WHAT’S
IN THE
BOX
quick
start
guide
POWER ON AND
AUTOMATICALLY ENTER PAIRING MODE
Choose
"JBL TUNE510BT"
to connect
Choose
"JBL TUNE510BT"
to connect
ON
Settings Bluetooth
Bluetooth
DEVICES
JBL TUNE510BT
Now Discoverable
Connected
Manual pairing mode
POWER OFF
>
5S
Manual
Pairing
ON
Settings Bluetooth
Bluetooth
DEVICES
Now Discoverable
Connected
JBL TUNE510BT
ENTER PAIRING MODE WITH THE 2
nd
DEVICE
(Maximum 2 devices)
*
Multi-point
connection
>
2S
1
To switch music source, pause the
music on the current device and select
play on the 2
nd
device.
2
Phone call will always take priority.
3
If one device goes out of bluetooth range
or powers off, you may need to manually
reconnect the remaining device.
4
SELECT “forget this device” on your
bluetooth devices to disconnect
multi-point.
1
st
bluetooth device
2
nd
bluetooth device
Choose "JBL TUNE510BT" to connect
ON
Settings Bluetooth
Bluetooth
DEVICES
Now Discoverable
Connected
JBL TUNE510BT
×22
×1
Siri
®
/
Google Assistant /
Bixby
×1×1
>
2
S
>
2S
×1
>
2S
TECH
SPEC
Model: TUNE 510BT
Driver Size: 32 mm / 1.26 " Dynamic driver
Power supply: 5 V 1 A
Weight: 160 g / 0.35 lbs
Headset battery type: Lithium-ion battery (3.7V / 450 mAh)
Charging time: 2 hrs
Music playtime with BT on: up to 40 hrs
Frequency response: 20 Hz – 20 kHz
Impedance: 32 ohm
Sensitivity: 103.5 dB SPL@ 1kHz 1mW
Maximum SPL: 95 dB
Microphone sensitivity: -29 dBV@1kHz/Pa
Bluetooth version: 5.0
Bluetooth profile version: A2DP v1.3, AVRCP v1.6, HFP v1.7
Bluetooth transmitter frequency range: 2.4 GHz – 2.4835 GHz
Bluetooth transmitted power: <8 dBm
Bluetooth transmitted modulation: GFSK, π/4DQPSK,8DPSK
Maximum operation temperature: 45 °C
power
on &
connect
BUTTON COMMAND
>
2S
>
2S2S
Charging
2HR
2HR5MIN
Low battery
CHARGING
FULLY CHARGED
led
behaviors
BT CONNECTING
BT connected
POWER ON/OFF
