1
Owner’s Manual
SmartRack
™
High-Capacity Vertical Cable Manager
Models:
SRCABLEVRT3, SRCABLEVRT6 & SRCABLEVRT12
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Introduction
SRCABLEVRT models are high capacity cable managers for Tripp Lite open frame racks and rack enclosures. The SRCABLEVRT6
and SRCABLEVRT12 models are designed for use in either a 2-post or 4-post open frame rack, while the SRCABLEVRT3 is
designed for installation in the SR42UBWD extra-wide enclosure. Each SRCABLEVRT unit includes three cable trays along
with three adapter plates that allow the unit to be mounted to PDU managers in 42U SmartRack enclosures.
Parts List
Cable Tray
Frames (3)
Adapter Plates
(3)**
Cable Tray
Doors (3)*
Cable Tray
Door Straps
(9)**
Cable
Guides (12)
Tie Plates (2)* Mounting
Buttons (6)
‡
Mounting
Brackets (6)*
Mounting
Brackets (6)**
Door Hinges (18) M4 x 6 mm
Flat Head
Screws (12)
†
M4 x 12 mm Pan
Head Screws (18)
‡
M4 x 8 mm Pan
Head Screws (8)
Single-Depth Installation ..................2
SR42UBWD Installation: Front-Facing......11
Double-Depth Installation ................. 6
SR42UBWD Installation: Side-Facing......14
*SRCABLEVRT6 & SRCABLEVRT12 only.
**SRCABLEVRT3 only.
†SRCABLEVRT3 includes 6 pieces.
‡SRCABLEVRT3 includes 12 pieces.
Copyright © 2012 Tripp Lite. All rights reserved. SmartRack is a trademark of Tripp Lite.
42U Enclosure with PDU Manager Installation Side-Facing......16
WARRANTY
REGISTRATION:
register online today for a
chance to win a FREE Tripp Lite
product—www.tripplite.com/warranty
201202097 93-3029-EN with Addendum.indd 1 3/5/2012 12:14:50 PM
