Miele CVA 7370 Built-In Coffee Maker in Stainless

Operating and Installation

Instructions

Built-in Coffee Machine

Always read the operating instructions before setting up, installing,

and commissioning the appliance.

This prevents both personal injury and damage to the appliance.

en-CA M.-Nr. 11 823 010

Contents

2

Initial commissioning ........................................................................................ 23

Miele@home ........................................................................................................ 23

Before using for the first time.............................................................................. 24

Switching on for the first time ............................................................................. 24

Filling the bean containers ............................................................................... 26

Filling the water container................................................................................ 27

Switching on and off ......................................................................................... 28

Spout adjustment .............................................................................................. 29

Preparing drinks ................................................................................................ 30

Making coffee with and without milk................................................................... 30

Tea....................................................................................................................... 34

TeaTimer......................................................................................................... 35

Making tea...................................................................................................... 35

Tea pot............................................................................................................ 36

Dispensing warm or hot water ............................................................................ 36

............................................................................................................................ 37

Grinder setting................................................................................................... 38

Parameters......................................................................................................... 39

Displaying and changing parameters.................................................................. 39

Portion size.......................................................................................................... 39

Contents

3

Making drinks stored in a profile ......................................................................... 41

Editing profiles..................................................................................................... 41

Setting when the profile should change......................................................... 41

Changing the name ........................................................................................ 42

Deleting a profile ............................................................................................ 42

MobileStart......................................................................................................... 43

Settings .............................................................................................................. 44

Displaying and changing Settings....................................................................... 44

Language............................................................................................................. 44

Time of day.......................................................................................................... 44

Volume................................................................................................................. 45

Display brightness............................................................................................... 45

Lighting................................................................................................................ 45

Info (display information) ..................................................................................... 45

Altitude ................................................................................................................ 45

Performance Mode.............................................................................................. 45

Eco Mode ....................................................................................................... 46

Barista Mode .................................................................................................. 46

Latte Mode ..................................................................................................... 46

Party Mode ..................................................................................................... 46

Showroom program (demo mode) ...................................................................... 49

Factory default settings....................................................................................... 49

Cleaning and care ............................................................................................. 50

Overview of cleaning intervals............................................................................. 50

Contents

4

Unsuitable cleaning agents ................................................................................. 52

Cleaning the drip tray and grounds container..................................................... 53

Cleaning the drip tray cover ................................................................................ 55

Cleaning the water container .............................................................................. 55

Cleaning the central spout .................................................................................. 55

Cleaning the cup rim sensor ............................................................................... 57

Maintenance programs........................................................................................ 64

Rinse appliance................................................................................................... 64

Rinse milk pipework ............................................................................................ 64

Degreasing the brew unit and cleaning the interior............................................. 65

Descaling the appliance ...................................................................................... 68

Frequently Asked Questions ............................................................................ 70

Messages in the display...................................................................................... 70

Unusual performance of the coffee machine ...................................................... 73

Unsatisfactory results.......................................................................................... 76

Service and warranty ........................................................................................ 78

Accessories ....................................................................................................... 79

Building in the coffee machine............................................................................ 84

Warnings and safety instructions

This coffee machine complies with all current local and national

safety requirements. Inappropriate use can, however, lead to

personal injury and material damage.

Read the operating instructions carefully before using the coffee

machine. They contain important notes on installation, safety,

operation, and maintenance. This prevents both personal injury

and damage to the coffee machine.

In accordance with standard IEC60335-1, Miele expressly and

strongly advises you to read and follow the instructions in the

5

Warnings and safety instructions

Appropriate use

preparation of drinks such as espresso, cappuccino, latte macchiato,

tea, etc. All other types of use are not permitted.

physical, sensory, or mental capabilities or lack of experience and

knowledge if they are supervised whilst using it.

6

Warnings and safety instructions

Safety with children

of adults.

Ensure children do not touch hot surfaces of the coffee machine or

place parts of their body under the dispensing spouts.

machine unless they are constantly supervised.

without supervision if they have been shown how to use it in a safe

manner.

Children aged 8and older must be aware of the potential dangers

7

Warnings and safety instructions

Technical safety

8

Warnings and safety instructions

9

Guide to the appliance

16

Controls and indicators

18

For switching coffee machine on and

off

For making drinks

For showing information about the

current action or status

Profiles sensor button

For creating and managing profiles

Maintenance sensor button

Maintenance programs, e.g.,Descale

Parameters sensor button

For displaying or changing drink

settings

For confirming display messages and

saving settings

buttons

For scrolling through lists, selecting

“Back”sensor button

For dispensing 2portions of a drink

at once

“DoubleShot”sensor button

For making a particularly strong and

aromatic coffee by using twice as

much ground coffee but the same

amount of water

Controls and indicators

 Caffè latte

 Hot milk

 Milk froth

 Tea water

Using the appliance

20

To operate the coffee machine, tap the

sensor buttons with your finger.

An audible signal is generated each

time a button is tapped. You can

adjust the volume of the signal tones

or switch the tones off (see “Settings –

You can find more drinks in the

Additional menu (sensor button).

To select a menu option, keep pressing

the arrow buttons and until the

option you want is highlighted.

To scroll more quickly through the

value, message, or setting, the

memorable names.

Using the appliance

The following symbols may also appear in the display in addition to the text:

22

Initial commissioning

range with other appliances (including

microwave ovens and remote control

toys). This may result in sporadic or

even complete connection failures.

Therefore, the availability of featured

functions cannot always be guaranteed.

The ability to use the Miele app

depends on the availability of the

Miele@home service in your country.

free of charge from the Apple App

Store

or from the Google Play™ store.

Initial commissioning

24

 Connect the coffee machine to the

electricity supply.

 Install the coffee machine.

 Remove any notices from the

machine.

 Remove the protective foil from the

drip tray cover.

 Clean the water container, the bean

containers, and the central spout.

 Remove the bean containers and fill

them with roasted coffee beans.

 Touch the On/Offbutton.

 Select the desired display language.

You might also be asked for your

location.

The choice of location determines how

the time of day is displayed, e.g., in

during set-up: Set up “Miele@home”

up Miele@home for your coffee

machine at a later point. In this case,

select Skip.

 Make sure that your Wi-Fi network

signal is sufficiently strong in the

place where you want to set up your

coffee machine.

 TapContinue.

 Select the connection method you

wish to use.

 Follow the instructions provided in

the coffee machine display and in the

 Set the current date and tapOK.

 Set the current time of day and

tapOK.

Initial commissioning

°dH) and confirm withOK.

You can select the appropriate mode to

suit your personal preferences (see

“Settings – Performance Mode”).

from the factory testing process are

removed from the brewing system,

please throw away the first 2cups of

coffee when using the coffee

machine for the first time.

Preparing drinks

32

coffee machine until it clicks into

place.

Useful tip: It is easier to remove the

 Place a cup under the central spout.

 Tap the sensor button for the drink

you want.

The drink will be dispensed from the

central spout into the cup.

 Tap the lit orange symbol on the

control panel again.

Select the DoubleShot function if

you would like a particularly strong and

aromatic coffee. In this case, more

coffee beans will be ground and brewed

halfway through brewing. The shorter

extraction time means that fewer

unwanted aromas and bitter

compounds will be released.

Making a DoubleShot of coffee

immediately before or after you start

making a drink.

You can dispense 2portions of a drink

into 1large cup or into 2cups at the

same time.

 Place a cup under each of the coffee

dispensers in the central spout.

 Press the sensor button

immediately before or after you start

making a drink.

The sensor button lights up.

You can make several cups of coffee

one after the other automatically with

water containers have enough beans

and water inside them before starting

the Coffee Pot function.

 Place a sufficiently large container

under the central spout.

 Touch the sensor button.

 Select Coffee Pot and confirm

withOK.

 Select the number of cups you want

(3to8).

Preparing drinks

34

and can vary depending on the

ambient conditions.

When making tea, you can select from

the following options:

The type of tea selected determines the

preset temperature.

The respective dispensing temperatures

are the ones that Miele recommends for

making the types of tea concerned.

confirm withOK.

Tap the sensor button to access the

menu containing the various types of

tea.

The drinks menu is displayed.

similar or take a tea bag out of the

packet.

the tea cup.

Preparing drinks

36

the desired brewing time has

elapsed.

The Tea Pot function allows you to make

a large quantity of tea (maximum

Useful tip: Make sure that the water

container has enough water inside it

You can choose between the following

options:

Expert Mode

change the portion size while the drink

is being made. The setting will not be

saved and will only apply to the current

drink.

2portions, Expert mode cannot be

used to change the portion size.

 Select a drink.

Dispensing will start. You can adjust the

portion size while it is being dispensed,

e.g., individually change the amount of

hot milk, milk froth, and espresso for a

latte macchiato.

Grinder setting

38

contact time between the ground coffee

and the water, known as the extraction

time. When the ideal grinder setting is

selected, the machine dispenses a

perfect cup of coffee with a fine,

hazelnut-brown crema.

the coffee grinder is set correctly.

Set a finer grinder setting.

The grinder setting is too fine if the

coffee or espresso tastes too bitter and

the crema is dark brown.

Set a coarser grinder setting.

Only adjust the grinder one setting at

a time.

Start making a new drink to grind

beans again. Adjust the grinder

 Remove the water container.

one setting forward (for finer grinding)

or one setting backward (for coarser

grinding).

 Close the appliance door.

 Make one cup of coffee.

After this, you can adjust the grinder

setting again.

Parameters

drinks.

In addition, you can set the amount of

coffee, brew temperature, and pre-

brewing parameters for each coffee

current settings for the following

appear: Amount of coffee, Brew

temperature, and Pre-brewing.

The Portion size menu option is

displayed in the first line. If you

select Portion size and confirm

withOK, the drink will be dispensed

immediately.

 Select the parameter you want.

 Change the setting as required and

You can program the amount of water

for all drinks (apart from the Coffee Pot

function) to suit the size of your cups

and/or the type of coffee you are

using.

not only set the amount of espresso or

coffee but also the amount of milk or

milk froth to be dispensed with these

drinks.

programmed for each type of drink.

Dispensing stops once this has been

reached. The maximum possible

portion size is then saved by the

machine for this type of drink.

withOK.

The desired drink will be made and Save

will appear in the display.

 When the container is filled to the

desired level, tapOK.

If you want to change the portion size

for coffee made with milk, the

ingredients which make up the drink will

be saved one after the other while the

drink is being made.

Parameters

40

the control panel, you can change the

portion size by pressing and holding the

button down while the drink is being

dispensed. To do this, keep the drinks

button pressed until the machine starts

dispensing. During dispensing, Save

The coffee machine can grind and brew

7,5–12,5g of coffee beans per cup. The

greater the quantity, the stronger the

coffee.

The quantity of coffee is too low if the

espresso or coffee lacks body.

Increase the quantity of coffee so that

more ground coffee is brewed.

The quantity of coffee is too high if the

espresso or coffee tastes bitter.

are making espresso or coffee.

Several types are sensitive to high

brewing temperatures, resulting in an

impaired taste. If your coffee tastes

bitter, the brewing temperature you

have selected might be too high.

Espresso is usually brewed at higher

temperatures.

You can also adjust the brewing

temperature for making tea and

When the pre-brewing function is

turned on, the ground coffee is first

brewing” function. Depending on the

type of coffee used, pre-brewing can

intensify the taste.

You can set a short or long duration for

pre-brewing or turn the “Pre-brewing”

function off completely.

Useful tip: We particularly recommend

using the “Pre-brewing” function to

make coffee.

Profiles

(Miele profile), you can create individual

profiles to cater for different tastes and

preferences.

individually for all drinks.

The name of the current profile is

The editor will open in the display.

 Enter the profile name:

The profile has been created.

individually.

Settings

48

coffee machine is next switched off.

– been connected to a Wi-Fi network.

The remote control option appears

when the coffee machine is connected

when remote control is switched on. To

start making a drink via the app,

MobileStart also needs to be activated.

The remote control function is switched

on by default.

must be initiated manually.

If you do not install an update, you can

continue to use your coffee machine in

the usual way. However, Miele

recommends installing updates.

The RemoteUpdate function is

activated by default. Available updates

will be downloaded automatically but

will only be installed if you initiate

Settings

or postpone this until later. When the

coffee machine is switched on again,

you will be reminded about the update.

Deactivate RemoteUpdate if you do not

want to install the update.

The update may take several minutes.

Please note the following information

about the RemoteUpdate function:

The “Software version” menu option is

intended for Miele Service. You do not

need this information for domestic use.

Do not activate this function for

domestic use.

enables the coffee machine to be

demonstrated in shops or showrooms.

In this mode, the machine lights up but

no drinks can be prepared and no

maintenance programs can be run.

factory default settings.

- the number of drinks dispensed

- language

- time and date

- profiles and the associated drinks

Cleaning and care

become mouldy and/or milk residues to go off and pose a risk to health.

50

Cleaning and care

The brew unit is not dishwasher-

safe.

Only clean the brew unit by hand

with warm water. Do not use any

cleaning agents.

The following components must be

cleaned by hand only:

excessively high dishwasher

Components may be ruined (e.g.,

may become warped) if washed in a

with a maximum temperature of

55°C.

The following components are

dishwasher-safe:

Cleaning and care

52

on hot components or by hot liquids.

Components can become very hot

during operation. Touching hot

components can cause burning. The

steam are being dispensed.

Always allow the coffee machine to

cool down before cleaning it.

Please be aware that water in the

drip tray can also be very hot.

ingress.

The steam from a steam cleaner

could reach electrical components

go off and can block the milk pipework.

Contact with unsuitable cleaning

agents can alter or discolour the

external surfaces. All surfaces are

susceptible to scratching. Scratches

on glass can in some circumstances

lead to breakage.

Remove any residual cleaning agent

immediately. Make sure you remove

use:

Cleaning and care

container from the machine.

 Empty the grounds container after

removing it from the drip tray.

Cleaning and care

54

container in the dishwasher or wash

them by hand using warm water and

a little dish detergent.

Cleaning and care

water container sits on.

 Fill the water container with fresh,

cold drinking water.

 Push the water container all the way

door.

Clean the central spout’s stainless

steel cover by hand only, using warm

water and a little dish detergent.

With the exception of the stainless steel

cover, all parts of the central spout

should be cleaned in the dishwasher

once a week. This will remove coffee

Cleaning and care

56

cover forwards to remove it. Then

clean it.

 Grip the dispensing unit by the sides

and pull it down to remove it.

Cleaning and care

separating it into 3components: the

Y-piece, the spouts, and the holder.

 Clean all parts thoroughly.

 Clean the area around the central

spout with a damp cloth.

The dispensing unit is easier to

reassemble if the individual parts are

Press down firmly so that the spouts

become securely connected to the

holder.

 Refit the stainless steel cover.

Fit cover to main dispenser appears in the

display.

 Confirm the message withOK.

The cup rim sensor is located at the

bottom of the central spout.

Clean the cup rim sensor at least once

a week and more often if heavily soiled.

Cleaning and care

64

The coffee machine has the following

maintenance programs:

You can also start the Rinse appliance

function manually.

If you have made a drink with milk, the

coffee machine will rinse the milk

The milk pipework must be cleaned

roughly once a week.

The Clean milk pipework maintenance

program lasts for approx.15minutes.

 Touch the sensor button.

 Select Clean milk pipework and tapOK.

The process will start and various

For optimum cleaning results, we

recommend using the Miele Cleaning

Agent for milk pipework.

The cleaning agent for milk pipework

has been specially developed for use

with Miele Coffee Machines and

prevents subsequent damage.

You can order the cleaning agent for

milk pipework from the Miele online

Cleaning and care

mark with lukewarm water and stir

the solution.

with the specified amount of water.

Otherwise, cleaning will be

incomplete.

 Follow the instructions in the display.

 If prompted to do so in the display,

rinse the water container thoroughly

with clean water. Make sure that no

cleaning agent is left in the water

container. Fill the water container with

drinking water.

become blocked quite quickly. It must

ensure aromatic coffee and trouble-free

operation of the coffee machine.

for degreasing the brew unit in Miele

Coffee Machines and prevent

subsequent damage.

The cleaning tablets are available to

order from the Miele online shop, from

Miele Service, or from your Miele

dealer.

The maintenance program for

degreasing the brew unit lasts for

approx.10minutes.

You need 1cleaning tablet for the

maintenance program.

After 200portions have been

dispensed, a message prompting you

to degrease the brew unit will appear in

the display.

 Confirm the message withOK.

The maintenance program will then

start.

 Follow the instructions in the display.

Remove the water container and the brew

unit. Clean the interior of the machine. Rinse

the brew unit by hand and refit it with a

cleaning tablet in it. appears in the

display.

Cleaning and care

66

The moving parts of the brew unit

are lubricated. Cleaning agents will

damage the brew unit.

Only clean the brew unit by hand

with warm water. Do not use any

 Open the appliance door.

 Remove the water container.

 Press the button under the handle of

the brew unit and, while doing so,

turn the handle forward.

and then pull out to the front. Tilt

the brew unit forward while doing

so.

If you cannot remove the brew unit or

can only do so with difficulty, the brew

unit is not in the correct position (see

“Frequently Asked Questions”).

warm running water without using

cleaning agent or dish detergent.

Cleaning and care

 Wipe any coffee grounds from the

filters. One filter is located in the

funnel and the other to the left of the

funnel.

The process of removing the brew unit

causes ground coffee to drop onto the

drip tray.

 Remove the drip tray and clean the

ground coffee residues.

 Drop a cleaning tablet into the top of

the brew unit (arrow).

 Push the brew unit containing the

cleaning tablet back into the coffee

machine.

 Press the button under the handle of

the brew unit and, while doing so,

turn the handle backward.

Cleaning and care

68

the drinks menu appears.

Risk of damage from splashes from

the descaling solution.

Sensitive surfaces and/or natural

floors can suffer damage.

Wipe up any spillages immediately

when descaling.

Limescale builds up in the coffee

machine through use. How often the

appliance needs to be descaled will

depend on the water hardness level in

drip tray or fill the water container.

Descaling must be carried out. The

process takes approx.35minutes.

The coffee machine will give you plenty

of warning when it needs to be

descaled. The remaining number of

drinks that can be made before

descaling will show in the display after

each drink.

 Confirm the message withOK.

Cleaning and care

container.

 Fill the water container to the mark

with lukewarm water.

Frequently Asked Questions

machine, some of which may result from incorrect operation, can be remedied

without contacting the Service Department. This will save you time and money

because you won't need a service call.

70

Frequently Asked Questions

Frequently Asked Questions

maintenance programs.

 Fill the water container up to the relevant mark and

restart the process.

F233 The cup rim sensor is not inserted or is incorrectly

inserted.

If the central spout is moving upwards and the cup

rim sensor is bumped, e.g., with a cup, the cup rim

sensor loses its reference position.

 Confirm the message withOK.

 Refit the cup rim sensor.

 Remove and clean the milk valve (see “Cleaning

and care – Removing and cleaning the milk valve”).

72

Frequently Asked Questions

theOn/Offbutton.

The On/Offbutton was not held for long enough.

 Touch and hold theOn/Offbutton for at least

 Contact a qualified electrician or Miele Service.

The lighting has been switched off.

 Switch the lighting on (see “Settings” – “Lighting”).

The lighting is faulty.

 Contact Miele Service.

A fault has occurred.

reached.

 If required, you can select a new switch-off time

(see “Settings – Timer”).

The plug is not inserted in the socket correctly.

 Insert the plug into the socket.

There is an internal fault.

 Disconnect the coffee machine from the electricity

This is not a fault.

Once a drink has been dispensed or the machine

has been switched off, the internal fan will continue

to run until the interior is sufficiently dehumidified.

Caring for the environment

80

materials protect the appliance during

shipping. They have been designed to

be biodegradable and recyclable.

Electronic and electrical appliances

contain many valuable materials. They

handled incorrectly. Therefore, please

do not dispose of your old appliance

with general waste.

Installation

Before connecting the coffee machine,

make sure that the connection data on

Installation

82

Installation

Installation

84

operation.

A machine that has not been built in

is not safe and can cause injuries.

Installation

FCC Declaration of Conformity

86
