DIRECTIONS:
1. Attach the supports to the legs.
2. Assemble the cross bar on the leg and upright supports.
3. Tighten all the screws
4. Stick the rubber feet on the legs. There are two for each leg;
they go on the front and back of each leg
5. Then you can mount your equipment on this rack stand
with the screws and washers supplied. You can either place
it on a table or the ground
19” RACK STAND
QUICK USER GUIDE
MODEL: PLRNSTND10
Thank you for choosing this 19” rack stand.
IN THE BOX:
(2) Uprights supports
(2) Leg tubes
(2) Cross bars
(8) Screws
(may already be in tubes, in which case, you’ll need to remove them for assembly)
(4) Transparent rubber feet
* Additional screws and washers needed for mounting
Upright
Support
Leg
Tube
Cross
Bar
SPECIFICATIONS:
Construction Material: Steel
Maximum Weight Load Capacity: 110 lbs.
Assembled Dimensions (L x W x H):
19.3’’ x 14.0’’ x 21.7’’
