PRELIMINARY SPECIFICATION GUIDE FREESTANDING DISHWASHER, 60CM, SANITISE
OVERVIEW
Freestanding design for flexible installation anywhere in the
kitchen. Adjustable storage allows for easy stacking, while a
combination of clever technologies means a reliable wash
performance.
MODELS
Freestanding Dishwasher, 15 Place Settings, Sanitise,
Stainless Steel
DW60FC2X2
SERIES & STYLE
Series 5
Contemporary Style
FEATURES
1 Freestanding installation anywhere in the kitchen,
including under bench heights between 848–908mm
2 15 place setting capacity and easily accommodates plate
sizes up to 320mm
3 Seven wash programs including Auto, Eco and 60 Min
cycles
4 Dry+, Sanitise and Half Load modifiers for added
flexibility*
5 ThermoDry technology with auto door opening at the end
of the cycle to remove excess moisture
6 Flexible racking including adjustable upper basket,
foldable cup racks and cutlery basket
7 Front-of-door controls with status display
8 With 4 star energy and 5 star water rating*
9 Quiet wash performance, running at a decibel rating of
46dBA**
*Energy and water ratings subject to change. Final certification pending.
**Noise levels subject to change
90002440 Date: 21.07.2022 | Product specifications may vary from those shown in this Preliminary Specification Guide. This document is superseded and will become obsolete upon launch of the
product. This Preliminary Specification Guide should not be used as installation guidance for any product. Further information is required to safely and correctly install the products featured here. Specific
installation guidance will be available with the product on delivery and on our website fisherpaykel.com
PRELIMINARY SPECIFICATION GUIDE FREESTANDING DISHWASHER, 60CM, SANITISE
PRODUCT DIMENSIONS
mm
A Overall height* 848 - 89
B Overall width 597
C Overall depth 600
*Depending on adjustment of levelling feet
PRODUCT SPECIFICATIONS
Model No. DW60FC2X2
Dimensions H 848 - 89mm W 597mm D 600mm
Electrical
Supply 20 VAC, 50 Hz
Service 10 Amp circuit
Receptacle -prong grounding-type
Plumbing
Supply /4 BSP (20mm) connector water inlet hose
Pressure Min 150 kPa (22 psi) Max 827 kPa (120 psi) @
20°C
CAVITY DIMENSIONS: STANDARD INSTALLATION
mm
A Overall height with top deck* 850 - 895
Overall height without top deck* 820 - 865
B Overall width 600
C Overall depth min. 605
*Depending on adjustment of levelling feet
ISO VIEW ISO VIEW
ISO VIEW
Service outlet at rear extends both sides, hoses and cords can be routed to either or both sides.
*Depending of adjustment of levelling feet.
A
A
B
B
C
C
100-145mm*
60mm
REAR VIEW
PLUMBING AND ELECTRICAL
