Single Handle Pull-out Bathroom Faucet
Tools:
PLUMBERS PUTTY FLASHLIGHT BASIN WRENCH
SAFETY GLASSES SCREWDRIVER
PLIERSCHANNELLOCKS ADJUSTABLE WRENCH
HEX-KEY TAPE
Helpful Information
Valencia
2022-03-10 MAAN4366-5
SEALED-TUBE
Please keep the tools for future use!
Gather the necessary tools as shown below to complete the installation of
this faucet. Some may not be needed depending on the model of faucet you
are installing. Check with your local hardware store on the requirements of
your installation situation.
WARNING:
For easy installation, you will need:
- To read all the installation instructions completely before beginning.
- To read all the warning, attention and maintenance information.
- To purchase the proper supply lines.
Connect to water supply lines with either
A 3 8 O D copper tubing ball nose
risers with the coupling nuts or
B 3 8 copper tubing no ball with
supplied tube head interior connector or
C IPS faucet connectors 1 2
C
A . B .
C .
Important
Tighten connection with two wrench to prevent damage to
tube body.
Be careful not to bend the stem as this will void the
product warranty
• STANDARDS
ASME A112.18.1-2012
CSA B125.1-12
NSF 61-9
LISTED IAPMO/cUPC
• 1.2 gpm/4.5 L/min
