Wall Mounting Patio Heater
SLOHT28
Remote Control Wall Patio Heater
with High Rated Aluminum Reflector and LED Indicator
Questions? Comments?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]
www.SereneLifeHome.com2
www.SereneLifeHome.com2 www.SereneLifeHome.com 3
PLEASE MAKE SURE THAT YOU HAVE READ THE MANUAL
CAREFULLY BEFORE USING IT.
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed
to reduce the risk of re, electric shock, and injury to persons, including the
following:
1. Read all instructions before using this heater.
2. Extreme caution is necessary when any heater is used by or near children or
invalids and whenever the heater is left operating and unattended.
3. Do not operate any heater after it malfunctions. Disconnect power at service
panel and have heater inspected by a reputable electrician before reusing.
4. Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or re, or damage the heater.
5. To prevent a possible re, do not block air intakes or exhaust in any manner.
6. A heater has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint, or ammable vapors or liquids are used or stored.
7. The unit must be placed with the clearance of 100cm to the wall and 30cm to
the ceiling.
8. This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. High temperature, keep combustible material such as furniture, papers,
clothes, curtains at least 3 feet (0.9m) from the front of the heater and away
from the side and rear.
9. The heater must be installed at least 2.1m above the oor.
10. The unit is at high temperature during operation. It keeps hot for a period
after shut down. Potential danger would occur when touching it during this
period.
11. Don't place the unit close to curtain and/or other ammable objects.
Otherwise there will be a danger of catching re.
12. Don’t cover the unit with anything during operation or a short time after it's
shut down.
13. Don't wrap the power supply cord on the unit.
14. The unit must be handled with care, and avoid of vibration or hitting.
15. The unit must be securely grounded during operation.
16. When damaged, the unit must be repaired by professional repairing team.
17. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
18. The heater must not be located immediately below a socket-outlet.
19. When assembling, keep clear from any board or ammable material.
20. Do not use this heater with a programmer, timer or any other device that
switches the heater on automatically, since a re risk exists if the heater is
covered or positioned incorrectly.
21. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
22. Children should be supervised to ensure that they do not play with the
appliance.
23. The head of the unit is at high temperature during operation. Unplug the unit
and wait till it's cool before cleaning.
24. Don't use this heater in the immediate surroundings of a bath, a shower or a
swimming pool.
25. Don't use this unit in place where causticity or volatile air exists, i.e. dust,
steam, gas, etc.
26. Don't use this unit as a cloth drier or towel drier.
27. Don’t use this unit as a sauna heater.
28. Don't use this unit as a room heater of heat storing.
29. Don't use this unit in place of animal propagating and raising.
30. Don't use this unit in heating system of hot air centre.
31. Don't immerse this unit into water for cleaning.
32. The unit should be plugged in a socket, which is easily visible and reachable.
33. Two Dark points may exist on the surface of the heating elements, or the surface
of the heating element may turn white during the rst few minutes after it's
turned on. This is normal, and may not aect the performance of the unit
34. To avoid potential re hazards, never place your heater or its electrical cord
under rugs, or carpeting. Place the electrical cord away from busy areas to
avoid accidental tripping and contact.
35. To disconnect heater, turn controls to o, and turn o power to heater circuit
at main disconnect panel. then remove plug from outlet.
36. Use this heater only as described in this manual.
Any other use not recommended by the manufacturer may cause re, electric
shock, or injury to persons.
37. Avoid the use of and extension cord because the extension cord may overheat
and cause a risk of re. However, if you have to use an extension cord, the cord
shall be No. 14AWG minimum size and rated not less than 1875 watts.
www.SereneLifeHome.com2
www.SereneLifeHome.com4 www.SereneLifeHome.com 5
38. Surface temperatures become very hot when operating heater. Children and
adults should stay away to avoid burns or clothing ignition.
39. Young children should be carefully supervised when they are in the area of
the heater.
40. SAVE THESE INSTRUCTIONS.
PREPARATION
1. Prepare a cross head screw driver.
2. Read this instruction manual carefully before installation and use. Keep this
instruction manual in a proper and safe place for future use in case needed.
PARTS DESCRIPTIONS:
PARTS DESCRIPTIONS:
INSTALLATION
1. Drill 4 wholes positioned as shown above. Insert Plastic Plug (#4), (4 PCs totally)
to the holes respectively. Align Wall Bracket (#2) to the holes, and then x it
with Tapping Screw (#3).
2. Insert the wall bracket into the hole (Section C) of Control Box.
Fix them with the Screw Knob M6*12 (#5).
OPERATIONS:
1. Plug in the unit to a socket. Make sure the power supply is same as rated.
The blue indicator light will start ashing, which means it's in standby status.
2. Press button "On" on the control panel or the remote controller to switch on
the heater. Then the blue indicator will light up.
3. When the heater is no longer required, switch o, using the o button on the
unit or the o button on the remote controller and unplug the unit.
MAINTENANCE AND CLEANING
1. Before cleaning, make sure the power has been turned o at the circuit breaker
panel and that the heating element of the heater is cool.
2. To maintain the external appearance of the radiator, it only needs to be wiped
over occasionally with a dry duster. During the summer months, or at other
times when the appliance is not in use and is completely cold, it should be the
best opportunity to wipe over with a damp cloth.
3. Do not use abrasive cleaning powders or furniture polish to clean the appliance.
Do not use chemical or abrasive products, metallic scourers and so on, they
may deteriorate the surface.
4. All other servicing should be performed by qualied service personnel.
5. No disassembly when cleaning.
A
36
2
6
1
5
31
1800mm
B
C
3 4
31mm
No.
Part Name
No.
Part Name
1
Control Box
4
Plastic Plug
2 Wall Bracket
5
Screw Knob M6*12
3
Tapping Screw ST4*30 6 Remote Controller
www.SereneLifeHome.com2
www.SereneLifeHome.com6 www.SereneLifeHome.com 7
GROUNDING INSTRUCTIONS:
This heater is for use on 120 volts. The cord has a plug as shown at A in Figure
below. An adapter as shown at C is available for connecting three-blade grounding-
type plugs to two-slot receptacles. The green grounding lug extending from the
adapter must be connected to a permanent ground such as a properly grounded
outlet box. The adapter should not be used if a three-slot grounded receptacle is
available.
FEATURES:
•
Secure Locking System
• High Rated Aluminum Reector
• Oers Sun-like Infrared Heating
• Includes Mesh Grille Front
• Odorless, No Gas or Propane Use
• Remote Control Wall Mounting Heater
• Dust and Waterproof Design
• Anodized Extruded Aluminum Alloy Housing
• High-Eciency Carbon Fibre Heating Elements
• One Power Settings
• IP65 Approved
Technical Specs:
•
Construction Material: Aluminum Alloy Frame
• Power Supply: 1500W
• 1 Heat Levels: 1500 Watts
• Heating Area: 18 sq. ft.
• Maximum Amperage: 12.5 Amps
• Battery Life: Up to 2+ Hours
• Battery Operated Remote: 1.5V, (2) x ‘AAA’ Batteries (not included)
• Power Cable Length: 2 Meters, 120V
• Heat Warm Range: Around 10-15 Square Meters
• Product Dimensions (L x W x H): 25.6'' x 8.46'' x 9.65'' -inches
What's in the Box:
•
1500 Watt Electric Patio Heater
• (1) Wall Bracket
• (4) Plastic Plug
• (4) Tapping Screw ST4 x 30
• (1) Remote Controller
Grounding Methods
Metal Screw
Ground cover
Outlet Box
Grounding Pin
A B
Grounding Pin
Grounding Means
C D
ADAPTER
