Point the sensor to the
object (radiation source).
General Description
The tester can be used to measure the magnitude of electromagnetic field radiation generated by power line, computer monitor, TV set,
video/audio machine, microwave oven, or many other similar devices.
Specification
Measurement Range: 0.1 ~ 199.9mG( milligauss )
Accuracy: ± (10% of reading + 8 digits ), at 50Hz/60Hz
Frequency Response: 30Hz ~ 400Hz
Battery: 9V, 6F22 or equivalent, 1 piece
Overrange Indication: only figure " 1 " shown on the display
Sampling Rate: about 2.5 times/sec
Operation Environment: 0°C ~ 40°C(32°F ~ 104°F), < 80%RH
Storage Environment: -10°C ~ 60°C(14°F ~ 140°F), < 70%RH
Size: 146×70×33mm
Weight: about 166g (including battery)
Structure Instruction
Display
Power Switch
Sensor ( located at the
top center of the tester)
Operation Instruction
1. Turn on the tester. Place the tester at desired position or near the object
to be tested, point the sensor to this device.
Note: The nearer the sensor approaches the device, the higher the
electromagnetic field radiation level may be.
2. Change the angle between the tester and the device under test until the
max. reading is obtained. This max. reading is the measurement result,
reading's unit is milligauss (mG). Turn off the tester.
Note:
Due to the disturbance of the electromagnetic field in the environment, the
tester may show a reading on the display before you perform measurement.
Do not expose yourself to electromagnetic field radiation for a long time.
V090506
1. The contents of this Instruction Sheet are subject to change without notice.
2. Our company will not take the other responsibilities for any loss.
3. The contents of this Instruction Sheet can not be used as the reason to use the tester for any special application.
EMF Tester
When the display shows the symbol " ", the battery is low and should be replaced immediately.
To replace battery, remove the screw on the battery cover, slide out the cover, replace the exhausted battery with a new one of same type
(6F22 or equivalent). Reinstall the battery cover and the screw.
Battery Replacement
Disposal of this Article
Dear Customer
If you at some point intend to dispose of this article, then please keep in mind that many of its components consist of
valuable materials, which can be recycled.
Please do not discharge it in the garbage bin, but check with your local council for recycling facilities in your area.
