1
11 LITRE
2400W DUAL COMPARTMENT
AIR FRYER OVEN
USER MANUAL
MODEL: T17102
2
THIS BOX CONTAINS 3
SPECIFICATIONS 3
IMPORTANT SAFETY INFORMATION 4
• General safety 4
• Plug and cord 5
• Wiring safety 6
GETTING TO KNOW YOUR AIR FRYER OVEN 7
• Control panel and display 7
• Structure of your appliance 8
BEFORE FIRST USE 9
• Preparing for use 9
• Air fryer drawer safety switch 9
• Turning on the appliance 9
• Auto-off function 9
USING YOUR AIR FRYER OVEN 10
• Selecting a compartment 10
• Start/Pause function 10
• Pre-set menu selection 11
• Sync finish 12
• Setting the temperature/time 12-13
• Keep warm & reheat functions 13
WEIGHTS & MEASURES TABLE 14
SETTINGS TABLE 15
16
CLEANING AND CARE 17
TROUBLESHOOTING 18
DISPOSAL OF THE UNIT 19
CUSTOMER SUPPORT 19
RECIPES 20-24
TABLE OF CONTENTS
3
THIS BOX CONTAINS
SPECIFICATIONS
RATED VOLTAGE AC 220 - 240V~
FREQUENCY 50/60Hz
POWER CONSUMPTION 2200 - 2400W
CAPACITY 2 x 5.5L
TEMPERATURE RANGE 45°C - 200°C
TIME RANGE 1-60 minutes
H: 405 x W 318 : x D: 322 mm
WEIGHT 8.1Kg
Instruction manual
11L Air Fryer Oven
2 x Cooking Racks
2 x Cooking Basket
2 x Drip Trays
4
Please read these safety NOTES carefully
BEFORE using your Tower appliance.
These warnings have been provided in the
interest of safety. Basic safety precautions
should always be followed including the
following:
KEY SAFETY POINTS
CAUTION: During operation:
• Surfaces are hot. DO NOT press the hot
surfaces.
• Hot steam is released through the air
outlet openings. Keep your hands and
face at a safe distance from the steam
and from the air outlet openings.
• Hot steam and air may escape when the
appliance door is opened.
GENERAL SAFETY
• DO NOT immerse cords, plugs or any part
of the appliance in water or any other
liquid.
• Close supervision is necessary when any
appliance is used by or near children.
• Children should not play with the
appliance.
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
• Cleaning and user maintenance should
not be undertaken by children without
supervision.
• Take care when any appliance is used
near pets.
•
or removing accessories, after use and
before cleaning.
• Allow the appliance to cool down for
or removing accessories or cleaning.
• If the supply cord or appliance is
damaged, stop using the appliance
immediately and seek advice from the
manufacturer, its service agent or a
• The use of accessory attachments is
not recommended by the appliance
manufacturer, apart from those supplied
with this product.
• DO NOT use the appliance outdoors.
• DO NOT place the appliance on or near a
hot stove top or heated oven.
• Take care when moving the appliance, or
removing accessories and food as hot oil
or other hot liquids may be present.
• This appliance is for household use only.
It is important that this instruction
manual is retained for future
reference.
If the appliance is given to someone
else, it should always be accompanied
by these operating instructions, as
they form an integral part of the
appliance.
IMPORTANT SAFETY INFORMATION
5
• DO NOT place anything on top
of the appliance.
• DO NOT clean the appliance with
metal kitchen utensils, caustic
or abrasive cleaning agents or scouring
sponges.
• DO NOT use this appliance for anything
other than its intended use.
WHILST AIR FRYING
• Please ensure that the appliance is used
on a stable, level, and heat resistant
surface.
• DO NOT place the appliance
on or near combustible materials
such as a tablecloth or curtain.
• DO NOT place the appliance against
a wall or against other appliances.
Leave at least 10cm free space
on the back and sides and 10cm free
space above the appliance.
• DO NOT place the appliance in
the presence of explosive
• DO NOT cover the air inlet and outlet
during operation.
• Any accessories, baking trays or oven
dishes used in the appliance
will become hot. Always use oven gloves
when handling or removing anything
from the appliance.
• DO NOT place food that is still packed in
plastic wrap or plastic bags
in the appliance.
• DO NOT allow food to come into contact
with the heating element of
the appliance.
• If the appliance begins to emit smoke,
unplug it immediately.
Only open the door once the smoke has
cleared. Remove burnt remnants.
• DO NOT leave this appliance unattended
whilst operating.
PLUG AND CORD
• Check that the voltage of the main
circuit corresponds with the rating of the
appliance before operating.
• WARNING: DO NOT let the cord hang over
the edge of a table or counter, serious
burns may result from the air fryer being
pulled off the counter where it may
be grabbed by children or become
entangled with the user.
• DO NOT let the supply cord press
hot surfaces.
• DO NOT carry the appliance by the power
cord.
• DO NOT use any extension cord
with this appliance.
• The appliance is not intended to be
operated by means of an external timer
or separate remote-control system.
• DO NOT pull the plug out by the cord
as this may damage the plug and/or
the cable.
• DO NOT plug and unplug with
wet hands.
6
IMPORTANT: As the colours in the mains
lead of this appliance may not correspond
with the coloured markings identifying
the terminals in your plug, please proceed
as follows:
The wires in the mains lead are labelled
in accordance with the following code:
Blue neutral [N] Brown live [L] Green/
Yellow [EARTH]
PLUG FITTING DETAILS
(WHERE APPLICABLE)
• The wire labelled blue is the neutral
and must be connected to the terminal
marked [N].
• The wire labelled brown is the live wire
and must be connected to the terminal
marked [L].
• The wire labelled green/yellow must be
connected to the terminal marked with
the letter [E].
• On no account must either the brown
or the blue wire be connected to the
[EARTH] terminal.
• Always ensure that the cord grip is
fastened correctly.
•
conforming to BS 1362 and be ASTA
approved.
•
who will be pleased to do this for you.
NON-REWIREABLE MAINS PLUG
If your appliance is supplied with a
lead and should the fuse need replacing,
you must use an ASTA approved one
(conforming to BS 1362 of the same rating).
who will be pleased to do this for you.
If you need to remove the plug - disconnect
it from the mains - then cut it off of the
mains lead and immediately dispose of it
in a safe manner. Never attempt to reuse
the plug or insert it into a socket outlet as
there is a danger of an electric shock.
In the unlikely event the appliance develops a fault, stop using it immediately
and seek advice from the Customer Support Team. +44 (0) 333 220 6066
WARNING:
This appliance MUST be earthed!
FUSE
Earth
(G
reen/Yellow)
Fuse
Neutral
(Blue)
Live
(Bro
wn)
WIRING SAFETY FOR UK USE ONLY
7
GETTING TO KNOW YOUR AIR FRYER
CONTROL PANEL AND DISPLAY
1. Compartment A Selection Key
2. Dual Compartment Selection Key
3. Compartment B Selection Key
4. Compartment A LED Display
5. Compartment B LED Display
6. Time/Temperature +/- Keys
7. Time/Temperature Selection Key
8. Start/Stop Key
9. Keep Warm Function Key
10. Power On/Off Key
11. Sync Finish Function Key
12. Compartment Light On/Off Key
13. Pre-set Menu Selection Panel
14. Reheat Function Key
15. Defrost Function Key
1
10111213 1415
9
2 34 5 6 7
8
KEEP
WARM
SYNC
FINISH
START
STOP
A
B
A+B
REHEAT
Air outlet
STRUCTURE OF YOUR APPLIANCE
Air inlet
Compartment
1
Compartment 1
Viewing Window
Compartment 2
Viewing Window
LED
Screen
Cool Touch
Handle
Compartment
2
9
PREPARING FOR USE
1. Remove your appliance from the
packaging.
2. Check that there is no damage to the
cord or any visible damage to the body.
3. Check that all listed parts are present.
4. Remove any stickers or labels from the
appliance. DO NOT remove the rating
plate or any warnings.
5. Dispose of the packaging in a
responsible manner.
6. Locate the appliance on a stable,
horizontal, even and heat-resistant
surface in accordance with the
Important safety information section.
7. Thoroughly clean the drawer and grill
plate with hot water, some washing up
liquid and a non-abrasive sponge.
8. Wipe the inside and outside of the
appliance with a moist cloth.
9. DO NOT
frying fat or any other liquid. This is an
oil-free fryer that works on hot air.
10. Place the grill plate in the drawer.
11. DO NOT put anything on top of the
and the hot air frying will be affected as
a result.
AIR FRYER DRAWER
SAFETY SWITCH:
For your safety, this air fryer contains
a safety switch in the drawer designed
to keep if from accidentally turning on
when the frying basket and drawer are
not properly situated inside the appliance.
Before using the air fryer, please ensure
that the baskets are inside of the drawers,
the drawers are fully close.
TURNING THE APPLIANCE ON
1. Plug the unit into a mains socket. The
unit will emit an audible signal and the
before entering stand-by mode with
just the key illuminated.
2. Press the key to turn the appliance
on, this will illuminate the control panel.
3. Press the key to stop further
operation. The unit will emit an audible
signal and go into standby mode.
AUTO-OFF FUNCTION
1. When cooking is not in progress, the
appliance will automatically go into
Standby mode if there has been no
contact with the control panel for
10 minutes. The key will remain
all other indicators as well as the LED
display will go out to show the unit is in
Standby mode.
2. Press the key while the unit is in this
state to bring it out of Standby mode.
The indicators on the unit’s control
panel will light up to show the unit has
been taken out of Standby mode.
3. Once the unit is out of Standby mode,
press any of the compartment selection
keys to activate the control panel for
the corresponding compartment(s).
BEFORE FIRST USE
10
SELECTING A COMPARTMENT
1. Once the unit has been turned on,
press either the
A
,
B
or
A+B
keys on
the control panel to activate the left-
hand compartment, the right hand
compartment or both compartments
simultaneously, respectively. There will
be a sound prompt, the corresponding
display on the opposite side will go out
(if applicable) to show each mode has
been selected.
2. Press one of the other keys at any time
while the unit is in operation to activate
the other compartment. There will be
a sound prompt, the corresponding
LED display on the second
compartment will illuminate to show it
has been selected.
NOTE: When
A+B
mode is selected, pressing
one of the other two keys will cause the
opposite compartment to de-activate;
for instance, pressing the A key when this
mode is selected will de-activate the right-
hand side compartment, while pressing
the B key will de-active the compartment
on the left-hand side.
TURNING THE COMPARTMENT
LIGHTS ON/OFF
This unit is equipped with an internal light,
allowing for the cooking process to be
checked on at any time without the need
to open the corresponding compartment,
or for better visibility when a compartment
Is opened.
1. Press the Light key on the unit’s
control panel at any time to turn the
compartment lights on. There will be a
sound prompt and both compartment
lights will come on to show this
function has been selected.
2. Press the key again while the
compartment lights are on to
turn them off.
NOTE: The compartment lights cannot be
turned on or off separately. Pressing the
Light On/Off button always activates both
compartment lights at once, even if only
one of the compartments is in use.
NOTE: Once activated, the compartment
lights will remain on for a period of two
minutes, even when the unit is in Standby
mode; once this time has elapsed,
the lights will automatically turn
themselves off.
START/PAUSE
1. Once the appropriate function, time
and temperature have been set press
the Start/Stop key. The indicator for the
and the unit will begin to operate on
the selected settings. The LED display
will alternately show the selected
temperature and the remaining
cooking time for the duration of the
cooking cycle.
2. Press the Start/Stop key again while the
unit is in operation to pause the cooking
process. The unit’s fan will stop working
and all the indicators on the control
panel will illuminate to show the
cooking process has been interrupted.
3. Press the Start/Stop key again while
the unit is paused to resume the
cooking process. The unit’s fan will
start to operate again, and the unit
will continue to operate on the latest
selected settings.
USING YOUR AIR FRYER
11
9b. If the food is ready, empty the basket
into a bowl or onto a plate. Take care
when doing so, as excess oil from
cooking may leak onto the ingredients.
9c. When a batch of food is ready, the
appliance is instantly ready for
preparing another batch. However, if
the appliance is not required for further
cooking, turn it off and unplug it from
the mains socket. Leave the drawer(s)
open to allow the unit to cool down
more quickly.
NOTE: When cooking on the Fries/Chips
pre-set, there will be a sound prompt
halfway through. When this sounds, take
the cooking basket out of the air fryer oven,
shake the ingredients for a few seconds,
then place the basket back inside the
corresponding compartment and close the
door. The unit will automatically resume
cooking on the standard pre-set settings.
NOTE: Alternatively, refer to the diagram
printed at the top of the unit for
information on the default times and
temperatures for each pre-set.
MENU
DEFAULT
TIME (MIN)
DEFAULT
TEMP (ºC)
Fries/Chips 18 200
Toast 5 190
Cake 25 150
Vegetables 15 150
Dehydrate 20 hours 50
Reheat 3 180
Keep Warm 120 60
Chicken 30 180
Chicken Wings 18 175
Steak 12 160
Fish 15 170
Prawns 13 170
Defrost 15 45
PRE-SET MENU SELECTION
(Once plugged in and in stand-by)
1. Place the food in the compartments,
2. Press the key.
3. Press the
A
,
B
or
A+B
key to select
the desired compartments.
4. Press the corresponding icon for each
pre-set on the unit’s control panel
to activate it. There will be a sound
prompt, the icon for the selected
default time and temperature settings
for that program will be displayed on
the unit’s LED screen to indicate that
pre-set has been selected
5. If using both compartments to cook
separate pre-sets, press the icon for
the opposite compartment to the one
selected, and repeat steps 4 and 5.
6. Once the desired pre-set menus have
been set, press the Start/Stop key to
start the cooking process. The digits
on the unit’s control panel will stop
operate to show the cooking process is
under way.
NOTE! If there is no input on the control
selected, the cooking cycle for that pre-set
will begin automatically.
7. When the operation time has elapsed
there will be an audible signal, the
heating element will stop working and
the unit will go into Standby mode to
show the cooking cycle is complete.
8. Open the corresponding
compartment(s) and take out the
cooking racks or remove the food
directly.
9. Check if the food is ready.
9a. If the food is not ready yet, return the
drawer to the appliance and set the
timer for a few extra minutes, then
press the Start/Stop key.
12
THE SYNC FINISH FUNCTION
This unit is equipped with a Sync Finish
function, which allows for the cooking
programs on both compartments to be
time, preventing extended wait times
and ensuring the food remains as fresh as
possible when served.
To activate the Sync Finish function, carry
out the following steps.
1. Place the food in the compartment(s),
2. Press the key to turn the unit on.
3. Press the A key to select operation for
4. Select the desired pre-set from the
corresponding menu on the unit’s
control panel, or manually select and
set the required time and temperature,
as detailed in the corresponding
sections of this instruction manual.
5. Once the correct pre-set or time and
have been set, press the B key to select
operation for the second compartment.
6. Repeat step 4 for the second
compartment.
7. Once the correct pre-set or time
and temperature for the second
compartment have been set, press the
Sync Finish key on the unit’s control
panel. The indicators for the selected
pre-sets will remain illuminated and
go out, and the Sync Finish button will
activated.
8. Once the Sync Finish function has
been activated, press the Start/Stop
key to start the cooking cycles. The
unit will now carry out both programs
simultaneously, but delay the start of
the shorter program to ensure the two
MANUALLY SETTING THE
TEMPERATURE
The temperature control range is 45-200ºC.
1. Press the Time/Temperature key on the
unit’s control panel once to activate
the Temperature Selection function
on either or both compartments. The
corresponding indicator will illuminate
and the corresponding digits will
show this function has been selected.
If no selection is made, the air fryer
will automatically begin a 30-minute
cooking cycle at 180 degrees. Should
this be the case, the fan will begin to
work and all the pre-set indicators will
go out to show a cooking cycle has
started.
2. Once the Temperature function has
been activated, press the ^ and V keys
on the corresponding side of the air
fryer to adjust the temperature by
increments of 5, from 45 to 200 degrees
Celsius. Short press each key to adjust
this setting gradually or press and hold
to change the time more quickly.
3. If required, repeat this process for the
other compartment.
4. Once the correct temperature for each
compartment is set, press the Start/
Stop key to start the cooking process.
The unit will automatically begin to
operate at the latest selected settings.
NOTE: The temperature can be changed
during operation. To do this, press the
Time/Temperature key while a cooking
cycle is in progress, then follow the steps
outlined above. The unit will automatically
adjust to the new settings within a few
seconds.
13
MANUALLY SETTING THE TIMER
This unit is equipped with an adjustable
60-minute timer.
1. Press the Time/Temperature key again
when the Temperature function is
activated to activate the Timer function
on either or both compartments. The
corresponding indicator will illuminate
and the corresponding digits will begin
function has been selected.
2. Once the Temperature function has
been activated, press the ^ and V keys
on the corresponding side of the air
fryer to adjust the temperature by
increments of 5, from 45 to 200 degrees
Celsius. Short press each key to adjust
this setting gradually or press and hold
to change the time more quickly.
3. If required, repeat this process for the
other compartment.
4. Once the correct temperature for each
compartment is set, press the Start/
Stop key to start the cooking process.
The unit will automatically begin to
operate at the latest selected settings.
NOTE: The time can be changed during
operation. To do this, press the Time/
Temperature key while a cooking cycle is
in progress, then follow the steps outlined
above. The unit will automatically adjust to
the new settings within a few seconds.
KEEP WARM & REHEAT
FUNCTIONS
This unit is equipped with Keep Warm and
Reheat functions, accessible at the press of
a button from the press control panel.
1. To activate either of these functions,
press the corresponding key on
the unit’s press control panel. The
corresponding indicator will begin to
selected.
2. Once the desired mode has been
selected, press the Start/Stop key to
start the cooking cycle. The unit will
automatically begin to work at the
default pre-set time and temperature
for that function.
NOTE: If required, the time and
temperature for the Reheat function
can be adjusted manually at any time, as
detailed in the corresponding sections of
this instruction manual. However, for the
Keep Warm function, only the cooking
time can be adjusted; the temperature for
TIPS
1. To remove large or fragile ingredients,
pull the ingredients out of the
compartment with a pair of tongs.
2. The cooking time will depend on the
size of your ingredients. Smaller sizes
may require a shorter cooking time.
3. A larger quantity of ingredients requires
a slightly longer preparation time than a
smaller quantity of ingredients.
4. Shaking smaller ingredients halfway
during the cooking time optimises
the end result and can help prevent
unevenly fried ingredients.
5.
recommended that potatoes be
parboiled before frying.
6. The optimal amount for preparing
crispy fries is 500 grams.
14
WEIGHTS AND MEASURES
Check these charts for basic imperial
to metric conversions of weights.
METRIC IMPERIAL US CUPS
250ml 1 cup
180ml 3/4 cup
150ml 2/3 cup
120ml 1/2 cup
75ml 1/3 cup
60ml 1/4 cup
30ml 1/8 cup
15ml 1 tablespoon
IMPERIAL Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
16 oz 425g
1 lb oz 450g
FOOD ALLERGIES
IMPORTANT: Some of the recipes
contained in this document may contain
nuts and/or other allergens. Please be
careful when making any of our sample
recipes that you ARE NOT allergic to any of
the ingredients. For more information on
allergies, please visit the Food Standards
Agency’s website at: www.food.gov.uk
SETTINGS
The table on the next page will help you
select the basic settings for a variety of
common ingredients.
NOTE: Besides the pre-set menu, the
appliance can be used to make other foods
by setting the time and temperature. This
settings table will help you to select the
basic settings for the ingredients.
NOTE: Keep in mind that these settings are
indications. As ingredients differ in origin,
size, shape and brand the best settings for
the ingredients cannot be guaranteed.
NOTE: Because the Rapid Air technology
instantly reheats the air inside the
appliance instantly, removing the
during hot air frying barely disturbs the
process.
NOTE: Add 3 minutes to the preparation
time before you start frying if the appliance
is cold.
15
Time
(mins)
Temp
(°C)
Extra information Shake
POTATO & FRIES
Thin Frozen Fries 12-16 200 Yes
Thick Frozen Fries 12-20 200 Yes
Home-made fries (8x8mm) 18-25 180 Add ½ tbsp of oil Yes
Home-made Potato Wedges) 18-22 180 Add ½ tbsp of oil Yes
Home-made Potato Cubes 12-18 200 Add ½ tbsp of oil Yes
Rösti 15-18 180
Potato Gratin 18-22 180
MEAT & POULTRY
Steak 8-12 180
Pork Chops 10-14 180
Hamburger 7-14 180
Sausage Roll 13-15 200
Drumsticks 18-22 180
Chicken Breast 10-15 180
SNACKS
Spring Rolls 8-10 200 Use Oven Ready Yes
Frozen Chicken Nuggets 6-10 200 Use Oven Ready Yes
Frozen Fish Fingers 6-10 200 Use Oven Ready
Frozen Bread Crumbed
Cheese Snacks
10 200 Use Oven Ready
Stuffed Vegetables 10 160 Use Oven Ready
SETTINGS
16
Spare part replacements and accessories are available to purchase via:
+44 (0) 333 220 6066
www.towerhousewares.co.uk
PART NO DESCRIPTION IMAGE
T17102001 Air Flow Basket
T17102002 Air Flow Rack
T17102003 Drip Tray
ACCESSORIES/SPARE PARTS
17
WARNING! Do not immerse the appliance
in water or any other liquid.
NOTE: Clean the appliance after every use.
CLEANING THE DRAWER
AND COOKING PLATES:
1. DO NOT use metal kitchen utensils or
abrasive cleaning materials to clean
them, as this may damage
the non-stick coating.
2. Remove the mains plug from the wall
socket and let the appliance cool down
before cleaning.
NOTE: Remove the drawers to let the
air fryer cool down more quickly.
3. Wipe the outside of the appliance with
a moist cloth.
4. Clean the drawers and grill plates with
hot water, some washing-up liquid and
a non-abrasive sponge.
CLEANING AND CARE
5. You can use degreasing liquid to
remove any remaining dirt.
NOTE: The drawers are NOT dishwasher
proof. NEVER place the drawer or
basket in the dishwasher. TIP: If dirt is
stuck to the basket or the bottom of the
with some washing-up liquid, and let
the drawer soak for approximately
10 minutes.
6. Clean the inside of the appliance with
hot water and a non-abrasive sponge.
7. Clean the heating element with a
cleaning brush to remove any food
residues.
STORAGE
• Ensure that the air fryer is cool, clean
and dry before you store it.
• Store the appliance in a cool and dry
place.
18
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
The air fryer
does not work.
The appliance is not plugged in.
Plug the appliance into an
earthed wall socket.
The START/PAUSE key has not
been pressed.
Press the START/PAUSE key.
The compartments are open
and the selected function is
paused.
Close the compartments to
automatically resume the
selected function.
The cooking
racks will not
slide inside the
unit properly.
There is too much food in the
racks.
The racks are not correctly
placed inside the unit correctly.
Ensure the racks are correctly
the compartment.
Fried snacks
are not crispy
when they
come out of
the fryer.
Wrong type of snacks used.
Use oven snacks or lightly brush
some oil onto the snacks for a
crispier result.
Food stuck together or not in an
even layer.
Shake or turn the food
periodically through the cooking
process.
The fried
ingredients are
not done.
Too much food has been added
to the air fryer.
Put smaller batches of
ingredients in the air fryer.
Smaller batches are fried more
evenly.
The set temperature is too low.
Set to an appropriate
temperature.
The cooking time is too short. Set an appropriate cooking time.
Fresh fries are
fried unevenly
in the air fryer.
Wrong type of potatoes used.
Use fresh potatoes and make
The potato sticks were not
rinsed adequately before frying
Rinse the potato sticks properly
to remove the starch from the
outside.
Fresh fries
are not crispy
when they
come out of
the air fryer.
The crispiness of the fries
depends on the amount of oil
and water in them.
Make sure you dry the potato
sticks properly before you add
the oil.
Cut the potato sticks smaller for a
crispier result.
Add slightly more oil for a crispier
result.
TROUBLESHOOTING
19
Appliances bearing the symbol shown
here may not be disposed of in domestic
rubbish. You are required to dispose of old
electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk
or www.recyclenow.co.uk for access
to information about the recycling of
electrical items.
Please visit www.weeeireland.ie for access
to information about the recycling of
electrical items purchased in Ireland.
If you have any questions or concerns about your new product,
please contact our helpful Customer Support Team:
+44 (0) 333 220 6066
www.towerhousewares.co.uk
Please have your Model No. available. This can be found on the front
cover of this instruction manual and on the appliance’s rating label.
The WEEE directive, introduced in August
2006, states that all electrical items must
Please arrange to take this appliance to
your local Civic Amenity site for recycling,
once it has reached the end of its life.
DISPOSAL OF THE UNIT
CUSTOMER SUPPORT
20
INGREDIENTS
2 large potatoes
such as Maris Piper
Salt and black pepper
METHOD
1. Peel the potatoes and cut into 1 cm thick
chips.
2. Place the chips into a pan and cover with
cold water, bring to the boil then simmer
for 10 minutes. Drain in a colander then
rinse under the tap to cool completely and
pat dry on kitchen paper.
3. Place the potatoes in a bowl and drizzle
over the oil, then season with salt and
black pepper.
4. Remove the fries from the bowl leaving
behind any excess oil.
5. Place the fries into the air fryer
and then cook according to the times
and temperatures shown in the Settings
table above.
15 MINS 20 MINS
HOMEMADE FRIES
FAMILY SIZE
SERVES
4
21
INGREDIENTS
1 free range egg
1 strip of bacon
Cheese of your
choosing
Salt and black pepper
METHOD
1. Crack the egg into a small ramekin or oven
proof dish.
cheese on one half.
ramekin) into the corresponding drawer.
4. Turn on the Air Fryer and set it to 200ºC for
6 minutes.
5. Once it’s cooked, assemble your breakfast
BACON AND EGG BREAKFAST MUFFIN
10 MINS 20 MINS
FAMILY SIZE
SERVES
4
22
HONEY LIME CHICKEN WINGS
5 MINS 30 MINS
INGREDIENTS
12 chicken wings
2 tbsp soy sauce
2 tbsp honey
1 ½ tsp salt
¼ tsp white pepper
¼ tsp black pepper
2 tbsp fresh lime juice
METHOD
1. Place all the ingredients inside a large
mixing bowl or zip-locked sealing bag.
2. Mix them well and marinate in the
refrigerator for at least 4 hours (preferably
overnight.
3. Line a baking tray with baking paper and
evenly scatter the chicken wings across it.
4. Cook according to the times and
temperatures shown in the Settings table
above, turning halfway through.
FAMILY SIZE
SERVES
4
23
LEMON GARLIC SALMON
15 MINS 30 MINS
INGREDIENTS
4 tbsp butter
1 clove garlic, minced
1 tsp salt
1 tsp fresh dill, chopped
1 tbsp fresh parsley, chopped
Juice of 1 lemon
METHOD
1. Melt the butter and mix in the remaining
ingredients to create a butter sauce.
then place it on a baking tray
lined with baking paper.
3. Place the baking tray inside the air fryer
FAMILY SIZE
SERVES
4
24
MOLTEN CHOCOLATE LAVA CAKE
10 MINS 25 MINS
INGREDIENTS
100g dark chocolate chips
100g unsalted butter
2 eggs
2 ½ tbsp sugar
METHOD
1. Met the chocolate and butter, continuously
stirring to avoid burning the chocolate.
lightly and set the mixture aside.
3. In a separate mixing bowl, mix together
the eggs and sugar until light and frothy.
4. Add the chocolate mixture to the eggs and
sugar, slowly blending them together.
5. Pour the mixture into an oven-safe cup or
ramekin and place it inside the air fryer.
6. Use the Cake setting on the air fryer or turn
the air fryer on at 190ºC for 6 minutes.
7. Once baked serve immediately with ice-
cream.
FAMILY SIZE
SERVES
4
25
ADD YOUR OWN RECIPES HERE
INGREDIENTS : METHOD :
26
ADD YOUR OWN RECIPES HERE
INGREDIENTS : METHOD :
27
ADD YOUR OWN RECIPES HERE
INGREDIENTS : METHOD :
28
This product is guaranteed for 12 months
from the date of original purchase.
If any defect arises due to faulty
materials of workmanship, the faulty
products must be returned to the place
of purchase.
Refund or replacement is at the
discretion of the retailer.
THE FOLLOWING CONDITIONS APPLY:
The product must be returned to the
retailer with proof of purchase or a
receipt.
The product must be installed and used
in accordance with the instructions
contained in this instruction guide.
It must be used only for domestic
purposes.
It does not cover wear and tear, damage,
misuse or consumable parts.
Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and
Eire only.
The standard one year guarantee is only
extended to the maximum available
for each particular product upon
registration of the product within 28
days of purchase. If you do not register
the product with us within the 28 day
period, your product is guaranteed for
1 year only.
To validate your extended warranty,
please visit www.towerhousewares.
co.uk and register with us online.
Please note that length of extended
warranty offered is dependent on
product type and that each qualifying
product needs to be registered
individually in order to extend its
warranty past the standard 1 year.
Extended warranty is only valid with
proof of purchase or receipt.
Your warranty becomes void should you
decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
Or call our Customer Support Team on:
+44 (0) 333 220 6066
We hope you enjoy your appliance for many years...
YEAR
GUARANTEE
3
