INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or death.
FORYOUR SAFETY:
-- Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHATTO DO IFYOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
Refer to your serial plate for
applicable agency certification
• ALL RANGES
CAN TIP
• INJURYTO PERSONS
COULD RESULT
• INSTALL ANTI-TIP
DEVICE PACKED WITH
RANGE
• SEE INSTALLATION
INSTRUCTIONS
Note. For appfiances installed in the
state of Massachusetts see page 2.
RANGE
OVERALL /_8,,
DIMENSIONS _ 29 718" i_
46-3/4"
Maximum _
T
36+i/8'
44 5/8"
Door Open _\ 29 7/8"/_J _
Minimum to
Wall on Either Minimum
Side of Range |
Above 36" 2" _ 4-
Height.
36 o
FRONT SIDE
VIEW VIEW
1-13"_1
Maximum Depth
for Cabinets
Above Range Top. /
)
_25"_
E /
O" Clearance Below Cooking Top and at Rear of Range.
t Minimum to
3" Cabinets on
Either Side
_ of Range.
II
© ©
_ 30-1/8" _
Clearances and Dimensions
1. Location--Check location where the range will be
instal led. Check for proper electrical and gas supply,
and the stability of the floor.
2. Dimensions that are shown must be used. Given
dimensions provide minimum clearance. Contact
surface must be solid and level.
Espa_ol- Pages 9-16
PIN 316259327 EN_SP (0309)
Important Notes to the Installer
1. Read all instructions contained in these installation
instructions before installing range.
2. Remove all packing material from the oven compartments
before connecting the gas and electrical supply to the
range.
3. Observe all governing codes and ordinances.
4. Be sure to leave these instructions with the consumer.
Important Note tothe Consumer: Keep these instructions
with your Use & Care Guide for future reference.
