Rechargeable Air Circulator Owner's Manual
Model:
FC-150B
(115V 60HZ)
Read and save these instructions
www.xpower.com | 1-(855)-855-8868 | info@xpower.com
Index: NA-1-A35
Edition: 1.4.Final
English - 2
Safety Instructions
!
WARNING - READ AND SAVE THIS INSTRUCTIONS BEFORE USING THIS PRODUCT.
The user of electrical products may create hazards that include, but are not limited to
injury, fire, electrical shock. Failure to follow these instructions may damage and/or
impair its operation and void the warranty.
• Before operating, remove all packaging material and check for any damage that may
have occurred during shipping or any missing items.
• Check household power supply to ensure it matches the appliance’s specification.
• DO NOT operate any fan with a damaged cord or plug. Discard fan or return it to an
authorized service facility for examination and/or repair.
• Use only on GFCI protected receptacles. Please contact a qualified electrician for
verification and / or installation of a GFCI receptacle if necessary.
• DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or
similar coverings. DO NOT route cord under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
• To reduce the risk of fire or electric shock, DO NOT use this fan with any solid-state
speed control device.
• DO NOT touch this appliance or the plug with wet hands or while standing in water.
• DO NOT operate the appliance in any pooled water.
• DO NOT use the product in areas where gasoline, paint or other flammable goods and
objects are used or stored.
• DO NOT insert or allow objects to enter any ventilation or exhaust opening as this may
damage the appliance and void the warranty.
• DO NOT cover the air inlet or outlet on the appliance.
• DO NOT direct the air flow at human faces or bodies.
• DO NOT allow children to play with this appliance.
• AUTOMATICALLY OPERATED DEVICE – To reduce the risk of injury, disconnect from
power supply before servicing.
• Remove the power cord from the electrical receptacle by grasping and pulling on the
power cord plug-end only, DO NOT pull the cord directly.
• DO NOT attempt to repair or adjust any electrical or mechanical functions of this
appliance, as this may cause danger and void the warranty.
• If the appliance is damaged or it malfunctions, DO NOT continue to use it. Unplug the
product from the electrical outlet. Refer to troubleshooting guide or contact XPOWER.
• Store in a dry area, away from exposure to sunlight, extreme temperature and humidity,
or other extreme environments, when not in use.
• DO NOT disassemble the battery. If the machine or battery malfunctions, refer to the
Troubleshooting Guide.
• DO NOT stack more than six units of this appliance.
• CAUTION: To reduce the risk of electric shock, connect only to an outlet provided with
a ground fault circuit interrupting device.
English - 3
Items Included
Axial Fan Owner's Manual
XXX Manual De Usuario (página 10)
XXX Mode d'emploi (page 18)
Model / Modelo / Modèle:
P-80 Series, P-100 Series, P-200 Series
(115V 60HZ)
Read and save these instructions before use
Lea y guarde estas instrucciones antes de usar la unidad
Lire et conserver ces instructions avant utilisation
www.xpower.com | 1-(855)-8868 | [email protected]
Index: NA-1-A2
Edition: 1.0.Alpha
• Owner’s Manual x 1• Air Circulator x 1*
Parts Description
Speed Switch
Rack
Handle
Air Inlet
Grill
Rack
Handle
Air Outlet
Grill
Timer Switch
Battery
Case
Battery Indicator
Light
• An electronic instruction manual can be obtained through manufacturer’s website
www.xpower.com.
English - 4
Rechargeable Air Circulator Introduction
• XPOWER Rechargeable Air Circulators are
designed to offer efficient air circulation and
ventilation with its high and long-distance
focused airflow.
• It’s perfect for air circulation and ventilation in
janitorial/sanitation jobs, air condition control
and more.
Installation and Operation Guide
Switch Plate
OFF
MAX
LOW
Variable Speed Switch
• Turn to “OFF” position to switch the machine OFF. Turn
clockwise to any position between “MAX” and “LOW” to
switch the machine ON.
• You can adjust to any desired speed variably. “MAX” is
the highest speed and “LOW” is the lowest speed.
• Turn clockwise to set timer for minutes count down to an
automatic stop.
• The timer can be set for up to 180 minutes (3 hours).
• When the timer reaches “0” position, the unit stops
working. On “ON” position, it will work constantly.
Timer Switch
120
60
0
ON
180
• This light indicates the capacity of the battery.
Battery Indicator Light
English - 5
Installation and Operation Guide
(Continued)
Adjusting the Operation Position
• The Air Circulator features 360° Rotation. Tilt Air Circulator to desired angle and
screw on rack handles to secure the position.
• Connect the unit to the power source.
• When the battery is charging, all the bars of the battery indicator light will shine green.
• IMPORTANT: Please charge the battery fully to activate the battery before initial use.
• IMPORTANT: To avoid the battery working on low capacity condition and encountering
permanent damage, it’s recommended to charge the battery fully before each prior to
operation.
• The unit can work normally while charging.
Charging the Battery
English - 6
User Maintenance Instructions
Frequent maintenance is recommended on this appliance. Failure to follow the
maintenance instructions may cause failure of the appliance and void the warranty.
• When not in use, unplug and store the appliance in a dry and cool indoor place. Make
sure it’s out of reach of children.
• Before performing any maintenance or cleaning, always disconnect the Air Circulator
from its power source.
• Use a damp cloth to wipe the surface of the housing. Do not clean the unit with water
directly.
• Check if the grille covers are clean. Remove dirt or any other objects that could block
the air inlet and air outlet.
Fasten the Rack Handles
• To prevent possible injury, when
you finish using this appliance,
please position the Air Circulator
UPRIGHT.
• Fasten the rack handle to lock the
position of the Air Circulator.
Transportation
Lift with Handle
• Lift the Air Circulator with the handle on
the top.
English - 7
Organize the Power Cord
• Wrap the power cord around the housing.
• Clip the cord to the cord clip on the plug shown above.
User Maintenance Instructions
(Continued)
Stack Multiple Units
• Stack the Air Circulators on the sides. Align the air
inlets of both Air Circulators.
WARNING
• DO NOT stack more than six units of this appliance.
• Stacking function is not secure during
transportation.
!
English - 8
If troubleshooting does not resolve your problem, please contact XPOWER or other
parties authorized by XPOWER for further instructions.
PROBLEM POSSIBLE CAUSE SOLUTION
Air Circulator does
not start
No electricity. Check for power supply.
The power cord is not properly
plugged in.
Remove and reconnect the
power cord.
The timer switch is set to “0”
position.
Set the timer switch to “ON”
position.
Battery is not activated yet. Please charge the battery
until to activate the battery
before the first usage.
Low battery capacity. When the battery capacity
is 20% or lower, in order to
protect the battery, the preset
program will stop the machine
and prohibit the machine from
working again. (See Page 5:
Charge the Battery.)
Unit runs but the
speed or the sound
is abnormal
Air inlet or air outlet is blocked. Remove blockage.
Low battery capacity. When the battery capacity
is 20% or lower, in order to
protect the battery, the preset
program will stop the machine
and prohibit the machine from
working again. (See Page 5:
Charge the Battery.)
Troubleshooting Guide
English - 9
Technical Specication
MODEL NUMBER
FC-150B
AC Rating 115 V~
,
60 Hz / 0.6 A
Battery Output DC 26 V / 1.0 A
Output Power 26 W
Rated Airflow 1000 CFM
Speed Control Variable
Timer 3 Hours (OFF)
Battery Specification
Lithium Ion Battery
67 W·h
Run Duration ≈ 3 - 50 Hours
Recharge Duration ≈ 3 Hours
Cord Length 6 ft. / 1.8 m
Housing PP
Unit Dimension
(L) x (W) x (H)
16.1 x 8.9 x 14.2 in. / 41.0 x 22.5 x 36.0 cm
Unit Weight 9.9 lbs. / 4.5 kg
If your product(s) is not listed above, please visit www.xpower.com for more information.
English - 10
XPOWER Limited Warranty (USA)
1 YEAR LIMITED WARRANTY
XPOWER-branded products purchased in the U.S. from authorized distributors include
a 1-year limited warranty. Contact XPOWER to confirm warranty information about your
product(s).
This limited warranty covers defects in materials and workmanship in your XPOWER-
branded products, purchased in the U.S. ONLY. Local warranty policy (if any) in your
country will cover products purchased outside the U.S.
Items mentioned but not limited to below are not covered by warranty:
(1) Power cord, filters or any other components considered as a “consumable parts” by
XPOWER.
(2) Normal wear and tear.
(3) Problems that result, directly or indirectly, at XPOWER’s sole discretion, from:
(3.1) External causes such as accident, abuse, misuse or problems with electrical power
supply.
(3.2) Disassembling, servicing or modification not authorized by XPOWER.
(3.3) Usage that is not accordant with product instructions stated in Owner’s Manual.
(3.4) Failure to follow the product instructions or lack of necessary maintenance stated
in Owner’s Manual.
Before contacting XPOWER, please try one or more of the following:
(1) Consult this Owner’s Manual and follow the instructions of troubleshooting guide.
(2) Access www.xpower.com for more advice and information that could be helpful to
address your problems.
If you need additional assistance from XPOWER, please:
(1) Email info@xpower.com.
(2) Call XPOWER U.S. Customer Service Department at 855-855-8868 or other numbers
provided on www.xpower.com.
(3) Visit XPOWER U.S. Head Office at 668 S. 6th Ave., City of Industry, CA 91746 or the
most current address provided on www.xpower.com.
Please also have your original proof of purchase and the serial number(s) of your
product(s) ready when you contact XPOWER.
IMPORTANT:
(1) Please finish the online warranty registration before usage. Visit https://xpower.
com/warranty-registration/
(2) This Limited Warranty applies with its own timeliness. Contact XPOWER or visit
www.xpower.com for more information.
!
English - 11
If you are instructed to return the unit for service or replacement, please:
(1) Request a RMA (Return-Merchandise-Authorization) number.
(2) Use the original or an equivalent packaging, prepay shipping charges at your own
expense to the address provided by XPOWER, with the RMA number on the shipping
label or the packaging.
(3) Include all the original parts and components.
XPOWER will inspect, assess and advise the repairs needed and applicable cost, if any.
For products under warranty, we will pay to ship the repaired or replaced product(s) to
you if you use an address within the Contiguous United States. Otherwise, we will ship
the product(s) to you at your own expense.
XPOWER Limited Warranty (USA)
Read and save these instructions
www.xpower.com | 1-(855)-855-8868 | info@xpower.com
668 S. 6th Ave.,
City of Industry, CA 91746 USA
Index: NA-1-A35
Edition: 1.4. Final
XPOWER Manufacture, INC.
