13885
EN
Version 1
June 2023
RECHARGEABLE
TRIPOD
SITE LIGHT
This document is part of the product; retain it for the life of the product, passing it on to subsequent holders.
Read this manual in full before attempting to assemble, operate, or maintain this product. Always use the
latest version of the product manual, available from drapertools.com/manuals
2. Health and Safety Information
Important: Read all Health and Safety instructions
before attempting to operate, maintain or repair this
product. Non-compliance with these instructions
may result in injury or damage to the user or the
product. Draper Tools accepts no responsibility for
improper use of this device.
• Inspect the product and electrical connections
for signs of damage or battery leakage before
every use.
− DO NOT use the product if defects are present
and withdraw it from service until it has been
repaired.
− If the external power cable is damaged, it
must be replaced by suitably qualied
personnel or returned to Draper Tools for
repair.
• DO NOT modify this product in any way.
• Remove all packaging and wrapping before use.
• Position the product appropriately.
− Use only on level surfaces.
− Ensure that the product is stable and unlikely
to tip over.
− Where necessary, apply weights to the stand
or secure it.
• Ensure that all joints are securely fastened when
the product is in use or stored.
• This is a Class III appliance and should only be
used with the charging equipment supplied.
WARNING! This product may become hot
when in use.
− NEVER place objects on the lamp area or
hang objects on any part of this product.
− NEVER use the light near ammable or
combustible substances or equipment.
1. Specication
Stock No.: 13885
Part No.: RC/TSL/50W
Bulb wattage: 50W
Lumens: 5,000lm
Beam angle: 120°
Beam distance:
At 10%: 25m
At 30%: 50m
At 100%: 90m
Colour temperature: 4,000~7,000K
Charging time: 3.5h
Run time:
At 10%: 5h
At 30%: 2.5h
At 100%: 1h
Battery: 2 x 21700 7.4V, 4,000mA
Charger:
Rated voltage: 100–240V AC
Rated frequency: 50/60Hz
Rated output: 8.4V DC / 3A
Charging current: 1.5A
Ingress protection: IPX4
Dimensions:
Folded: W 12 x H 89 x D 12cm
Max.: W 67 x H 230 x 67cm
Weight: 4.5kg
