User manual
Register your product and get support at:
www.philips.com/support
Sleep Headphones
with Kokoon
TAN7808
1 Important safety instructions 2
Hearing safety 2
General information 2
2 Your sleep headphones 4
What's in the box 4
Other devices 4
Overview of your sleep headphones 5
3 Get started 6
Charge the battery 6
How to wear 6
App download 7
4 Use your headphones 9
Connect to your Bluetooth device 9
Manage your calls and music 9
Headphones LED indicator status 10
9 Frequently asked questions 17
Contents
5 Reset the headphones 11
6 Technical data 12
7 Notice 13
Declaration of conformity 13
Disposal of your old product
and battery 13
Remove the integrated battery 13
Compliance with EMF 14
Environmental information 14
Notice of compliance 14
8 Trademarks 16
1 Important
safety
instructions
Hearing safety
Be sure to observe the following
guidelines when using your headphones.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can't hear what's around
you.
• You should use caution or
temporarily discontinue use in
potentially hazardous situations.
• Excessive sound pressure from
headphones and headphones can
cause hearing loss.
• Using headphones with both ears
covered while driving is not
recommended and may be illegal in
some areas.
• For your safety, avoid distractions
from music or phone calls while in
environments.
• Do not wear any jewellery in or
around the ear that may interfere
with the device.
General information
To avoid damage or malfunction:
Danger
To avoid hearing damage, limit the time you
use headphones at high volume and set the
volume to a safe level. The louder the volume,
the shorter the safe listening time is.
Caution
Do not expose headphones to excessive heat.
Do not drop your headphones.
Headphones shall not be exposed to spraying
water or splashing.
Do not allow your headphones to be
submerged in water.
Do not charge your headphones when the
connector or socket is wet.
Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
Use a clean, damp cloth to clean your
headphones - especially the sound conduits and
the microphone holes - regularly and avoid
buildup of substances such as sweat or earwax.
If any sweat or water droplets are left in the
sound conduits, air holes or microphone holes,
the sound level will temporarily drop or cut out
entirely. This is not a malfunction. Use a soft,
damp cloth to dry the headphones thoroughly.
Alternatively, remove the earbud tips, turn the
sound conduits downward and gently tap the
similar to remove any water collected inside.
Be sure the headphones are completely dry
before charging and using. Avoid using
disposable alcohol pads or other substances for
cleaning.
The integrated battery shall not be exposed to
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
mechanically crushing or cutting a battery, can
result in an explosion.
Leaving a battery in an extremely high
temperature surrounding environment can
result in an explosion or the leakage of
A battery subjected to extremely low air
pressure may result in an explosion or the
Replacement of a battery with an incorrect type
risks severely damaging the headphones and
the battery (for example, in the case of some
lithium battery types).
If the headset is not used for a long time, the
rechargeable battery will begin to lose its
charge. To avoid this loss, please fully charge
the battery at least once every three months.
2 EN
Operating and storage temperatures and
humidity
• Store in a place where the
temperature is between -20°C (-4°F)
and 35°C (95°F) with up to 85%
relative humidity.
• Operate in a place where the
temperature is between 5°C (41°F)
and 45°C (113°F) with up to 85%
relative humidity.
• Battery life may be shorter in high or
low temperature conditions.
3 EN
only by external power source which output
capacity is less than 15W.
4 EN
2 Your sleep
headphones
What's in the box
Congratulations on your purchase, and
your product at www.philips.com/support.
With these Philips sleep headphones, you
can:
• Have the best sleep experience
• Enjoy convenient wireless
handsfree calls
• Enjoy and control music wirelessly
• Switch between calls and music
Other devices
A mobile phone or device (e.g. notebook,
tablet, Bluetooth adapters, MP3 players
etc) which supports Bluetooth and is
compatible with the headphones.
Philips sleep headphones TAN7808
Earbud sleeves x 10
Quick start guide
Carrying case
Warranty
USB-C charging cable
L1
L2
L3
L4
L5
R1
R2
R3
R4
R5
Warranty Information
www.philips.com/welcome
Welcome card
5 EN
Overview of your sleep
headphones
Multi-function button (MFB)
Volume - / skip backward
Volume + / skip forward
Bio-sensor
LED indicator
USB-C charging slot
2
3
5
4
1
6
1
2
3
4
5
6
6 EN
3 Get started
Charge the battery
Plug one end of the USB-C cable into the
control unit and the other end into the
power source.
Before you use your headphones, charge the
battery for 2 hours for optimum battery
capacity and lifetime.
Use only the original USB-C charging cable to
avoid any damage.
Finish your call before charging.
Note
1
Put the control unit at the back of
your neck.
2
Hook the cable on the ears.
Insert the earpieces
How to wear
Select suitable earbud sleeve for
optimum �t
Test which earbud sleeve provides
you with the best sound and
wearing comfort.
5 sizes of silicone earbud sleeves are
provided.
1
2
?
L1
L2
L3
L4
L5
R1
R2
?
R3
R4
R5
Don't overstretch the cable.
Note
7 EN
Pair the headphones with
your Bluetooth device for
the �rst time
3
Insert the earpieces into the ears
achieved.
4
blue.
The headphones are now in
pairing mode and ready to pair
with a Bluetooth device.
(e.g. a mobile phone)
1
2
Make sure that the headphones are
Press MFB for ~5 seconds to power
on, it will be in pairing mode and
ready to connect.
Scan the QR code/press 'Download the
Kokoon App'. Our headphones and the
Kokoon app work together to deliver the
best sleep experience.
App download
Turn on the Bluetooth function of
your Bluetooth device.
Pair the headphones with your
Bluetooth device, refer to the user
manual of your Bluetooth device.
3
4
8 EN
The following example shows you
how to pair the headphones with
your Bluetooth device.
Turn on the Bluetooth function of
your Bluetooth device, select
Philips TAN7808.
Enter the headphones' password
“0000” (4 zeros) if prompted. For
those devices featuring Bluetooth
3.0 or higher, there is no need to
enter a password.
1
2
Philips TAN7808
9 EN
The headphones will search the
last connected Bluetooth device
and reconnect to it automatically.
If the last connected one is not
available, the headphones will
search and reconnect to the
second last connected device.
4 Use your
headphones
Connect the headphones
to your Bluetooth device
1
2
Turn on the Bluetooth function of
your Bluetooth device.
Turn on the headphones.
Task
Turn the
headphones
on
Press and
hold for ~2
seconds
Press and
hold for ~2
seconds
Turn the
headphones
Power on/off
Button
MFB
MFB
Operation
Manage your calls and
music
Music control
MFB
+
-
Play or pause
music
Next track Press twice
Previous
track
Press twice
Adjust
volume +/-
Press once
Task Button Operation
Call control
Pick up/
Switch caller
during a call
Hang up call/
Reject call
MFB Press and
hold for
1 second
MFB Press once
Task
Button
Operation
Press once+/-
10 EN
Indicator
Headphones LED
indicator status
Headphones status
The headphones
are turned on
The headphones are
ready for pairing
The headphones
are connected
Battery is charging
LED single blue
pulse
LED single white
pulse
Battery is fully
charged
LED green single
pulse
5 Reset the
headphones
If you encounter any pairing or connection
issue, you can hold the MBF and “-” button
headphones to factory default settings.
11 EN
05"
12 EN
6 Technical data
Music play time: more than 10 hours
Charging time: 2 hours
Lithium-ion battery 110 mAh
Bluetooth version: 5.0
• A2DP (Advanced Audio
• AVRCP (Audio Video Remote
Supported audio codecs: SBC
Frequency range: 2.402-2.480 GHz
Transmitter power: < 10 dBm
Operation frequency: 110-205,000Hz
(62.8 dBuV/m)
Operating range: Up to 10 meters
(33 feet)
USB-C port for charging
Water resistant : IPX2
notice.
Note
13 EN
7 Notice
Hereby, MMD Hong Kong Holding Limited
declares that the product is in compliance
with the essential requirements and other
relevant provisions of RED Directive
2014/53/EU and UK Radio Equipment
the Declaration of Conformity on
www.philips.com/support.
Declaration of conformity
Disposal of your old
product and battery
Your product is designed and
manufactured with high quality materials
and components which can be recycled
and reused.
This symbol on a product means that the
product is covered by European Directive
2012/19/EU.
This symbol means that the product
contains a built-in rechargeable battery
covered by European Directive
2013/56/EU which cannot be disposed of
with normal household waste. We
strongly advise you to take your product
service centre to have a professional
remove the rechargeable battery.
Inform yourself about the local separate
collection system for electrical and
electronic products and rechargeable
batteries. Follow local rules and never
dispose of the product and rechargeable
batteries with normal household waste.
Correct disposal of old products and
rechargeable batteries helps prevent
negative consequences for the
environment and human health.
Remove the integrated
battery
If there is no collection/recycling system
for electronic products in your country,
you can protect the environment by
removing and recycling the battery
before disposing of the headphones.
• Make sure the headphones are
disconnected before removing the
battery.
14 EN
Compliance with EMF
This product complies with all
applicable standards and regulations
regarding exposure to electromagnetic
Environmental information
All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
protective foam sheet.)
Your system consists of materials which
can be recycled and reused if
disassembled by a specialized company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Notice of compliance
The device complies with the FCC rules,
Part 15. Operation is subject to the
following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause
undesired operation.
FCC rules
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed
to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and,
if not installed and used in accordance
with the instruction manual, may cause
harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
user is encouraged to try to correct the
interference by one or more of the
following measures:
Reorient or relocate the receiving
antenna
Increase the separation between
equipment and receiver
Connect the equipment into an outlet
the receiver is connected
Consult the dealer or an experienced
radio/TV technician for help
FCC Radiation Exposure Statement:
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located or
operated in conjunction with any other
antenna or transmitter.
Canada:
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s license-exempt
RSS(s). Operation is subject to the
following two conditions: (1) This device
may not cause interference. (2) This
device must accept any interference,
including interference that may cause
undesired operation of the device.
Caution:
The user is cautioned that
approved by the party responsible for
compliance could void the user's authority
to operate the equipment.
15 EN
IC Radiation Exposure Statement:
This equipment complies with Canada
radiation exposure limits set forth for
uncontrolled environments.
This transmitter must not be co-located
or operated in conjunction with any
other antenna or transmitter.
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts
de licence.
L’exploitation est autorisée aux deux
conditions suivantes :
(1) L’appareil ne doit pas produire de
brouillage;
(2) L’appareil doit accepter tout
brouillage radioélectrique subi, même si
le brouillage est susceptible d’en
compromettre le fonctionnement.
CAN ICES-003(B)/NMB-003(B)
16 EN
8 Trademarks
The Bluetooth® word mark and logos are
registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by MMD Hong Kong Holding
Limited is under license. Other
trademarks and trade names are those of
their respective owners.
Bluetooth
Siri is a trademark of Apple Inc., registered
in the U.S. and other countries.
Siri
Google and Google Play are trademarks
of Google LLC.
Google
17 EN
9 Frequently
asked
questions
My Bluetooth headphones cannot turn
on.
The battery level is low. Charge the
headphones.
I cannot pair my Bluetooth headphones
with my Bluetooth device.
The Bluetooth is disabled. Enable the
Bluetooth feature on your Bluetooth
device and turn on the Bluetooth device
before you turn on the headphones.
Pairing does not work.
• Make sure you have disabled the
Bluetooth function of any previously
connected Bluetooth devices.
• On your Bluetooth device, delete
“Philips TAN7808” from the Bluetooth
list.
• Pair your headphones (see ‘Pair the
headphones with your Bluetooth
The Bluetooth device cannot �nd the
headphones.
• The headphones may be connected
to a
the connected device or move it out
of range.
• Pairing may have been reset or the
headphones have been previously
paired with another device. Pair the
headphones with the Bluetooth
device again as described in the user
manual. (see ‘Pair the headphones
with your Bluetooth device for the
My Bluetooth headphones are connected
to a Bluetooth stereo-enabled mobile
phone, but music only plays on the
mobile phone speaker.
Refer to the user manual of your mobile
phone. Select to listen to music through
the headphones.
The audio quality is poor and a crackling
noise can be heard.
• The Bluetooth device is out of range.
Reduce the distance between your
headphones and Bluetooth device, or
remove obstacles between them.
• Charge your headphones.
The audio quality is poor when streaming
from a mobile phone is very slow or
streaming does not work at all.
Make sure your mobile phone not only
supports (mono) HFP but also supports
A2DP and is BT4.0x (or higher) compatible
(see ‘Technical data’ on page 12).
Clean your headphones regularly.
• Use a clean, damp cloth to clean your
headphones - especially the sound
conduits and the microphone holes -
regularly and avoid buildup of
substances such as sweat or earwax.
• If any sweat or water droplets are left
in the sound conduits, air holes or
microphone holes, the sound level will
temporarily drop or cut out entirely.
This is not a malfunction. Use a soft,
damp cloth to dry the headphones
thoroughly. Alternatively, remove the
earbud tips, turn the sound conduits
downward and gently tap the
cloth or similar to remove any water
collected inside.
• Be sure the headphones are
completely dry before charging and
using. Avoid using disposable alcohol
pads or other substances for cleaning.
18 EN
Charge your headphones regularly.
If the headset is not used for a long time,
the rechargeable battery will begin to
lose its charge. To avoid this loss, please
fully charge the battery at least once
every three months.
UM_TAN7808_00_EN_V2.0
2023 © MMD Hong Kong Holding Limited. All rights reserved.
Philips and the Philips Shield Emblem are registered trademarks
of Koninklijke Philips N.V. and are used under license. This product
has been manufactured by and is sold under the responsibility
MMD Hong Kong Holding Limited is the warrantor in relation to this
product. All other company and product names may be trademarks
of its respective companies with which they are associated.
