Maintenance Bypass Panel
Models: SU100KMBPKX, SU120KMBPK, SU160KMBPKX,
SU180KMBPKX, SU210KMBPKX
Installation and Operation Manual
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All trademarks are the sole property of their respective owners.
Contents
1. Introduction 2
2. Important Information About This Manual 2
2.1 Manual Symbols 2
3. Safety Precautions 2
4. Inspection Upon Receipt of Goods 3
4.1 General 3
4.2 Visible Damage 3
4.3 Concealed Damage 3
4.4 Return of Damaged Goods 3
5. System Overview 3
6. System Specifications 3
6.1 Electrical 3
6.2 Environmental 3
6.3 General Specifications 4
7. Installation 4
7.1 Preparation 4
7.1.1 Equipment Inspection 4
7.1.2 Necessary Equipment and Tools 4
7.1.3 Installation Safety Precautions 4
7.1.4 Storage 4
7.2 Installation Steps 4
7.2.1 Equipment Location 4
7.2.2 Equipment Mounting 4
7.2.3 Equipment Connections 5
7.2.4 Pre-Energizing Inspection 5
7.2.5 Energizing 5
8. System Operation 6
9. Maintenance 7
9.1 Short Circuits and Overloads 7
10. Reference Materials 7
11. Warranty 9
Español 10
Français 19
Русский 28
