q Appliance settings 40
3
H Sensors 40
3
2 Cleaning and maintenance 41
3
3 Faults and what to do about them 44
4
4 After-sales service 49
4
[ Consumption values 50
4
J Technical data 51
4
r Aqua-Stop warranty 51
4
8 Intended use
4
Intended use
4
( Safety instructions
5
Safety instructions
5
Children/people/pets
5
: Warning
5
Risk of death!
5
: Warning
5
Risk of death!
5
: Warning
5
Risk of suffocation!
5
: Warning
6
Risk of poisoning!
6
: Warning
6
Eye/skin irritation!
6
Installation
6
: Warning
6
Risk of electric shock/fire/ material damage/damage to the appliance!
6
: Warning
6
Risk of electric shock/fire/ material damage/damage to the appliance!
6
: Warning
7
Risk of fire/material damage/ damage to the appliance!
7
: Warning
7
Risk of injury/material damage/damage to the appliance!
7
: Warning
7
Risk of injury!
7
Caution!
7
Material damage/damage to the appliance
7
Operation
8
: Warning
8
Risk of explosions/fire!
8
: Warning
8
Risk of explosions/fire!
8
: Warning
9
Risk of fire/material damage/ damage to the appliance!
9
: Warning
9
Risk of poisoning!
9
: Warning
9
Risk of injury!
9
: Warning
9
Risk of scalding!
9
: Warning
10
Eye/skin irritation!
10
Caution!
10
Material damage/damage to the appliance
10
Cleaning/Maintenance
10
: Warning
10
Risk of death!
10
: Warning
11
Risk of poisoning!
11
: Warning
11
Risk of electric shock/material damage/damage to the appliance!
11
: Warning
11
Risk of injury/material damage/damage to the appliance!
11
Caution!
11
Material damage/damage to the appliance
11
7 Environmental protection
12
Environmental protection
12
Packaging/used appliance
12
Tips on economical use
12
5 Positioning and connecting
13
Positioning and connecting
13
Standard accessories
13
Note:
13
– WAF13 for loosening the transport braces and
13
– WAF17 for aligning the appliance feet
13
Safety instructions
13
: Warning
13
Risk of injury!
13
Caution!
14
Damage to the appliance
14
Caution!
14
Water damage
14
Notes
14
Installation surface
14
Note:
14
Installation on a base or a wooden joist floor
14
Caution!
14
Damage to the appliance
14
Note:
14
Installing the appliance in a kitchenette
14
: Warning
14
Risk of death!
14
Notes
14
Removing the transport locks
14
Caution!
14
Damage to the appliance
14
Note:
15
1. Take the hoses out of the holders.
15
2. Unscrew and remove all four transport brace screws.
15
a) Remove the mains cable from the holders.
15
b) Remove the sleeves.
15
3. Fit the covers.
15
4. Lock the covers firmly in place by applying pressure to the snap-in hooks.
15
Removing the support struts
16
1. Unscrew and remove all screws in the vertical transport struts.
16
2. Remove the transport struts.
16
Hose and cable lengths
16
Note:
16
Water inlet
16
: Warning
16
Risk of death!
16
Notes
16
1. Connect the water supply hose to the water tap (¾" = 26.4 mm) and to the appliance:
17
– Model: Standard
17
– Model: AquaSecure
17
– Model: Aqua-Stop
17
Tip:
17
2. Open the water tap carefully, checking the leak tightness of the connection points. The screw connection is under mains water pressure.
17
Water outlet
17
: Warning
17
Risk of scalding!
17
Caution!
17
Water damage
17
Caution!
18
Damage to the appliance/fabrics
18
Note:
18
Note:
18
Alignment
18
1. Loosen the lock nuts using a wrench, by turning it in a clockwise direction.
18
2. Check the alignment of the appliance with a spirit level, and adjust it if necessary. Change the height by turning the appliance feet.
19
3. Tighten the lock nut against the housing.
19
Electrical connection
19
: Warning
19
Risk of death!
19
Notes
19
Before washing for the first time
19
Note:
19
1. Insert mains plug.
20
2. Turn the water tap on.
20
3. Close the door. Do not load any laundry.
20
4. Select the Drum Clean Û 90°C programme.
20
5. Open the detergent drawer.
20
6. Pour approx. 1 litre of water into dispenser II.
20
7. Add standard detergent to dispenser II according to manufacturer’s instructions for light soiling.
20
Note:
20
8. Close the detergent drawer.
20
9. Select Start/Pause A .
20
10. When the programme ends, turn the programme selector to Off.
20
Transportation
20
Preparatory work:
20
1. Turn off the water tap.
20
2. Reduce the water pressure in the supply hose. ~ Page 43
20
3. Drain any residual water. ~ Page 42
20
4. Disconnect the appliance from the mains.
20
5. Remove the hoses.
20
6. Empty the dispensers.
20
Caution!
20
Risk of damage to the appliance caused by detergent/fabric softener leaking from the dispensers
20
Installing the transport locks:
20
1. Remove the covers and keep them in a safe place.
20
Note:
20
2. Insert all four sleeves.
20
a) Clip the mains cable securely in the holders.
20
b) Insert and tighten the screws.
21
c) Clip the hoses securely in the holders.
21
Notes
21
* Getting to know the appliance
22
Getting to know the appliance
22
Appliance
22
Control panel
23
Display panel
24
Displays for the programme
24
Z Laundry
26
Laundry
26
Preparing laundry for washing
26
Protecting your laundry and appliance
26
Caution!
26
Damage to the appliance/textiles
26
Sorting laundry
26
Note:
26
– Light: No need to pretreat, adjust the Speed G setting if necessary.
26
– Normal
26
– Heavy: Load less laundry, need to pretreat or soak laundry firstly.
26
– Stains: Remove/pretreat stains while they are fresh. First dab with soapy water; do not rub. Then wash the items of laundry with the appropriate programme. Stubborn or dried-in stains can sometimes only be removed by washing several times.
26
Preparing laundry for drying
27
Note:
27
Notes
27
/ Overview of programmes
28
Overview of programmes
28
Selectable programme
28
Programme/Type of laundry
28
Options/Information
28
Note:
29
Note:
29
Notes
29
Note:
29
Note:
30
Note:
30
Note:
31
Note:
31
Drying table
32
Soaking
32
1. Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions.
32
2. Set the programme selector to Cottons i 60°C and select Start/ Pause A
32
3. After approximately 10 minutes select Start/Pause A to pause the programme.
32
4. After the required soaking time, reselect Start/Pause A if the programme is to be continued or change the programme.
32
Note:
32
0 Changing programme default settings
33
Changing programme default settings
33
Temp.°C 6
33
Spin 0
33
Ready In ñ
33
Note:
33
1. Touch the Start/Pause A button.
33
2. Touch the Ready In ñbutton and change the Finish in time.
33
3. Touch the Start/Pause A button.
33
Dry 5
33
Notes
34
1. Touch button Dry 5 and activate the function » (Cupboard dry) or · (Cupboard dry plus).
34
2. Do not exceed the maximum loads for drying.
34
3. Maximum spin speed for the washing programme will be selected automatically to obtain a good drying result.
34
\ Selecting additional functions
34
Selecting additional functions
34
Speed G
34
Note:
34
Eco F
34
Extra Rinse Ï
34
1 Operating the appliance
35
Operating the appliance
35
Preparing the appliance
35
Notes
35
1. Insert mains plug.
35
: Warning
35
Risk of death from electric shock!
35
2. Turn the water tap on.
35
3. Open the appliance door.
35
Select programme/switch on the appliance
35
Note:
35
Adjusting the selected programme
35
Note:
35
Notes
36
Notes
36
Placing laundry into the drum
36
Notes
36
Dosing and adding detergent and care products
37
Caution!
37
Damage to the appliance
37
1. Pull out the detergent drawer.
37
: Warning
37
Eye / skin irritation!
37
2. Pour in detergent and/or cleaning product.
37
Notes
37
Starting the programme
37
Note:
38
Childproof lock
38
Note:
38
Adding/removing laundry
38
Notes
38
Changing the programme
38
If you have started the wrong programme by mistake, you can change the programme as follows:
38
1. Touch the Start/Pause A button.
38
2. Select another programme.
38
3. And touch the Start/Pause A button again. The new programme starts from the beginning.
38
Note:
38
Interrupting or ending the programme
38
1. Touch Start/Pause A button.
38
2. To cool down laundry: select à Rinse.
38
3. Touch Start/Pause A button.
38
1. Touch Start/Pause A button.
39
2. Select 0 Spin.
39
3. Touch Start/Pause A button.
39
1. Select 5 Intensive Dry or ‰ Gentle Dry .
39
2. Touch Dry 5 button, and set drying time to 15 minutes.
39
3. Touch Start/Pause A button.
39
End of the programme
39
Notes
39
Removing laundry/switching off the appliance
39
1. Set programme selector to Off.
39
2. Open the door and remove the laundry.
39
3. Turn off the water tap.
39
Note:
39
Notes
39
Q Appliance settings
40
Appliance settings
40
Activate setting mode:
40
1. Set the programme selector to position 1. The appliance is switched on.
40
2. Touch and hold the Start/Pause A button and, at the same time, turn the programme selector clockwise to position 2. Release the Start/Pause A button.
40
Changing the volume
40
H Sensors
40
Sensors
40
Unbalanced load detection system
40
Note:
40
2 Cleaning and maintenance
41
Cleaning and maintenance
41
: Warning
41
Risk of death!
41
Caution!
41
Fire and explosion hazard!
41
Caution!
41
The appliance may be damaged!
41
Appliance housing/control panel
41
Drum
41
: Warning
41
Risk of injury/material damage/ damage to the appliance!
41
Descaling
41
Emptying the detergent draw, cleaning the detergent drawer and its housing
41
If the appliance contains detergent or fabric softener residues:
41
1. Pull out the detergent drawer. Press down the insert and fully remove the drawer.
41
2. To remove the insert: Push the insert upwards from below with your finger.
42
3. Clean the detergent dispenser tray and insert with water and a brush, and dry it. Clean the inside of the housing as well.
42
4. Fit the insert and lock it in place (push the cylinder onto the guide pin).
42
5. Push in the detergent drawer.
42
Note:
42
Drain pump is blocked
42
Note:
42
: Warning
42
Risk of scalding!
42
1. Turn the programme selector to Off. Pull out the mains plug.
42
2. Open the service flap.
42
3. Take the drain hose out of the retainer.
42
4. Carefully unscrew the pump cover; residual water may leak out.
43
5. Refit and screw on the pump cover. The handle must be in a vertical position.
43
6. Close the service flap.
43
Note:
43
The drain hose at the siphon is blocked
43
1. Turn the programme selector to Off. Pull out the mains plug.
43
2. Loosen the hose clamp. Carefully remove the drain hose; residual water may leak out.
43
3. Clean the drain hose and siphon connecting piece.
43
4. Re-attach the drain hose and secure the connection point using the hose clamp.
43
Filter in the water supply is blocked
43
1. Turn off the water tap.
43
2. Select any programme (except à Rinse and 0 Spin programmes).
43
3. Select the Start/Pause A button. Allow the programme to run for approx. 40 seconds.
43
4. Turn the programme selector to Off.
43
5. Pull out the mains plug.
43
1. Disconnect the hose from the rear of the appliance.
44
2. Use pliers to remove the filter.
44
3. Clean the filter with a small brush.
44
4. Connect the hose and check for leaks.
44
3 Faults and what to do about them
44
Faults and what to do about them
44
Emergency release
44
However, if the laundry has to be removed, the appliance door can be opened as follows:
44
: Warning
44
Risk of scalding!
44
: Warning
44
Risk of injury!
44
Caution!
44
Water damage!
44
1. Turn the programme selector to Off. Pull out the mains plug.
44
2. Open the service flap.
44
3. Drain the water. ~ Page 42
45
4. Pull the emergency release downwards with a tool and release.
45
Information on the display panel
45
Display
45
Cause/Remedy
45
Faults and what to do about them
46
Faults
46
Cause/Remedy
46
Note:
46
Note:
48
4 After-sales service
49
After-sales service
49
[ Consumption values
50
Consumption values
50
Energy and water consumption, programme duration and residual moisture for the main washing programmes (approximate values)
50
Programme
50
Rated capacity [kg]
50
Energy consumption [kWh/cycle]*
50
Water consumption [l/cycle]*
50
Program duration [h:min]*
50
J Technical data
51
Technical data
51
r Aqua-Stop warranty
51
Aqua-Stop warranty
51
In addition to warranty claims against the vendor based on the purchase agreement and to our appliance warranty, we will provide compensation under the following conditions:
51
1. If water damage is caused due to a fault in our Aqua-Stop system, we will compensate domestic customers for the damage caused.
51
2. The liability guarantee is valid for the service life of the appliance.
51
3. It is a prerequisite of all warranty claims that the appliance with Aqua- Stop must have been installed and connected correctly in accordance with our instructions; this also includes a correctly fitted Aqua-Stop extension (genuine accessories).
51
4. Appliances with Aqua-Stop do not need to be supervised during operation, nor secured afterwards by turning off the tap.
51
*9001588013*
52
Thank you for buying a Bosch Home Appliance!
52
Looking for help? You´ll find it here.
52
Search:
×
Search
