1
USB 3.2 Type-C to RJ45
LAN 2.5 Gbps Ethernet
Adapter, Black
Model: U436-06N-2P5
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Quick Start Guide
Este manual está disponible en español en la página de Tripp Lite:
tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite :
tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
2
• U436-06N-2P5 USB to 2.5G Ethernet Network Adapter
• Quick Start Guide
• Supports USB Type-C Input and 2.5 Gbps RJ45 Output
• Supports USB-C plug-and-play and hot swap
• Supports 10M/100M/1G/2.5G bandwidth
• Supports twisted pair crossover detection and auto-
correction
• USB bus-powered (no external power supply)
• Support wake-on-LAN (WOL), full duplex and auto-
negotiation
• Supports the following operating systems:
• Windows: Windows 8 / Windows 8 / Windows 10 /
Windows Vista / Windows XP (32/64 bit)
• Mac: macOS 10.6 to 10.12.5
• Linux
Note: If driver software installation is required, please download from
tripplite.com.
Package Contents
Product Features
3
1. Connect USB Type-C end of the U436-06N-2P5 to the USB
Type-C or Thunderbolt 3 host port on your PC
2. Connect the Gigabit Ethernet port to an Ethernet router with
an Ethernet cable (not included)
3. Automatically or manually set IP address of computer
Operation
Ethernet Source Type-C/Thunderbolt 3 Host
4
When the U436-06N-2P5 is connected to a Windows PC, the
“auto-run” function will allow the driver to start installation.
If the Windows PC cannot automatically start the “auto-run”
function, you will need to set it up manually:
1. Double-click the below icon in the File Explorer window.
Driver Installation
5
Driver Installation
2. Double-click the “Driver Installation” icon, then click “Yes” to
nish the installation.
6
Input/Output Connector
Input USB-C (Male)
Output RJ45 (Female)
RJ45 Basic Specications
Supported Communication Rate 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps
Wake On LAN Yes
Full Duplex Flow
(10M/100M/1G/2.5G Rate)
Yes
Auto-Negotiation Yes
Size & Weight
Dimensions (LxWxH) 2.165 x 0.846 x 0.511 in.
5.5 x 2.15 x 1.3 cm
Weight 0.044 lb.
20 g
Environmental
Operating Temperature Range 32 to 113°F
0 to 45°C
Storage Temperature Range 14 to 158°F
-10 to 70°C
Operating Humidity Range 10 to 85% RH, Non-Condensing
Storage Humidity Range 5 to 90% RH, Non-Condensing
Power Consumption
Voltage Supported 4.75V to 5.25V
Standby Power <60mA (When Ethernet cable is not
connected)
Normal Operating Power <250mA 10/100/1000/2500Mbps
Regulatory Approvals
Certications RoHS, REACH, CE, FCC
Accessories
Quick Start Guide English
Specications
7
Warranty and Product Registration
1-Year Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions,
to be free from original defects in material and workmanship for a period of one
(1) year from the date of initial purchase. If the product should prove defective
in material or workmanship within that period, Seller will repair or replace the
product, at its sole discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE
RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER
MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY
EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED
BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL
WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND
THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND
CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how
long an implied warranty lasts, and some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you. This warranty gives you specic legal rights,
and you may have other rights which vary from jurisdiction to jurisdiction.)
WARNING: The individual user should take care to determine prior to use
whether this device is suitable, adequate or safe for the use intended. Since
individual applications are subject to great variation, the manufacturer makes no
representation or warranty as to the suitability or tness of these devices for any
specic application.
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll
be automatically entered into a drawing for a chance to win a FREE Tripp Lite
product!*
*No purchase necessary. Void where prohibited. Some restrictions apply. See website for
details.
8
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
21-09-376 9340DD_RevA
Warranty and Product Registration
WEEE Compliance Information for Tripp Lite Customers and Recyclers
(European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive
and implementing regulations, when customers buy new electrical and
electronic equipment from Tripp Lite, they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis
(this varies depending on the country)
• Send the new equipment back for recycling when this ultimately
becomes waste
Use of this equipment in life support applications where failure of this equipment
can reasonably be expected to cause the failure of the life support equipment or
to signicantly aect its safety or eectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specications are subject
to change without notice. Photos and illustrations may dier slightly from actual
products.
