JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated. JBL is a registered trademark
of JBL, Incorporated.
Part No.
ai0449
TWEETER TYPE: Pure-titanium dome with EOS™ waveguide
DESIGN GOAL: Bring the thrill of live performance and movie sound to
the outdoors by calling on JBL’s professional engineering leadership.
CROSSOVER NETWORK: Straight-Line Signal Path™ (SSP)
WOOFER TYPE:
Cast-aluminum basket with HeatScape™ motor structure
ENCLOSURE DESIGN: Sealed
PROFESSIONAL REFERENCE: Studio Monitor
OWNER’S GUIDE
PRO SOUND
COMES HOME
™
PRODUCT LINE:
STUDIO
™
SERIES
MODEL
S36AW
NUMBER:
SPECIFICATIONS
S36AW
Description: 3-Way 6" vertical/horizontal, mirror-image,
wall-mount/bookshelf, weather-resistant loudspeakers
Maximum Recommended
Amplifier Power*: 150W
Nominal Impedance: 8 Ohms
Sensitivity (2.83V/1m):
90dB
Frequency Response (–3dB):
60Hz – 20kHz
Crossover Frequencies: 650Hz, 3000Hz
High-Frequency Transducer: 1" Pure-titanium dome, with rubber surround,
shielded; Elliptical Oblate Spheroidal™ (EOS)
waveguide
Midrange Transducer: 4" WeatherPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, shielded; Linear Field
Proximity™ (LFP) bezel
Low-Frequency Transducer
: 6" WeatherPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, SFG™, magnetic shorting
rings, high-temp oversized Kapton
®
voice coil,
HeatScape™ motor structure, cast-aluminum
baskets, shielded
Baffles: Low diffraction, IsoPower™
Enclosure: Sealed
Network: Straight-Line Signal Path™ (SSP)
Terminals: All-metal, gold-plated 5-way binding posts
Dimensions (H x W x D): 10-1/4" x 14-5/8" x 5"
260mm x 371mm x 127mm
Weight: 11 lb/5kg
*The maximum recommended amplifier power rating will ensure proper system headroom to allow
for occasional peaks. We do not recommend sustained operation at these maximum power levels.
All features and specifications are subject to change without notice.
