- 1 -
M965906 (5/18)
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018
Thank you for selecting American-Standard...
the benchmark of fine quality for over 140 years.
To ensure that your installation proceeds smoothly-please read
these instructions carefully before you begin.
RECOMMENDED TOOLS
ROUGHING-IN DIMENSIONS
n To assure proper positioning in relation to wall,
note roughing-in dimensions.
Flash
™
Shower
Valve Rough
INSTALLATION
INSTRUCTIONS
RU101, RU102
RU107, RU108
RU109, RU107E
RU108E
Tubing Cutter Adjustable Wrench Channel Locks
Flat Blade Screwdriver
Plumbers' Putty or Caulking
Phillips Screwdriver
1/2" NPT
FINISHED WALL
BOTTOM OF TUB
OPTIONAL TO
FINISHED
FLOOR USUALLY
BETWEEN
65'' AND 78''
TOP OF
TUB RIM
4"
(102 mm)
1/2" NPT
7/8" TO 2"
(22 TO 50 mm)
NOTE: TO AVOID SHOWER RISE OR
OTHER RELATED ISSUES, DO NOT
USE PEX CONNECTIONS ON ANY OF
THE OUTLETS.
RU102
RU101
OUTLETS
1/2" STUB OUT
92 mm
(3-5/8")
113 mm
(4-7/16")
INLETS
1/2" STUB OUT
120 mm
(4-3/4")
142 mm
(5-5/8")
OUTLETS
1/2" NOM.
COPPER SWEAT
OR 1/2" NPT
INLETS
1/2" NOM.
COPPER SWEAT
OR 1/2" NPT
RU108
RU107
*RU107E
92 mm
(3-5/8")
156 mm
(6-1/8")
RU109
92 mm
(3-5/8")
162 mm
(6-3/8")
OUTLETS
1/2" NOM.
COPPER SWEAT
or 1/2" NPT
OUTLETS
1/2" NOM.
COPPER SWEAT
or 1/2" NPT
92 mm
(3-5/8")
120 mm
(4-3/4")
INLETS
1/2" PEX
(ASTM F1960)
INLETS
1/2" PEX
(ASTM F1807-2)
OUTLETS
1/2" NOM.
COPPER SWEAT
or 1/2" NPT
INLETS
1/2" NOM.
CPVC
92 mm
(3-5/8")
120 mm
(4-3/4")
OUTLETS
1/2" NOM.
COPPER SWEAT
or 1/2" NPT
INLETS
1/2" PEX
(ASTM F1807-2)
*RU108E
92 mm
(3-5/8")
156 mm
(6-1/8")
101 mm
(4")
89 mm
(3-1/2")
OUTLETS
1/2" NOM.
COPPER SWEAT
or 1/2" NPT
INLETS
1/2" PEX
(ASTM F1960)
PLASTER
GUARD
2-3/4" MAX. (69 mm)
1-3/4" MIN. (45 mm)
* NOTE: Inlet elbows on RU107E
and RU108E allows for 180
degree rotation.
