This manual contains important information regarding your unit. Please read this manual thoroughly
prior to equipment set-up, operation and maintenance. Failure to comply with regular maintenance
guidelines outlines in this manual may void the warranty.
Instruction Manual
Hot Food Display
HFD-85
MARCH 2018
WARNINGS
• Fire, injury or death hazard – have this unit installed by a qualied installer in accordance with all deferral state and
local codes. Failure to install this equipment properly can result in injury or death.
• Fire and burn hazard – re and burn injuries can occur if this equipment is not used properly. To reduce the risk of
injury or death:
• Do not touch any hot surfaces
• Plug only into a 3-hole grounded electrical outlet
• Do not immerse unit, cord or plug in liquid at any time
• Do not operate unattended
• Do not use this unit for anything other than intended use
• Do not use outdoors
• Always use on a rm, dry and level surface at least 12” from walls or other obstructions
• Do not use if the unit has a damaged cord or plug, in the event the appliance malfunctions, or has been damaged
in any manner
• Keep children and animals away from unit
• Any incorrect installation, alterations, adjustments and/or improper maintenance can lead to property loss and
injury. All repairs should be done by authorized professionals only.
• Ensure that the designated power supply is adequate for continual usage and the voltage is correct
* This unit is intended to be used as a merchandiser for hot food in commercial food service environments only.
It is not intended for household use.
STRUCTURE AND PARTS
Temperature Controller
Upper Shelf
Temperature Controller
Lower Shelf
Power Shift
Power Shift
INSTALLATION
• Remove all packing material and tape, as well as any protective plastic or tape
• Clean off any glue or tape residue
• Place the unit on an even and safe surface that can support its weight and is not heat sensitive
• Plug the unit into a properly grounded electrical supply that matches the data plate rating. Damage to the unit may
occur if incorrect power is supplied to the unit.
MARCH 2018
OPERATION
• Before using, clean the unit with a soft cloth and mild cleaning agent and then dry thoroughly.
• Remove the water bowl from the unit and ll with water
• Connect the unit to a properly grounded electrical supply that matches the data plate rating.
• Set the unit to the required temperature. Operating temperature range is 30˚C-90˚C (86˚F - 194˚F).
• Ensure foods are placed in appropriate containers before placement in unit.
• Always use safety gloves when placing or removing food from unit.
• Disconnect from power outlet when not in use.
CLEANING
• For sanitary reasons, the unit should be cleaned regularly.
• Clean the inside, outside and trays with a soft, damp cloth and a mild cleaning agent.
• Clean the water bowl regularly
• Do not use abrasive agents or pads as these will scratch the surface
• Use a soft, dry cloth to dry and polish the surface
MAINTENANCE
• Check the power cord regularly for damage. If the cord is damaged, do not use the device.
• Any repairs must be performed by a qualied technician
WIRING DIAGRAM
*
a
d
�odet
Pa _
RTR-850
2
I
\
5
n.
Temperature Controller
Temperature Controller
ACE Equipment One Year Limited Warranty
ACE warrants its equipment against defects in materials and workmanship, subject to the following conditions:
ACE Equipment is warranted for one year, effective from the date of purchase by the original owner. A copy of the
original receipt or other proof of purchase is required to obtain warranty coverage. This warranty applies to the original
owner only, and is not assignable.
S
hould any product fail to function in its intended manner under normal use within the limits defined in this warranty, at
ACE’s discretion, such product will be repaired, replaced with a refurbished unit, or replaced with a new unit by ACE,
after defective unit has been inspected and defect has been confirmed. ACE does not assume any liability for extended
delays in replacing any item beyond its control. This warranty does not apply to rubber and non-metallic synthetic parts
that may need to be replaced due to normal usage, wear or lack of preventative maintenance.
This warranty covers products shipped into the 48 contiguous United States. Warranty coverage on products used outside
the 48 contiguous United States, Hawaii, Alaska, Puerto Rico, and Canada, cover parts only.
The following conditions are not covered by warranty:
•
Equipment failure relating to improper installation, improper utility connection or supply and problems due to
improper ventilation.
•
Equipment that has not properly been maintained, damage from improper cleaning, and water damage to
controls.
•
Equipment that has not been used in an appropriate manner, or has been subject to misuse, neglect, abuse,
accident, alteration, negligence, damage during transit, delivery or installation, fire, flood, riot, or act of God.
•
Equipment that has the model number or serial number removed or altered.
•
Equipment on which the security seal has been broken.
If the equipment has been changed, altered, modified, or repaired without express written permission from ACE, then the
manufacturer shall not be liable for any damages to any person or to any property, which may result from the use of this
equipment thereafter.
This equipment is intended for commercial use only and this warranty is void if equipment is used in other than a
commercial application.
For warranty and non-warranty related issues, technical support, please contact NSA at 1-877-672-7740. To purchase
replacement parts and warranty registration visit www.admiralcraft.com.
Please have your model number, serial number
and proof of purchase ready. It is not necessary to contact the place where you originally purchased your product from.
“THE FOREGOING WARRANTY IS IN LIEU OF ANY AND ALL WARRANTIES EXPRESSED OR IMPLIED
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILTY OR FITNESS FOR PARTICULAR
PURPOSES AND CONSTITUTES THE ENTIRE LIABILITY OF ACE. IN NO EVENT DOES THE LIMITED
WARRANTY EXTEND BEYOND THE TERMS STATED HEREIN.”
WARRANTY
REGISTRATION
National Service America • 230 Park Ave, 3
rd
Floor WEST • New York, NY • 10169
CARD
MAIL CARD
IMMEDIATELY
(Name of Business) (Dealer Purchased From)
(Address) (City) (State) (Zip Code)
(Model Number) (Serial Number)
This card must be
mailed immediately
after installation date
This is to inform that I,
(Please print name of individual who owns business)
have had the above installed in my place of business
(Date of Purchase)
for warranty to be in
effect.
(Contact Phone Number) (Contact E-mail) (Signature of Individual Who Owns Business)
The above warranties are in effect from this installation date, or 90 days, whichever comes first.
