Shure ULXD4Q-H50 User Manual
Shure ULXD4Q-H50 ULXD4Q Quad-Channel Digital Wireless Receiver H50: 534 to 598 MHz
User Manual
For ULXD4Q-H50.
PDF File Manual
,
70 pages
,
Read Online
|
Download pdf file
Table of Contents
ULX-D Dual and Quad Wireless Microphone System
