Table of Contents
1. Important Safety Instructions 2
2. Overview 2
3. Feature Identification 3
4. Enclosure Installation 4
4.1 Preparation 4
4.2 Unpacking 4
4.3 Ground Connection 4
5. Enclosure Configuration 5
5.1 Door Locks 5
5.2 Cable Access & Management 5
5.3 Reversing the Enclosure 5
5.4 Mounting Rails 6
5.5 Adjusting Mounting Rail Depth 6
6. Wall Mounting the Enclosure 6
7. Equipment Installation 7
7.1 Installing or Removing Cage Nuts 7
7.2 Alternate Mounting: 7
Tapped Hole Mounting Rail
7.3 Horizontal Rack-Mount Installation 8
7.4 Vertical Rack-Mount Installation 8
7.5 Cable Routing 8
8. Storage and Service 9
9. Warranty and Product Registration 9
Español 10
Français 19
28
Non-Swinging Wall-Mounted
SmartRack
®
Enclosure
Models: SRW9UDPVRT, SRW9UDPGVRT
(Series Number: AG-00E9)
Owner’s Manual
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2018 Tripp Lite. All trademarks are the sole property of their respective owners.
