GAS PROPANE FORGE
Furnace Burner
12/18/2020
Specification
●
ATM: Gas pressure from gas pressure regulator (in Atmospheres). 1ATM - 1.01Bar - 14.5PSI
PSI: Gas pressure from gas pressure regulator (in Pounds per square inch). 1PSI - 0.06ATM - 0.068Bar
BTU/Hr: British thermal unit per hour. 1 BTU/hr = 0.00029307107 kW
LBS/Hr: Pounds per hour. 1 lbs = 0.45359237 kilograms
Kg/Hr: Kilogram per hour. 1 kilogram = 2.20462262 lbs
KW/Hr: Kilowatt per hour. 1 kW/Hr = 3412.142 BTU/Hr
BTU为英制锻造炉的功率（1Kw每小时=3412.142BTU）
● DFP Burner
PSI
ATM
BTU/H
lbs/h
KW/h
Kg/h
1
0.07
16,299
0.75
4.78
0.34
2
0.14
23,051
1.07
6.76
0.48
3
0.20
28,231
1.31
8.27
0.59
4
0.27
32,599
1.51
9.55
0.68
5
0.34
36,446
1.69
10.68
0.77
6
0.41
39,925
1.85
11.70
0.84
7
0.48
43,124
2.00
12.64
0.91
8
0.54
46,102
2.14
13.51
0.97
9
0.61
48,898
2.26
14.33
1.03
10
0.68
51,543
2.39
15.11
1.08
15
1.02
63,127
2.92
18.50
1.33
20
1.36
72,893
3.38
21.36
1.53
25
1.70
81,497
3.77
23.88
1.71
30
2.04
89,275
4.13
26.16
1.88
35
2.38
96,428
4.47
28.26
2.03
40
2.72
103,086
4.77
30.21
2.17
DFP Burner
Regulator
Regulator
● Gas regulator with POL CGA-510 connection included for: UNITED STATES, CANADA,
SWEDEN, NORWAY, AUSTRALIA, NEW ZEALAND, ISRAEL, MEXICO, INDONESIA,
THAILAND
● · Gas regulator with G 5/8" UK POL LH connection included for: UNITED KINGDOM,
SOUTH AFRICA
● · Our standard gas pressure regulator with connection - Shell DIN external thread
to - W21.8 x 1/14" LH internal thread (Left thread) included for all other countries not
mentioned above. (Fits to GERMANY, AUSTRIA, FRANCE, NETHERLANDS, SPAIN,
BELGIUM, SLOVENIA, FINLAND, POLAND, LATVIA, RUSSIA and other countries)
DFS-1
● DFS – 1 burner forge
DFSW-1
Specification DFSW:
Burner: DFP 1pcs. ;
Forge Body Constructed of: steel 21 gauge (0.8mm), the shell is lightweight;
Interior Dimensions : 6"Width x 4.8"Height x 10"Length (150mm x 120mm x 250mm);
(Height with brick: 3.2" - 80mm);
Weight: 10lb (5kg).
Interior of the forge is fully covered with a 30mm ceramic blanket. The floor is made of
firebrick, providing superior strength and durability.
Connection kit included with every forge:
Gas pressure regulator, gauge with manometer;
7.8 ft (3m) gas hose
2 clamps.
DFSW-2
Specification DFSW2:
Burner: DFP 2pcs. ;
Forge Body Constructed of: steel 21 gauge (0.8mm), the shell is lightweight;
Interior Dimensions: 6"Width x 4.8"Height x 16"Length (150mm x 120mm x 400mm);
(Height with brick: 3,2" - 80mm);
Weight: 16lb (7kg).
Interior of the forge is fully covered with a 1-inch ceramic blanket. The floor is made of
firebricks, providing superior strength and durability.
Connection kit included with every forge:
Gas pressure regulator, gauge with manometer;
7.8 ft (3m) gas hose;
2 clamps.
All you need to supply is the propane tank.
Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF-1
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF-1+1D
● The manometer advantages: You can adjust exact gas pressur
DFPROF-1+2D
● Specification DFPROF1 + 2D:
● Burner: DFP 1pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 4.8"Width x 4.8"Height x 10"Length (120mm x 120mm x
250mm);
● Weight: 15lb (7kg).
● Interior of the forge is fully covered with a ceramic blanket. The floor is
made of firebrick, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● 6.5 ft (2m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF-2
DFPROF-2+1D
● Specification DFPROF2 + 1D:
● Burner: DFP 2pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 5.6"Width x 5.6"Height x 16"Length (140mm x 140mm x 400mm);
● Weight: 27lb (12kg).
● Interior of the forge is fully covered with a ceramic blanket. The floor is made of
firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● 2 clamps.
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF-2+2D
DFPROF-3
● Specification DFPROF3:
● Burner: DFP 3pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 5.8"Width x 5.8"Height x 24"Length (145mm x 145mm x
600mm);
● Weight: 32lb (15kg).
● Interior of the forge is fully covered with a 1-inch ceramic blanket. The floor is
made of firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF-3-1D
● Specification DFPROF3 + 1D:
● Burner: DFP 3pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 5.8"Width x 5.8"Height x 24"Length (145mm x 145mm x
600mm);
● Weight: 32lb (15kg).
● Interior of the forge is fully covered with a ceramic blanket. The floor is
made of firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF-3-2D
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF-5
● Specification DFPROF5:
● Burner: DFP 5pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 5.8"Width x 5.8"Height x 50"Length (145mm x 145mm x
1250mm);
● Weight: 63lb (29kg).
● Interior of the forge is fully covered with a ceramic blanket. The floor is
made of firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFHS1+1D/2.8"
● Specification DFHS1 + 1D 2.8":
● Burner: DFP 1pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 7.2"Width x 2.8"Height x 10"Length (180mm x 70mm x 250mm);
● Weight: 19lb (8.8kg).
● Interior of the forge is fully covered with a 1-inch ceramic blanket. The floor is
made of firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFHS2+1D/5.2"
● Specification DFHS2 + 1D 5.2":
● Burner: DFP 2pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 9.2"Width x 5.2"Height x 14.2"Length (230mm x 130mm x 355mm);
● Weight: 31lb (14.1kg).
● Interior of the forge is fully covered with a ceramic blanket. The floor is made of
firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● O u r m a n o m e t e r w i t h M p a m e a s u r e m e n t . 0 . 1 M p a - 1 B a r - 1 4 . 5 P S I
DFHS2+2D/5.2"
● Specification DFHS2 + 2D 5.2":
● Burner: DFP 2pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 10.2"Width x 5.2"Height x 12.8"Length (255mm x 130mm x
320mm);
● Weight: 32lb (14.5kg).
● Interior of the forge is fully covered with a ceramic blanket. The floor is
made of firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
DFPROF1+1D/2"
● Specification DFPROF1 + 1D 2":
● Burner: DFP 1pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 6"Width x 4.4"Height x 10"Length (150mm x 110mm x 250mm);
● Weight: 27lb (12kg).
● Interior of the forge is fully covered with a 2-inch ceramic blanket. The floor is
made of firebrick, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF2+1D/2"
● Specification DFPROF2 + 1D 2":
● Burner: DFP 2pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 6"Width x 4.4"Height x 16"Length (150mm x 110mm x 400mm);
● Weight: 35lb (16kg).
● Interior of the forge is fully covered with a 2-inch ceramic blanket. The floor is
made of firebrick, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFPROF3+1D/2"
● Specification DFPROF3 + 1D 2":
● Burner: DFP 3pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 6"Width x 4.4"Height x 24"Length (150mm x 110mm x 600mm);
● Weight: 46lb (21kg).
● Interior of the forge is fully covered with a 2-inch ceramic blanket. The floor is
made of firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
DFC Burner
PSI
ATM
BTU/H
lbs/h
KW/h
Kg/h
1
0,07
36674
1,70
10,75
0,77
2
0,14
51864
2,40
15,20
1,09
3
0,20
6352
2,94
18,62
1,33
4
0,27
73347
3,40
21,50
1,54
5
0,34
82005
3,80
24,03
1,72
6
0,41
89832
4,16
26,33
1,89
7
0,48
97029
4,49
28,44
2,04
8
0,54
103728
4,80
30,40
2,18
9
0,61
110021
5,10
32,24
2,31
10
0,68
115972
5,37
33,99
2,44
15
1,02
142036
6,58
41,63
2,98
20
1,36
164009
7,60
48,07
3,45
25
1,70
183368
8,49
53,74
3,85
30
2,04
200869
9,30
58,87
4,22
35
2,38
216964
10,05
63,59
4,56
40
2,72
231944
10,74
67,98
4,87
DFC Burner
DFPROFK2+2D
● Specification DFPROFK2:
● Burner: DFC 2pcs. ;
● Forge Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight;
● Interior Dimensions: 9.2"Width x 4"Height x 16"Length (230mm x 100mm x 400mm);
● Weight: 62lb (28kg).
● Interior of the forge is fully covered with a 2-inch ceramic blanket. The floor and
both sides are made of firebricks, providing superior strength and durability.
● Connection kit included with every forge:
● Gas pressure regulator, gauge with manometer;
● (3m) gas hose;
● All you need to supply is the propane tank.
● Our manometer with Mpa measurement. 0.1Mpa - 1Bar - 14.5PSI
