Generac GB1000 and GB2000
Portable Power Station
Owner’s Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE
013617
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(1-888-436-3722)
MODEL:________________________
SERIAL:________________________
DATE PURCHASED:______________
Table of Contents
Section 1 Introduction and Safety ..................................................................1
Introduction ........................................................................................................1
Safety Rules .......................................................................................................1
Important Alerts ..................................................................................................1
FCC Statement ..................................................................................................2
Section 2 General Information and Setup ......................................................3
What’s Included ..................................................................................................4
Know Your Power Station ..................................................................................4
Know Power Station Limits ................................................................................6
Estimated Operating Time .................................................................................6
Section 3 Operation .........................................................................................7
Operation and Use Questions ............................................................................7
General Use .......................................................................................................7
Using the Power Station (Discharging) ..............................................................7
Charging the Power Station ...............................................................................7
Simultaneous Charge Inputs ..............................................................................8
Pass-Through Charging .....................................................................................8
Parallel Connection ............................................................................................8
Transportation ....................................................................................................9
Section 4 Maintenance and Troubleshooting ..............................................10
Product Maintenance .......................................................................................10
Storage ............................................................................................................10
Disposal ...........................................................................................................10
FAQ ..................................................................................................................10
Troubleshooting ...............................................................................................10
Notes ................................................................................................................12
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.
Owner’s Manual for Power Station 1
Section 1 Introduction and Safety
Introduction
Read This Manual Thoroughly
If any section of this manual is not understood,
contact the nearest Independent Authorized
Service Dealer (IASD) or Generac Customer
Service at 1-888-436-3722 (1-888-GEN-
ERAC), or visit www.generac.com for start-
ing, operating, and servicing procedures. The
owner is responsible for proper maintenance
and safe use of the unit.
SAVE THESE INSTRUCTIONS for future ref-
erence. This manual contains important
instructions that must be followed during
placement, operation, and maintenance of the
unit and its components. Always supply this
manual to any individual that will use this unit,
and instruct them on how to correctly start,
operate, and stop the unit in case of emer-
gency.
The information in this manual is accurate
based on products produced at the time of
publication. The manufacturer reserves the
right to make technical updates, corrections,
and product revisions at any time without
notice.
Safety Rules
The manufacturer cannot anticipate every
possible circumstance that might involve a
hazard. The alerts in this manual, and on tags
and decals affixed to the unit, are not all inclu-
sive. If using a procedure, work method, or
operating technique that the manufacturer
does not specifically recommend, verify that it
is safe for others and does not render the
equipment unsafe.
Throughout this publication, and on tags and
decals affixed to the unit, DANGER, WARN-
ING, CAUTION, and NOTE blocks are used to
alert personnel to special instructions about a
particular operation that may be hazardous if
performed incorrectly or carelessly. Observe
them carefully. Alert definitions are as follows:
NOTE: Notes contain additional information
important to a procedure and will be found
within the regular text of this manual.
These safety alerts cannot eliminate the haz-
ards that they indicate. Common sense and
strict compliance with the special instructions
while performing the action or service are
essential to preventing accidents.
Important Alerts
Electrical Hazards
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
(000104)
DANGER
Electrocution. Water contact with a power source,
if not avoided, will result in death or serious injury.
(000756)
DANGER
Electrocution. Contact with bare wires,
terminals, and connections will result in death
or serious injury.
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000482)
Electrocution. Never charge a battery in wet
conditions. Doing so could result in death, serious
injury, equipment or property damage.
WARNING
WARNING
Electrocution. Never operate this unit in wet conditions,
and always store it under a cover or in a dry location.
Failure to do so could result in death, serious injury, or
equipment or property damage.
(000713a)
2 Owner’s Manual for Power Station
Fire and Explosion Hazards
Additional Personal Property
Hazards
FCC Statement
The equipment complies with part 15 of the
FCC rules. The operation shall meet the fol-
lowing two conditions:
1. The device may not cause harmful inter-
ference, and
2. The equipment must accept any interfer-
ence received, including interference that
may lead to accidental operation.
3. The equipment complies with FCC radia-
tion exposure limits for uncontrolled envi-
ronments. The equipment shall be
installed and operated at a minimum dis-
tance of 20 cm between the radiator and
the vehicle body.
NOTE: According to part 15 of the FCC rules,
the equipment has been tested and found to
comply with the limitations of class B digital
equipment. These restrictions are intended to
provide reasonable protection against harm-
ful interference with residential facilities. The
equipment can be used and radiate RF
energy. If it is not installed and used according
to the instructions, it may cause harmful inter-
ference to radio communication. However,
there is no guarantee that interference will not
occur in a specific installation. If the equip-
ment does cause harmful interference to radio
or television reception, it can be determined
by turning off the equipment, and users are
encouraged to correct the interference by one
or more of the following measures:
1. Reposition or reposition the receiving
antenna.
2. Increase the distance between the device
and the receiver.
3. Connect the device to an outlet on a circuit
different from the circuit to which the
receiver is connected.
4. Consult your dealer or experienced radio /
TV technician for assistance.
Electrocution. Grasp electrical cord plug when
unplugging the electrical cord from the outlet. Do
not touch metal prongs. Failure to do so could
result in death or serious injury.
WARNING
(000714a)
(000162)
Explosion. Do not dispose of batteries in a fire.
Batteries are explosive. Electrolyte solution can cause
burns and blindness. If electrolyte contacts skin or eyes,
flush with water and seek immediate medical attention.
WARNING
WARNING
Risk of fire. Do not crush, puncture, or subject
battery units or modules to strong impacts. Failure
to do so could result in death, serious injury,
property damage, or equipment damage.
(000730)
WARNING
Equipment and property damage. Do not operate unit on
uneven surfaces, or areas of excessive moisture, dirt, dust
or corrosive vapors. Doing so could result in death, serious
injury, property and equipment damage.
(000250)
(000757)
WARNING
Injury and equipment damage. Do not use battery as
a step. Doing so could result in falling, damaged
parts, unsafe equipment operation, and could result
in death or serious injury.
(000752)
WARNING
Injury and equipment damage. The use of non-Generac
equipment could result in unit damage, death or serious
injury.
(000163a)
Risk of burn. Do not open or mutilate batteries.
Batteries contain electrolyte solution which can cause
burns and blindness. If electrolyte contacts skin or
eyes, flush with water and seek immediate medical
attention.
WARNING
(000128a)
WARNING
Personal injury. Keep out of reach of children.
Failure to do so could result in death or serious injury.
Owner’s Manual for Power Station 3
Section 2 General Information and Setup
Figure 2-1. Features and Controls
TABLE 1. Components
4
16
013615013617
15
9
013763
17
3
1
8 10
7
2
5
13 12 11
14
6
1 Main ON/OFF Button
2 AC Output ON/OFF Button
3 NEMA 1-15R AC Receptacles
4 AC Output Circuit Breaker
5 DC Output ON/OFF Button
6 12V Car Port
7 USB-A Output Receptacle
8 USB-C Output Receptacle
9 Wireless Charging Pad
10 Display ON/OFF Button
11 Display Screen
12 LED ON/OFF Button
13 Diffused LED Light
14 Parallel Ports
15 AC Charging Port
16 DC Charging Port
17 Cord Storage Pocket
4 Owner’s Manual for Power Station
Figure 2-2. Control Panel and LCD Display
TABLE 2. Display Screen Icons
What’s Included
Know Your Power Station
Replacement owner’s manuals are available
at www.generac.com.
10 9 71
5
11
6
8
3
2
013619
4
1 Battery State of Charge
2 Battery State of Charge Indicator Bar
3 Input Power (Charging)
4 Output Power
5 AC Output ON/OFF Icon
6 DC Output ON/OFF Icon
7 Estimated Charge / Discharge Time
Remaining
8 Low Battery Power Indicator
9 Fault Warning
10 Low Temperature Warning
11 High Temperature Warning
Car Charger Cord
013943
Solar Adapter Cord
(XT90 to MC4)
AC Charge CordPower Station
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
Owner’s Manual for Power Station 5
TABLE 3. Product Specifications
GB1000 GB2000
GENERAL
Dimensions
(L x W x H)
14.1 x 10.2 x 12.0 in
(359 x 258 x 305 mm)
16.8 x 10.4 x 15.1 in
(425 x 265 x 384 mm)
Weight 27.1 lbs (12.3 kg) 43 lbs (19.5 kg)
Output
AC Output (x3) 120VAC / 13.3A (1600W / 3200W Surge)
USB-A (x2) 5VDC / 3.1A (15.5W max ea.)
USB-C (x2) 5-20VDC / 3.3A (65W max ea.)
12V Car Port 12VDC / 10A (120W max)
Wireless Charger 15W max
Charge Input
AC Wall Charger 120VAC 60Hz 450W max
DC / Solar Charger 10-28VDC / 30A (468W max)
Battery
Cell Chemistry Li-ion NMC
Pack Capacity 1086Wh 2106Wh
Cycle Life* 800 cycles to 80% capacity 1000 cycles to 80% capacity
Shelf Life Charge every 3-6 months
Management System
High / Low temperature protection
Overload protection
Over voltage protection
Under voltage protection
Short circuit protection
Environmental
Discharge Temperature -4°F to 104°F (-20°C to 40°C)
Charge Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature
Optimal 59°F to 77°F (15°C to 25°C)
Max -4°F to 113°F (-20°C to 45°C)
Exposure Rating Temporary Outdoor Use
*Cycle life based on charge rate of 0.5C and discharge rate of 1C @ 25°C
6 Owner’s Manual for Power Station
Know Power Station Limits
Overloading a Power Station can result in
damage to the Power Station and connected
electrical devices. Observe the following to
prevent overload:
• Add the total wattage of all electrical
devices to be connected at one time. This
total should NOT be greater than the Power
Station's wattage capacity.
• The rated wattage of lights can be taken
from light bulbs. The rated wattage of tools,
appliances, and motors can be found on a
data label or decal affixed to the device.
• If the appliance, tool, or motor does not
give wattage, multiply volts times ampere
rating to determine watts (volts x amps =
watts).
• Some electric motors, such as induction
types, require approximately three times
more watts of power for starting than for
running. This surge of power lasts only a
few seconds when starting such motors.
Make sure to allow for high starting wattage
when selecting electrical devices to con-
nect to the Power Station:
1. Calculate the watts needed to start the
largest motor.
2. Add the starting watts to the running watts
of all other connected loads.
The Wattage Reference Guide is provided to
assist in determining how many items the
Power Station can operate at one time.
NOTE: All figures are approximate. See data
label on appliance for wattage requirements.
Estimated Operating Time
Device Image Watts GB1000 Runtime GB2000 Runtime
Light 10W 90.0 Hrs 180.0 Hrs
CPAP 40W 22.5 Hrs 45.0 Hrs
Refrigerator 120W 7.5 Hrs 15.0 Hrs
Microwave 1200W 0.8 Hrs 1.5 Hrs
50” TV 110W 8.2 Hrs 16.4 Hrs
Phone
11Wh 82 Full Charges 164 Full Charges
Laptop
60Wh 15 Full Charges 30 Full Charges
Car Fridge
60W 15.0 Hrs 30.0 Hrs
Circular Saw
1400W 0.6 Hrs 1.3 Hrs
Electric Drill
1000W 0.9 Hrs 1.8 Hrs
Electric Grill
1150W 0.8 Hrs 1.6 Hrs
Portable
Heater
1500W 0.6 Hrs 1.2 Hrs
Owner’s Manual for Power Station 7
Section 3 Operation
Operation and Use Questions
Call Generac Customer Service at 1-888-
GENERAC (1-888-436-3722) with questions
or concerns about equipment operation and
maintenance.
General Use
Powering ON the Power Station
Press and hold the ON/OFF button to turn ON
the Power Station. The ON/OFF button will
illuminate, and the LCD display will turn ON.
NOTE: The Power Station will automatically
shut down after 60 minutes of idle operation to
conserve the battery.
Press and hold the ON/OFF button again to
turn off the Power Station.
LCD Display
The LCD display automatically turns ON when
the Power Station is turned ON. Once the
Power Station is ON, the display can be tog-
gled ON and OFF by pressing the Display But-
ton.
NOTE: The Power Station display will enter
sleep mode after 10 minutes of idle operation.
LED Light
With the Power Station powered ON, press
the LED button once to turn ON the low flood
light. Press the LED Button again to turn ON
the high flood light. Press the LED Button
again to turn off the light.
Wireless Charger
With the Power Station powered ON, press
the DC Button to turn ON the wireless charger.
NOTE: Ensure the device is centered on the
wireless charging pad. Wireless charger may
not be compatible with certain devices or
cases on devices.
AC Output
With the Power Station powered ON, press
the AC Button to use the 120V AC recepta-
cles. The AC Button will illuminate, and the AC
icon will appear on the display.
NOTE: If the AC Button is flashing, press and
hold the AC Button to reset the circuit. See
Troubleshooting if the flashing persists.
DC Output
With the Power Station powered ON, press
the DC Button to use the USB’s, 12V car
adapter and wireless charger. The DC Button
will illuminate, and the DC icon will appear on
the display.
NOTE: If the DC Button is flashing, press and
hold the DC Button to reset the circuit. See
Troubleshooting if the flashing persists.
Using the Power Station
(Discharging)
Starting the Power Station
NOTE: If using only one, or all three AC
receptacle(s), the load must not exceed 13.3A
current, 1600 watts of power.
1. Confirm the device or equipment requiring
power is OFF.
2. Press and hold ON/OFF button for three
(3) seconds to turn unit ON.
3. Connect equipment.
– AC Power - Turn ON AC power switch.
– DC Power (USB/vehicle charging) -
Turn ON DC power switch.
NOTE: Power Station will automatically turn
off after 60 minutes if not in use.
Charging the Power Station
IMPORTANT NOTE: Always use the
charging cord(s) supplied with the unit.
NOTE: The ambient temperature for product
use should be between 0 °C to 40 °C (32 °F to
104 °F).
Place the Power Station on a clean, dry, level
surface.
The Power Station can be charged three (3)
separate ways.
1. See Figure 3-1. AC Power Supply - Insert
AC charging cord from the AC charging
port to the wall electrical outlet.
Figure 3-1. AC Wall Charging
2. See Figure 3-2. Solar Panels - Insert DC
charging cord from the solar panel into the
DC charger port.
NOTE: Charging time is dependent on the
solar panel power and light intensity.
(000752)
WARNING
Injury and equipment damage. The use of non-Generac
equipment could result in unit damage, death or serious
injury.
013906
8 Owner’s Manual for Power Station
NOTE: Confirm the solar panel is compatible
with the power station before connecting the
solar panel. Power stations support 10-
28VDC, 30A max, up to 468W of solar input.
Solar panels not meeting these requirements
may damage the power station.
Figure 3-2. Solar Charging
3. See Figure 3-3. Car Charging - Insert DC
charging cord from the car power supply
into the DC charger port.
NOTE: Car charging the power station will
drain the vehicles battery. It is recommended
to only charge the power station while the
vehicle is running to prevent depletion of the
vehicle’s battery.
NOTE: Always disconnect the power station
when the vehicle is turned off.
Figure 3-3. Car Charging
Simultaneous Charge Inputs
Power Stations are compatible with simultane-
ous AC and DC charge inputs (example: solar
+ generator).
The charging input reference guide provides
suggested charge input power range.
NOTE: Exceeding suggested charge input
power can reduce battery life.
Pass-Through Charging
Power Stations support simultaneous
charging and discharging of the battery during
operation.
NOTE: This device is not designed to be used
as a UPS (Uninterrupted Power Supply).
NOTE: Pass-through charging can reduce
battery life.
Parallel Connection
• The rated power of equipment should not
exceed the total rated power of parallel
products.
• Only use with compatible Power Stations
and Generac Portable Inverter Generators.
See parallel kit manual for complete list of
compatible devices.
• The use of non-Generac equipment could
cause unit damage or personal injury.
• Connect parallel devices before turning the
power ON.
• Turn the power OFF before disconnecting
parallel devices.
Paralleling two Power Stations provides
almost twice the power.
1. See Figure 3-4. Insert the parallel plugs
from the parallel box into the Power Sta-
tions.
2. Press ON/OFF button on the Power Sta-
tions.
3. Press AC button on the Power Stations.
4. Plug electrical equipment into the AC out-
lets. Turn ON equipment.
NOTE: If a fault occurs, the AC power will turn
off and the fault light will flash for 10 seconds.
NOTE: AC and DC Power Station outlets can
be used at the same time as the parallel kit
although output is limited to the Power Sta-
tion’s rating.
Figure 3-4. Parallel Connections
BATTERY
LIFE
GB1000 GB2000
Best <540W <1000W
Good 540W - 800W —
Not Advised >800W —
013907
013908
Car Adapter
(000752)
WARNING
Injury and equipment damage. The use of non-Generac
equipment could result in unit damage, death or serious
injury.
013623
Owner’s Manual for Power Station 9
Transportation
• Position and/or tie-down power station
securely during travel to prevent rolling or
tipping of the product. Failure to secure the
power station may result in unit damage or
personal harm.
• Refer to FAA regulations regarding air
travel. Power stations with lithium batteries
(>160Wh) are not permitted for commercial
air travel.
10 Owner’s Manual for Power Station
Section 4 Maintenance and Troubleshooting
Product Maintenance
• Use a damp cloth with mild soap to wipe
exterior surfaces clean.
NOTE: Avoid cleaning solvents harmful to
plastics to prevent damage to the power sta-
tion.
• Visually inspect unit to ensure vents are
clear before each use.
• Clean dust and debris from vent(s) with a
clean cloth before each use.
• Discharge and charge battery once every
three (3) months. See Using the Power Sta-
tion (Discharging).
• Charge the Power Station as soon as the
display reads 20% state of charge or less.
Storage
• Store unit in a clean, dry, ventilated area.
• Store at an optimal temperature of 59°F -
77°F (15°C - 25°C) and a max temperature
of -4°F - 113°F (-20°C - 45°C).
• The Power Station should be between 30-
60% state of charge for long term storage.
Recharge every three (3) months to main-
tain battery life.
Disposal
Contact an IASD to return Power Station for
disposal.
FAQ
Q: Why does the power station show power
output when I don’t have anything plugged
in?
A: The power station uses power for the dis-
play, fans, inverter, etc. Power usage is
shown on the LCD display for user aware-
ness.
Q: Can the GB1000/GB2000 be discharged at
the same time it is charging?
A: Yes, both models can be simultaneously
charged and discharged.
NOTE: Pass-through charging can reduce
battery life.
Q: How do I estimate the operating time for a
device?
A: Estimated operating time (hrs) = Capacity
(Wh) * 0.8 / Device Load (W).
Q: Can I use the GB1000/GB2000 outside?
A: Yes, both models are rated for temporary
outdoor use.
NOTE: The power stations should NOT be
exposed to rain or moisture.
Q: How do I silence the beeping sound when
pressing buttons?
A: Hold the DISPLAY button for five (5) sec-
onds.
Troubleshooting
PROBLEM CAUSE CORRECTION
Unit does not have out-
put power.
1. Unit turned off.
2. AC or DC output turned off.
3. AC circuit breaker OPEN.
4. Unit is overloaded. (Solid Fault
Warning on display)
5. Unit temperature is below -4
°F (-20 °C). (Low Temp Warn-
ing Icon on display)
6. Unit temperature is above 104
°F (40 C°). (High Temp Warn-
ing Icon on display)
7. AC or DC circuit error (AC /
DC display icon flashing).
8. Unit is defective. (Flashing
Fault Warning on Display)
1. Hold ON/OFF power button on
the power station.
2. Press AC or DC button to
power on circuit.
3. Reset circuit breaker.
4. See
Know Power Station
Limits
.
5. Move power station inside to
warm up. (This may take some
time.)
6. Move power station to cooler
location. (This may take some
time.)
7. Hold AC or DC button for three
(3) seconds to reset circuit.
8. Contact IASD.
Owner’s Manual for Power Station 11
Unit will not charge. 1. Bad power source.
2. Loose connection.
3. Unit temperature is below 32
°F (0 °C). (Low Temp Warning
Icon on display).
4. Unit temperature is above 104
°F (40 °C). (High Temp Warn-
ing Icon on display).
5. Defective charger (Alarm dis-
play icon flashing two (2)
times).
1. Confirm power source is com-
patible with the power station.
2. Confirm plugs are firmly con-
nected.
3. Move power station inside to
warm up. (This may take some
time.)
4. Move power station to cooler
location. (This may take some
time.)
5. Contact IASD.
Unit will not start. 1. Power station powered ON
incorrectly.
2. Battery at 0% state of charge.
3. Unit is defective.
1. Hold ON/OFF button for three
(3) seconds to power ON the
power station.
2. Charge the power station.
3. Contact IASD.
Unit starts, then shuts
down.
1. No load present on unit.
A. Display sleeps after 10 min-
utes.
B. Power station automatically
shuts down after 60 minutes
to conserve battery.
2. Unit is defective. (Flashing
Fault Warning on Display).
1. Hold ON/OFF button to power
on the power station. Ensure
AC or DC output is turned ON
and load is connected.
2. Contact IASD.
Unit is overheating -
(High Temp Warning on
Display).
1. Unit temperature is too high
(High Temp Warning Icon on
display).
2. Dirty or clogged vents.
3. Defective cooling fan.
1. Move power station to cooler
environment. (This may take
some time.)
2. Clean vents.
3. Contact IASD.
Wireless charger not
working.
1. DC output turned OFF.
2. Device not centered on wire-
less charging pad.
3. Device not compatible.
4. Case on device.
1. Press DC button to power on
circuit.
2. Center device on wireless
charging pad.
3. Confirm device is compatible
with wireless charging.
4. Remove case from device and
try again.
PROBLEM CAUSE CORRECTION
12 Owner’s Manual for Power Station
Notes
Part No. A0002236216 Rev. A 05/09/2022
©2022 Generac Power Systems, Inc.
All rights reserved
Specifications are subject to change without notice.
No reproduction allowed in any form without prior
written consent from Generac Power Systems, Inc.
Generac Power Systems, Inc.
S45 W29290 Hwy. 59
Waukesha, WI 53189
1-888-GENERAC (1-888-436-3722)
www.generac.com
