FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not
expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.
2. IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables. Cable/s
supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC
authorization to use this product in the USA.
3. NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B”
digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a
residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio
frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to
the operation of other electronic devices. Compliance with FCC regulations does not guarantee that interference will not occur in all
installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”,
please try to eliminate the problem by using one of the following measures:
- Relocate either this product or the device that is being affected by the interference.
- Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.
- In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the
lead-in to co-axial type cable.
If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of
product. If you cannot locate the appropriate retailer, please contact Yamaha Corporation of America, 6600 Orangethorpe Ave., Buena
Park, CA90620, USA.
The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.
COMPLIANCE INFORMATION STATEMENT
(Supplierʼs declaration of conformity procedure)
Responsible Party: Yamaha Corporation of America
Address: 6600 Orangethorpe Ave. Buena Park Calif. 90620
Telephone: 714-522-9011
Type of Equipment: POWERED SPEAKER SYSTEM
Model Name: DXL1K
This device complies with Part 15 of the FCC Rules.
Operation is subject to two following conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received including interference
that may cause undesired operation.
(529-M02 FCC sdoc YCA 01)
(529-M04 FCC class B YCA 01)
4 DXL1K Owner’s Manual
PRECAUTIONS
PLEASE READ CAREFULLY
BEFORE PROCEEDING
Please keep this manual in a safe place for
future reference.
WARNING
Always follow the basic precautions listed below to avoid
the possibility of serious injury or even death from
electrical shock, short-circuiting, damages, fire or other
hazards. These precautions include, but are not limited
to, the following:
If you notice any abnormality
• If any of the following problems occur, immediately turn off the
power switch and disconnect the electric plug from the outlet.
- The power cord or plug becomes frayed or damaged.
- Unusual smells or smoke are emitted.
- Some object, or water has been dropped into the product.
- There is a sudden loss of sound during use of the product.
- Cracks or other visible damage appear on the product.
Then have the product inspected or repaired by qualified
Yamaha service personnel.
Power supply
• Do not place the power cord near heat sources such as
heaters or radiators, and do not excessively bend or otherwise
damage the cord, place heavy objects on it, or place it in a
position where anyone could walk on, trip over, or roll anything
over it.
• Only use the voltage specified as correct for the product. The
required voltage is printed on the name plate of the product.
• Use only the supplied power cord/plug.
If you intend to use the product in an area other than in the
one you purchased, the included power cord may not be
compatible. Please check with your Yamaha dealer.
• Check the electric plug periodically and remove any dirt or
dust which may have accumulated on it.
• Make sure to fully insert the electric plug to prevent electric
shocks or fire.
• When setting up the product, make sure that the AC outlet you
are using is easily accessible. If some trouble or malfunction
occurs, immediately turn off the power switch and disconnect
the plug from the outlet. Even when the power switch is turned
off, as long as the power cord is not unplugged from the wall
AC outlet, the product will not be disconnected from the
power source.
• Remove the electric plug from the outlet when the product is
not to be used for extended periods of time.
• Do not touch the product or the electric plug during an
electrical storm.
• Be sure to connect to an appropriate outlet with a protective
grounding connection. Improper grounding can result in
electrical shock, fire, or damage.
Do not open
• This product contains no user-serviceable parts. Do not
attempt to disassemble the internal parts or modify them in
any way.
Water warning
• Do not expose the product to rain, use it near water or in
damp or wet conditions, or place on it any containers (such as
vases, bottles or glasses) containing liquids which might spill
into any openings.
• Never insert or remove an electric plug with wet hands.
Fire warning
• Do not place any burning items or open flames near the
product, since they may cause a fire.
Hearing loss
• Before turning the power of all devices on or off, make sure
that all volume levels are set to the minimum. Failing to do so
may result in hearing loss, electric shock, or device damage.
• When turning on the AC power in your audio system, always
turn on the product LAST, to avoid hearing loss and speaker
damage. When turning the power off, the product should be
turned off FIRST for the same reason.
CAUTION
Always follow the basic precautions listed below to avoid
the possibility of physical injury to you or others. These
precautions include, but are not limited to, the following:
Power supply
• When removing the electric plug from the product or an outlet,
always hold the plug itself and not the cord. Pulling by the
cord can damage it.
Location and connection
• Do not place the product in an unstable position or a location
with excessive vibration, where it might accidentally fall over
and cause injury.
• Keep this product out of reach of children. This product is not
suitable for use in locations where children are likely to be
present.
• Do not block the vents. This product has ventilation holes at
the rear to prevent the internal temperature from becoming too
high. In particular, do not place the product on its side or
upside down. Inadequate ventilation can result in overheating,
possibly causing damage to the product(s), or even fire.
• To ensure proper heat dissipation of the product, when
installing it:
- Do not cover it with any cloth.
- Make sure the top surface faces up; do not install on its
sides or upside down.
- Do not use the product in a confined, poorly-ventilated
location.
Inadequate ventilation can result in overheating, possibly
causing damage to the product(s), or even fire. Make sure that
there is adequate space around the product: at least 30 cm
above, 30 cm at the sides and 30 cm behind.
PA_en_12 1/2
English
DXL1K Owner’s Manual 5
• Do not carry or transport the device unless it is disassembled.
Otherwise, you might be injured if the speaker or spacers
strike your head or body.
• Do not place the product in a location where it may come into
contact with corrosive gases or salt air. Doing so may result in
malfunction.
• Before moving the product, remove all connected cables.
• When transporting or moving the product, always use two or
more people. Attempting to lift the product by yourself may
result in injuries, such as back injuries, or cause the product to
be dropped and broken, which could lead to other injuries.
• Do not press the rear panel of the product against the wall.
Doing so may cause the plug and speaker cable to come in
contact with the wall and detach from the power cord,
resulting in short circuiting, malfunction, or even fire.
Maintenance
• Remove the power plug from the AC outlet when cleaning the
product.
Handling caution
• Do not insert your fingers or hands in any gaps or openings on
the product (vents).
• Do not rest your weight on the product or place heavy objects
on it.
• Do not operate the product if the sound is distorting.
Prolonged use in this condition could cause overheating and
result in fire.
• Do not use the included line array speaker with other
products, such as STAGEPAS 1K. Otherwise, malfunction,
overheating or fire might be caused.
• Confirm that the finished installation is safe and secure. Also,
carry out safety inspections periodically. Failure to observe
this may cause devices to fall and result in injury.
• Assemble and install in the manner instructed in the manual.
Falling or toppling may result in injury or damage.
NOTICE
To avoid the possibility of malfunction/ damage to the
product, damage to data, or damage to other property,
follow the notices below.
Handling and maintenance
• Do not use the product in the vicinity of a TV, radio, or other
electric products. Otherwise, the product, TV, or radio may
generate noise.
• Do not expose the product to excessive dust or vibration, or
extreme cold or heat, in order to prevent the possibility of
panel disfiguration, unstable operation, or damage to the
internal components.
• Do not install in locations where temperature changes are
severe. Otherwise, condensation may form on the inside or
the surface of the product, causing it to break.
• If there is reason to believe that condensation might have
occurred, leave the product for several hours without turning
on the power until the condensation has completely dried out,
in order to prevent possible damage.
• Do not place vinyl, plastic or rubber objects on the product,
since this might cause alteration or discoloration of the panel.
• Do not use sodium hypochlorite solution, ethanol, benzine,
thinner, detergent or a chemical rag to clean the surface of the
product. Otherwise, the surface may become discolored or
deteriorate.
Information
About functions/data bundled with the product
• XLR-type connectors are wired as follows (IEC60268 standard):
pin 1: ground, pin 2: hot (+), and pin 3: cold (−).
About this manual
• The illustrations as shown in this manual are for instructional
purposes only.
• The company names and product names in this manual are
the trademarks or registered trademarks of their respective
companies.
About disposal
•
This product contains recyclable components.
When disposing of this product, please contact the
appropriate local authorities.
* This applies only to products distributed
by YAMAHA CORPORATION OF AMERICA.
IMPORTANT
Please record the serial number of this unit in the space below.
Model
Serial No.
The serial number is located on the bottom or rear of the unit.
Retain this Owner’s Manual in a safe place for future reference.
(Ser.No)
Yamaha cannot be held responsible for damage caused by
improper use or modifications to the product, or data that is
lost or destroyed.
PA_en_12 2/2
6 DXL1K Owner’s Manual
Table of Contents
PRECAUTIONS .......................................................................4
NOTICE ...................................................................................5
Information.............................................................................5
Introduction............................................................................7
Features......................................................................................................7
Package contents .......................................................................................7
Optional items .............................................................................................7
Controls and Functions..........................................................8
Top panel ....................................................................................................8
Rear panel ..................................................................................................9
Quick Start Guide.................................................................11
Attaching the line array speaker and spacers...........................................11
Connecting microphones, musical instruments, or audio devices ............11
Getting sound out of the speaker..............................................................11
Storing the Unit....................................................................13
Troubleshooting ...................................................................14
General Specifications ........................................................15
Input Characteristics .................................................................................16
Output Characteristics ..............................................................................16
Dimensions ............................................................................................... 17
Block Diagram......................................................................18
English
Introduction
DXL1K Owner’s Manual 7
Introduction
Thank you for purchasing the Yamaha DXL1K powered
speaker! This product is designed for musical events or
other live performances. To get the most out of this
product and enjoy its sophisticated range of features, we
recommend that you read this manual thoroughly and
keep it in a safe place for future reference.
Features
• Column-type, 2-way, bi-amplified powered speaker.
• Easy setup involves connecting the line array speaker
to the subwoofer.
• Line array speaker can consistently cover a broad
area.
• 12-inch subwoofer produces a powerful low range.
• Equipped with a high-efficiency, 1,100 W Class-D
amplifier.
• Efficient, dedicated cover that accommodates the line
array speaker, spacers, and subwoofer.
• Suitable for a compact PA system that includes a
small-size mixing console, such as DM3, TF series,
or MG series.
• Combining this product with a STAGEPAS 1K mkII or
another DXL1K will upgrade to a stereo or multi-
speaker system.
Package contents
Optional items
• DL-SP1K (dedicated dolly)
• Subwoofer x 1 • Dedicated cover x 1
• Line array speaker x 1 • Spacer x 2
• Power cord x 1
• Owner’s Manual (this book)
Controls and Functions
8 DXL1K Owner’s Manual
Controls and Functions
Top panel
1 [PROTECT] LED
Lights red when the protection circuit is activated.
The protection circuit will be activated in one of the
following cases, and the speaker output will be
muted.
• The power to the unit is turned on
When the power is turned on, the protection circuit
will be activated for a few seconds to avoid noise.
After the unit is fully turned on, the LED will turn off.
• Amplifier overheat is detected
• A current surge is detected
If the protection circuit is activated, wait until the
temperature of the amplifier section decreases.
Alternatively, turn the power to the unit off and then
back on. Then the protection circuit will be
deactivated. If the protection circuit is not
deactivated, please contact your Yamaha dealer.
2 [POWER] LED
Lights green when the [I/O] (Power) switch (C) is
turned on.
3 [CLIP] LEDs
Light red if signals are clipping due to excessive
input levels. If these LEDs light up, lower the level of
the corresponding input channels, or set the
corresponding [MIC/LINE] switches to LINE.
4 [LEVEL] controls
Use these controls to adjust the volume for each
channel. To reduce noise, set the LEVEL control on
unused channels to minimum.
5 [MIC/LINE] switch (channel 1)
For low-level signals (including microphones), set
the switch to the MIC (N) position. For high-level
signals (including electronic instruments and audio
equipment), set the switch to the LINE (O) position.
6 [MODE] control
Use this control to adjust the overall sound pressure
and frequency balance. The center position (MUSIC)
is a basic setting. If you turn the control
counterclockwise (toward SPEECH), it will cut
unneeded low-range frequencies, and create an
optimum setting for speech, or singing and playing
an acoustic musical instrument. If you turn the
control clockwise (toward CLUB), it will boost the
high and low ranges, and create an optimum setting
for playback of sound sources.
7 [MAIN LEVEL] control/
[LIMIT] LED/[SIGNAL] LED
Determines the volume of the signal output from the
speaker and the level of signal routed to the [LINK
OUT] jack simultaneously. This allows you to adjust
the overall volume without changing the relative
volume balance between the channels. The
[SIGNAL] LED lights green when the output signal
reaches and exceeds a certain level. The [LIMIT]
LED lights red when the limiter is applied.
1
2
3
4
5
6
7
Handle
Line array speaker
socket
Control panel
Control panel
English
Controls and Functions
DXL1K Owner’s Manual 9
Rear panel
8 Mic/Line input jacks (channels 1-2)
Connect microphones, guitars, electronic musical
instruments or audio equipment. These are combo
jacks that support both XLR and phone plugs.
9 [LINK INPUT] jack
This jack supports an XLR-type plug.
An input signal is output directly from the speaker.
To control the tone and volume level of the signal,
use a connected STAGEPAS 1K mkII or mixing
console.
0 [LINK OUT] jack
This jack supports an XLR-type plug. Mixed signals
are output to the other DXL1K. Alternatively, you can
connect a different powered speaker here.
A Vents
These are the vents for the cooling fan inside this
product. Do not block the vents when the unit is in
use.
9
0
A
A
B C
8
XLR Phone
Controls and Functions
10 DXL1K Owner’s Manual
B [AC IN] jack
Connect the included power cord here. Connect the
power cord to this jack, and then insert the power
plug into an AC outlet.
Be sure to turn off the power switch before
connecting or disconnecting the power cord.
C I / O (Power) switch
Turns the power to the unit on (I) or off (O). When you
turn on the power to all connected devices, be sure
to first turn on the power to the external sound
source, then to this unit, and finally to the device that
is connected to the [LINK OUT] jack. When you turn
off the power to all devices, follow this order in
reverse.
Notice
Even when the power switch is turned off, a minimal
amount of electric current is still flowing to the unit. If you
plan not to use the unit for an extended period of time, be
sure to unplug the power cord from the AC outlet.
NOTE
Rapidly powering the unit on and off in succession may
cause it to malfunction. After turning the power off, wait for
about five seconds before turning it on again.
English
Quick Start Guide
DXL1K Owner’s Manual 11
Quick Start Guide
Attaching the line array speaker
and spacers
Use the included spacers to install the line array speaker
at approximately the same height as the ears of the
audience. The line array speaker features a grille.
1. Insert the line array speaker and
spacers firmly into the sockets
one by one.
Use the spacers as needed.
NOTE
Insert the line array speaker and spacers
firmly into the sockets. If the connectors are
not in contact sufficiently, no sound may be
output.
Connecting microphones, musical
instruments, or audio devices
Before making connections, lower the volume level to the
minimum by rotating the [LEVEL] controls counter-
clockwise.
Connection example
Getting sound out of the speaker
Make sure that the power to the unit is turned off.
2. Connect the plug on the included power
cord to the [AC IN] jack on the rear panel of
the unit.
Spacer x 2 Spacer x 1 No spacers
Acoustic-electric
guitar
Microphone
Quick Start Guide
12 DXL1K Owner’s Manual
3. Insert the other end of the power cord into
an AC outlet.
WARNING
• The DXL1K has been designed for grounded use. To
avoid electrical shock and damage to connected devices,
be sure to ground the unit using the included power cord.
If you have any questions regarding proper connections,
please contact your nearest Yamaha dealer.
• Use only the included power cord. Otherwise, heat may
be generated or an electrical shock may be caused.
Notice
Even when the power switch is turned off, a minimal
amount of electric current is still flowing to the unit. If you
plan not to use the unit for an extended period of time, be
sure to unplug the power cord from the AC outlet.
4. Turn the [LEVEL] controls (white knobs) and
[MAIN LEVEL] control (red knob) to the
minimum (zero).
5. Set the [MODE] control (yellow knob) to the
MUSIC position.
6. If a microphone is connected to channel 1,
set the [MIC/LINE] switch to the MIC (N)
position. If a musical instrument or audio
device is connected to channel 1, set the
[MIC/LINE] switch to the LINE (O) position.
7. Turn on the power to the connected musical
instrument or audio device first, then turn on
the power to this unit.
The [POWER] LED lights up.
8. Use the [MAIN LEVEL] control to adjust the
volume to an appropriate level.
9. While playing your musical instrument or
singing into the microphone, use the
[LEVEL] controls to adjust the volume of the
corresponding channels.
10. Use the [MAIN LEVEL] control to adjust the
overall volume.
If you can hear sound and the volume seems appropriate,
setup is complete. If not, please refer to the checklist in
the “Troubleshooting” (page 14) section.
NOTE
To avoid any loud, unexpected noises from the speaker, first turn
off the power to this unit, and then turn off the connected sound
source (such as a musical instrument or audio device).
When the volume is too loud
Turn the [LEVEL] control for the corresponding channel to
the minimum (zero). Set the [MIC/LINE] switch to the LINE
(O) position, then slowly raise the [LEVEL] control until
the desired volume is reached.
When the volume is too low
Turn the [LEVEL] control for the corresponding channel to
the minimum (zero). Set the [MIC/LINE] switch to the MIC
(N) position, then slowly raise the [LEVEL] control until
the desired volume is reached.
Adjusting the volume
English
Storing the Unit
DXL1K Owner’s Manual 13
Storing the Unit
1. Install the included, dedicated cover over the
DXL1K.
2. Put away the line array speaker and spacers
into the pocket that is marked with the
Yamaha logo.
To move the unit, open the flap on top of the
cover and hold the handle on the unit.
NOTE
For information regarding the DL-SP1K, an optional dolly
designed for use with the unit, please refer to the DL-SP1K
Owner’s Manual.
Troubleshooting
14 DXL1K Owner’s Manual
Troubleshooting
Power does not turn on.
Did you firmly and securely connect the power cord?
Power shuts down suddenly.
Are the vents of the unit blocked?
Since inadequate ventilation can result in overheating
this product, the power may be turned off automatically
to protect the system from overheating. Arrange the
ventilation for better cooling, then turn on the power
again.
No sound is heard.
Did you insert the line array speaker and spacers firmly
into the sockets?
If the speaker is not inserted into the spacers or socket
firmly, the connectors will not make sufficient contact
and no sound will be output.
Is the [PROTECT] LED lit?
If the internal power amplifier section is overloaded, the
amplifier will be muted to protect its circuits. The unit will
automatically reset itself after a while.
Sound is distorted or noise is produced.
Are the [LEVEL] controls of any relevant channels and/
or the [MAIN LEVEL] control set too high?
Is the [MIC/LINE] switch set to MIC?
If the input level from the source is high, setting the
[MIC/LINE] switch to MIC may result in a distorted
sound. Set the switch to LINE.
Is the volume of the connected device too high?
Lower the volume of the external device.
Sound is not loud enough.
Are the [LEVEL] controls of all relevant channels and/or
the [MAIN LEVEL] control set too low?
Is the [MIC/LINE] switch set to LINE?
Turn the [LEVEL] control to the minimum (zero). Set the
switch to MIC, then slowly raise the [LEVEL] control.
Is the volume of the connected device too low?
Raise the volume of the external device.
The high-range sounds and low-range sounds
are unbalanced.
Is the speaker properly outputting high-frequency range
signals?
If not, make sure that the line array speaker is firmly
inserted into the socket.
If a problem persists, please contact your Yamaha dealer.
English
General Specifications
DXL1K Owner’s Manual 15
General Specifications
Main specifications
Control panel
Amplifier section
Speaker section
Accessories
System Type Powered subwoofer with a line array speaker
Frequency Response (–10 dB) 37 Hz - 20 kHz
Coverage Angle (Horizontal × Vertical) 170° × 30°
Crossover Frequency 240 Hz
Maximum Output Level
(Measured peak, IEC noise@1 m)
125 dB SPL
Power Requirements 110-120 V 60 Hz, 220-240 V 50/60 Hz
Power Consumption 25 W (idle), 91 W (1/8 power)
Dimensions (W × H × D) System (maximum) 334 × 2,000 × 418 mm
Weight 23.0 kg (39 lbs)
The number of Mixing Channels 2
Analog Inputs
Mono mic/line × 1, mono line × 1
LINK IN (MONO)
Effects MODE (SPEECH/MUSIC/CLUB)
Outputs LINK OUT (MONO)
Rated Output Dynamic 1,100 W (Subwoofer: 500 W, Line array speaker: 600 W)
Enclosure
Line array speaker: Enclosed
Subwoofer: Bass-reflex type
Speaker Unit
Line array speaker: 1.5" (3.8 cm) Cone × 10
Subwoofer: 12" (30 cm) Cone
Dimensions (W × H × D)
Line array speaker: 67 × 582 × 86 mm
Spacer (each): 67 × 555 × 86 mm
Subwoofer: 334 × 550 × 418 mm
Weight
Line array speaker: 1.8 kg
Spacer (each): 0.6 kg
Subwoofer: 20.0 kg
Included in the package Power cord × 1, Dedicated cover × 1, Owner’s Manual
Optional accessories DL-SP1K (dedicated dolly)
General Specifications
16 DXL1K Owner’s Manual
Input Characteristics
Output Characteristics
* The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual,
access the Yamaha website then download the manual file.
Input
Terminals
Connector Type
MIC/LINE
SW
Input
Impedance
Source
Impedance
Input Level
*1
Sensitivity
*2
Nominal
*3
Max.
before
Clipping
CH IN1 XLR Combo
XLR
MIC
3 kΩ (Balance) 150 Ω Mics/Lines
−50 dBu −36 dBu −10 dBu
LINE −24 dBu −10 dBu +16 dBu
Phone
MIC
10 kΩ (Balance) 150 Ω Mics/Lines
−44 dBu −30 dBu −4 dBu
LINE −18 dBu −4 dBu +22 dBu
CH IN2 XLR Combo
XLR – 10 kΩ (Balance) 150 Ω Lines −24 dBu −10 dBu +16 dBu
Phone – 10 kΩ (Balance) 150 Ω Lines −18 dBu −4 dBu +22 dBu
LINK INPUT XLR-3-31 – 20 kΩ (Balance) 150 Ω Lines +10 dBu – +24 dBu
*1. 0 dBu= 0.775 Vrms
*2. INPUT VOLUME= MAX
*3. INPUT VOLUME= Nominal (Center position)
Output Terminals Connector Type Output Impedance Load Impedance
Output Level
*1
Nominal
Max. before
Clipping
LINK OUT XLR-3-31 75 Ω 10 kΩ +10 dBu +24 dBu
*1. 0 dBu=0.775 Vrms
English
General Specifications
DXL1K Owner’s Manual 17
Dimensions
Subwoofer
Line array speaker Spacer
Unit: mm
550
334
418
280
2,000
1,526
1,051
582
67
86
67
555
86
Block Diagram
18 DXL1K Owner’s Manual
Block Diagram
CH1
(MIC/LINE)
CH2
(LINE)
DSP section
AD
COMBO
(Balance)
COMBO
(Balance)
LEVEL
LEVEL
MIC/LINE
INPUT
CLIP
HA
HA
LINK
(LINE)
Dif
CLIP
AD
LIMITER
Fixed
DELAY
LIMITER
AMP
AMP
MUTE
MUTE
Fixed
EQ
Fixed
EQ
SPEAKER
ARRAY
SUBWOOFER
DA
DA
Fixed
DELAY
CROSS
-OVER
LIMIT PROTECT
MAIN
LEVEL
MODE
OUTPUT
MONO
XLR(Balance)
DA
XLR
(Balance)
PROTECTION LOGIC
EQ
MULTI
BAND
COMP
AD
SIGNAL
HPF
HPF
BA
LINK
English
DXL1K Owner’s Manual 19
MEMO
DXL1K Owner’s Manual 185
(58-M02 WEEE en 01)
(58-M02 WEEE de 01)
Information for users on collection and disposal of old equipment:
This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic
products should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in
accordance with your national legislation.
By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative
effects on human health and the environment which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products, please contact your local municipality, your waste
disposal service or the point of sale where you purchased the items.
For business users in the European Union:
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union:
This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or
dealer and ask for the correct method of disposal.
Verbraucherinformation zur Sammlung und Entsorgung alter Elektrogeräte
Befindet sich dieses Symbol auf den Produkten, der Verpackung und/oder beiliegenden Unterlagen, so sollten benutzte
elektrische Geräte nicht mit dem normalen Haushaltsabfall entsorgt werden.
In Übereinstimmung mit Ihren nationalen Bestimmungen bringen Sie alte Geräte bitte zur fachgerechten Entsorgung,
Wiederaufbereitung und Wiederverwendung zu den entsprechenden Sammelstellen.
Durch die fachgerechte Entsorgung der Elektrogeräte helfen Sie, wertvolle Ressourcen zu schützen, und verhindern
mögliche negative Auswirkungen auf die menschliche Gesundheit und die Umwelt, die andernfalls durch unsachgerechte
Müllentsorgung auftreten könnten.
Für weitere Informationen zum Sammeln und Wiederaufbereiten alter Elektrogeräte kontaktieren Sie bitte Ihre örtliche
Stadt- oder Gemeindeverwaltung, Ihren Abfallentsorgungsdienst oder die Verkaufsstelle der Artikel.
Information für geschäftliche Anwender in der Europäischen Union:
Wenn Sie Elektrogeräte ausrangieren möchten, kontaktieren Sie bitte Ihren Händler oder Zulieferer für weitere
Informationen.
Entsorgungsinformation für Länder außerhalb der Europäischen Union:
Dieses Symbol gilt nur innerhalb der Europäischen Union. Wenn Sie solche Artikel ausrangieren möchten, kontaktieren
Sie bitte Ihre örtlichen Behörden oder Ihren Händler und fragen Sie nach der sachgerechten Entsorgungsmethode.
186 DXL1K Owner’s Manual
(58-M02 WEEE fr 01)
(58-M02 WEEE es 01)
Informations concernant la collecte et le traitement des déchets d’équipements électriques et électroniques
Le symbole sur les produits, l'emballage et/ou les documents joints signifie que les produits électriques ou électroniques
usagés ne doivent pas être mélangés avec les déchets domestiques habituels.
Pour un traitement, une récupération et un recyclage appropriés des déchets d’équipements électriques et électroniques,
veuillez les déposer aux points de collecte prévus à cet effet, conformément à la réglementation nationale.
En vous débarrassant correctement des déchets d’équipements électriques et électroniques, vous contribuerez à la
sauvegarde de précieuses ressources et à la prévention de potentiels effets négatifs sur la santé humaine qui pourraient
advenir lors d'un traitement inapproprié des déchets.
Pour plus d'informations à propos de la collecte et du recyclage des déchets d’équipements électriques et électroniques,
veuillez contacter votre municipalité, votre service de traitement des déchets ou le point de vente où vous avez acheté les
produits.
Pour les professionnels dans l'Union européenne :
Si vous souhaitez vous débarrasser des déchets d’équipements électriques et électroniques, veuillez contacter votre
vendeur ou fournisseur pour plus d'informations.
Informations sur la mise au rebut dans d'autres pays en dehors de l'Union européenne :
Ce symbole est seulement valable dans l'Union européenne. Si vous souhaitez vous débarrasser de déchets
d’équipements électriques et électroniques, veuillez contacter les autorités locales ou votre fournisseur et demander la
méthode de traitement appropriée.
Información para usuarios sobre la recogida y eliminación de los equipos antiguos
Este símbolo en los productos, embalajes y documentos anexos significa que los productos eléctricos y electrónicos no
deben mezclarse con los desperdicios domésticos normales.
Para el tratamiento, recuperación y reciclaje apropiados de los productos antiguos, llévelos a puntos de reciclaje
correspondientes, de acuerdo con la legislación nacional.
Al deshacerse de estos productos de forma correcta, ayudará a ahorrar recursos valiosos y a impedir los posibles efectos
desfavorables en la salud humana y en el entorno que de otro modo se producirían si se trataran los desperdicios de
modo inapropiado.
Para obtener más información acerca de la recogida y el reciclaje de los productos antiguos, póngase en contacto con
las autoridades locales, con el servicio de eliminación de basuras o con el punto de venta donde adquirió los artículos.
Para los usuarios empresariales de la Unión Europea:
Si desea desechar equipos eléctricos y electrónicos, póngase en contacto con su vendedor o proveedor para obtener
más información.
Información sobre la eliminación en otros países fuera de la Unión Europea:
Este símbolo solo es válido en la Unión Europea. Si desea desechar estos artículos, póngase en contacto con las
autoridades locales o con el vendedor y pregúnteles el método correcto.
DXL1K Owner’s Manual 187
(58-M02 WEEE pt-BR 01)
(58-M02 WEEE it 01)
Informações para os usuários relativas à coleta e à eliminação de equipamentos usados
Este símbolo, presente em produtos, embalagens e/ou incluído na documentação associada, indica que os produtos
elétricos e eletrônicos usados não devem ser descartados juntamente com os resíduos domésticos em geral.
O procedimento correto consiste no tratamento, na recuperação e na reciclagem de produtos usados, que devem ser
levados aos pontos de coleta adequados, em conformidade com a legislação nacional em vigor.
O descarte desses produtos de forma adequada permite poupar recursos valiosos e evitar potenciais efeitos prejudiciais
para a saúde pública e para o ambiente, associados ao processamento incorreto dos resíduos.
Para obter mais informações relativas à coleta e à reciclagem de produtos usados, contate as autoridades locais, o
serviço de descarte de resíduos ou o ponto de venda onde foram adquiridos os itens relevantes.
Informações para usuários empresariais na União Europeia:
Para descartar equipamentos elétricos e eletrônicos, contate o seu revendedor ou fornecedor para obter informações
adicionais.
Informações relativas ao descarte em países não pertencentes à União Europeia:
Este símbolo é válido exclusivamente na União Europeia. Caso pretenda descartar esses tipos de itens, contate as
autoridades locais ou o seu revendedor e informe-se sobre o procedimento correto de descarte.
Informazioni per gli utenti sulla raccolta e lo smaltimento di vecchia attrezzatura
Questi simboli sui prodotti, sull'imballaggio e/o sui documenti che li accompagnano, indicano che i prodotti elettrici ed
elettronici non devono essere mischiati con i rifiuti generici.
Per il trattamento, il recupero e il riciclaggio appropriato di vecchi prodotti, si prega di portarli ai punti di raccolta designati,
in accordo con la legislazione locale.
Smaltendo correttamente questi prodotti si potranno recuperare risorse preziose, oltre a prevenire potenziali effetti
negativi sulla salute e l'ambiente che potrebbero sorgere a causa del trattamento improprio dei rifiuti.
Per ulteriori informazioni sulla raccolta e il riciclaggio di vecchi prodotti, si prega di contattare l’amministrazione comunale
locale, il servizio di smaltimento dei rifiuti o il punto vendita dove sono stati acquistati gli articoli.
Per utenti imprenditori dell'Unione europea:
Se si desidera scartare attrezzatura elettrica ed elettronica, si prega di contattare il proprio rivenditore o il proprio fornitore
per ulteriori informazioni.
Informazioni sullo smaltimento negli altri Paesi al di fuori dell'Unione europea:
Questi simboli sono validi solamente nell'Unione Europea; se si desidera scartare questi articoli, si prega di contattare le
autorità locali o il rivenditore e richiedere informazioni sulla corretta modalità di smaltimento.
188 DXL1K Owner’s Manual
For detailed guarantee information about this Yamaha product, and Pan-EEA* and Switzerland warranty service, please either visit the website address below (Printable file is available
at our website) or contact the Yamaha representative office for your country. * EEA: European Economic Area
Important Notice: Guarantee Information for customers in EEA* and Switzerland
English
Für nähere Garantie-Information über dieses Produkt von Yamaha, sowie über den Pan-EWR*- und Schweizer Garantieservice, besuchen Sie bitte entweder die folgend angegebene Internetadresse
(eine druckfähige Version befindet sich auch auf unserer Webseite), oder wenden Sie sich an den für Ihr Land zuständigen Yamaha-Vertrieb. *EWR: Europäischer Wirtschaftsraum
Wichtiger Hinweis: Garantie-Information für Kunden in der EWR* und der Schweiz
Deutsch
Pour des informations plus détaillées sur la garantie de ce produit Yamaha et sur le service de garantie applicable dans l’ensemble de l’EEE ainsi qu’en Suisse, consultez notre site Web
à l’adresse ci-dessous (le fichier imprimable est disponible sur notre site Web) ou contactez directement Yamaha dans votre pays de résidence. * EEE : Espace Economique Européen
Remarque importante: informations de garantie pour les clients de l’EEE et la Suisse
Français
Voor gedetailleerde garantie-informatie over dit Yamaha-product en de garantieservice in heel de EER* en Zwitserland, gaat u naar de onderstaande website (u vind een afdrukbaar
bestand op onze website) of neemt u contact op met de vertegenwoordiging van Yamaha in uw land. * EER: Europese Economische Ruimte
Belangrijke mededeling: Garantie-informatie voor klanten in de EER* en Zwitserland
Nederlands
Para una información detallada sobre este producto Yamaha y sobre el soporte de garantía en la zona EEE* y Suiza, visite la dirección web que se incluye más abajo (la version del
archivo para imprimir esta disponible en nuestro sitio web) o póngase en contacto con el representante de Yamaha en su país. * EEE: Espacio Económico Europeo
Aviso importante: información sobre la garantía para los clientes del EEE* y Suiza
Español
Per informazioni dettagliate sulla garanzia relativa a questo prodotto Yamaha e l’assistenza in garanzia nei paesi EEA* e in Svizzera, potete consultare il sito Web all’indirizzo riportato
di seguito (è disponibile il file in formato stampabile) oppure contattare l’ufficio di rappresentanza locale della Yamaha. * EEA: Area Economica Europea
Avviso importante: informazioni sulla garanzia per i clienti residenti nell’EEA* e in Svizzera
Italiano
Para obter uma informação pormenorizada sobre este produto da Yamaha e sobre o serviço de garantia na AEE* e na Suíça, visite o site a seguir (o arquivo para impressão está
disponível no nosso site) ou entre em contato com o escritório de representação da Yamaha no seu país. * AEE: Área Econômica Européia
Aviso importante: informações sobre as garantias para clientes da AEE* e da Suíça
Português
Για λεπτομερείς πληροφορίες εγγύησης σχετικά με το παρόν προϊόν της Yamaha και την κάλυψη εγγύησης σε όλες τις χώρες του ΕΟΧ και την Ελβετία, επισκεφτείτε την παρακάτω
ιστοσελίδα (Εκτυπώσιμη μορφή είναι διαθέσιμη στην ιστοσελίδα μας) ή απευθυνθείτε στην αντιπροσωπεία της Yamaha στη χώρα σας. * ΕΟΧ: Ευρωπαϊκός Οικονομικός Χώρος
Σημαντική σημείωση: Πληροφορίες εγγύησης για τους πελάτες στον ΕΟΧ* και Ελβετία
Ελληνικά
För detaljerad information om denna Yamahaprodukt samt garantiservice i hela EES-området* och Schweiz kan du antingen besöka nedanstående webbaddress (en utskriftsvänlig fil
finns på webbplatsen) eller kontakta Yamahas officiella representant i ditt land. * EES: Europeiska Ekonomiska Samarbetsområdet
Viktigt: Garantiinformation för kunder i EES-området* och Schweiz
Svenska
Detaljert garantiinformasjon om dette Yamaha-produktet og garantiservice for hele EØS-området* og Sveits kan fås enten ved å besøke nettadressen nedenfor (utskriftsversjon finnes
på våre nettsider) eller kontakte kontakte Yamaha-kontoret i landet der du bor. *EØS: Det europeiske økonomiske samarbeidsområdet
Viktig merknad: Garantiinformasjon for kunder i EØS* og Sveits
Norsk
De kan finde detaljerede garantioplysninger om dette Yamaha-produkt og den fælles garantiserviceordning for EØO* (og Schweiz) ved at besøge det websted, der er angivet nedenfor (der
findes en fil, som kan udskrives, på vores websted), eller ved at kontakte Yamahas nationale repræsentationskontor i det land, hvor De bor. * EØO: Det Europæiske Økonomiske Område
Vigtig oplysning: Garantioplysninger til kunder i EØO* og Schweiz
Dansk
Tämän Yamaha-tuotteen sekä ETA-alueen ja Sveitsin takuuta koskevat yksityiskohtaiset tiedot saatte alla olevasta nettiosoitteesta. (Tulostettava tiedosto saatavissa sivustollamme.)
Voitte myös ottaa yhteyttä paikalliseen Yamaha-edustajaan. *ETA: Euroopan talousalue
Tärkeä ilmoitus: Takuutiedot Euroopan talousalueen (ETA)* ja Sveitsin asiakkaille
Suomi
Aby dowiedzieć się więcej na temat warunków gwarancyjnych tego produktu firmy Yamaha i serwisu gwarancyjnego w całym EOG* i Szwajcarii, należy odwiedzić wskazaną poniżej stronę internetową
(Plik gotowy do wydruku znajduje się na naszej stronie internetowej) lub skontaktować się z przedstawicielstwem firmy Yamaha w swoim kraju. * EOG — Europejski Obszar Gospodarczy
Ważne: Warunki gwarancyjne obowiązujące w EOG* i Szwajcarii
Polski
Podrobné záruční informace o tomto produktu Yamaha a záručním servisu v celém EHS* a ve Švýcarsku naleznete na níže uvedené webové adrese (soubor k tisku je dostupný na našich
webových stránkách) nebo se můžete obrátit na zastoupení firmy Yamaha ve své zemi. * EHS: Evropský hospodářský prostor
Důležité oznámení: Záruční informace pro zákazníky v EHS* a ve Švýcarsku
Česky
A jelen Yamaha termékre vonatkozó részletes garancia-információk, valamint az EGT*-re és Svájcra kiterjedő garanciális szolgáltatás tekintetében keresse fel webhelyünket az alábbi
címen (a webhelyen nyomtatható fájlt is talál), vagy pedig lépjen kapcsolatba az országában működő Yamaha képviseleti irodával. * EGT: Európai Gazdasági Térség
Fontos figyelmeztetés: Garancia-információk az EGT* területén és Svájcban élő vásárlók számára
Magyar
Täpsema teabe saamiseks selle Yamaha toote garantii ning kogu Euroopa Majanduspiirkonna ja Šveitsi garantiiteeninduse kohta, külastage palun veebisaiti alljärgneval aadressil (meie
saidil on saadaval prinditav fail) või pöörduge Teie regiooni Yamaha esinduse poole. * EMP: Euroopa Majanduspiirkond
Oluline märkus: Garantiiteave Euroopa Majanduspiirkonna (EMP)* ja Šveitsi klientidele
Eesti keel
Lai saņemtu detalizētu garantijas informāciju par šo Yamaha produktu, kā arī garantijas apkalpošanu EEZ* un Šveicē, lūdzu, apmeklējiet zemāk norādīto tīmekļa vietnes adresi (tīmekļa
vietnē ir pieejams drukājams fails) vai sazinieties ar jūsu valsti apkalpojošo Yamaha pārstāvniecību. * EEZ: Eiropas Ekonomikas zona
Svarīgs paziņojums: garantijas informācija klientiem EEZ* un Šveicē
Latviešu
Jei reikia išsamios informacijos apie šį „Yamaha“ produktą ir jo techninę priežiūrą visoje EEE* ir Šveicarijoje, apsilankykite mūsų svetainėje toliau nurodytu adresu (svetainėje yra
spausdintinas failas) arba kreipkitės į „Yamaha“ atstovybę savo šaliai. *EEE – Europos ekonominė erdvė
Dėmesio: informacija dėl garantijos pirkėjams EEE* ir Šveicarijoje
Lietuvių kalba
Podrobné informácie o záruke týkajúce sa tohto produktu od spoločnosti Yamaha a garančnom servise v EHP* a Švajčiarsku nájdete na webovej stránke uvedenej nižšie (na našej
webovej stránke je k dispozícii súbor na tlač) alebo sa obráťte na zástupcu spoločnosti Yamaha vo svojej krajine. * EHP: Európsky hospodársky priestor
Dôležité upozornenie: Informácie o záruke pre zákazníkov v EHP* a Švajčiarsku
Slovenčina
Za podrobnejše informacije o tem Yamahinem izdelku ter garancijskem servisu v celotnem EGP in Švici, obiščite spletno mesto, ki je navedeno spodaj (natisljiva datoteka je na voljo na
našem spletnem mestu), ali se obrnite na Yamahinega predstavnika v svoji državi. * EGP: Evropski gospodarski prostor
Pomembno obvestilo: Informacije o garanciji za kupce v EGP* in Švici
Slovenščina
За подробна информация за гаранцията за този продукт на Yamaha и гаранционното обслужване в паневропейската зона на ЕИП* и Швейцария или посетете посочения по-долу уеб
сайт (на нашия уеб сайт има файл за печат), или се свържете с представителния офис на Yamaha във вашата страна. * ЕИП: Европейско икономическо пространство
Важно съобщение: Информация за гаранцията за клиенти в ЕИП* и Швейцария
Български език
Pentru informaţii detaliate privind acest produs Yamaha şi serviciul de garanţie Pan-SEE* şi Elveţia, vizitaţi site-ul la adresa de mai jos (fişierul imprimabil este disponibil pe site-ul nostru)
sau contactaţi biroul reprezentanţei Yamaha din ţara dumneavoastră. * SEE: Spaţiul Economic European
Notificare importantă: Informaţii despre garanţie pentru clienţii din SEE* şi Elveţia
Limba română
Za detaljne informacije o jamstvu za ovaj Yamahin proizvod te jamstvenom servisu za cijeli EGP i Švicarsku, molimo Vas da posjetite web-stranicu navedenu u nastavku ili kontaktirate
ovlaštenog Yamahinog dobavljača u svojoj zemlji. * EGP: Europski gospodarski prostor
Važna obavijest: Informacije o jamstvu za države EGP-a i Švicarske
Hrvatski
https://europe.yamaha.com/warranty/
URL_5
Important Notice: Guarantee Information for customers in European
Economic Area (EEA) and Switzerland
DXL1K Owner’s Manual 189
MEMO
190 DXL1K Owner’s Manual
MEMO
ADDRESS LIST
Head Office/Manufacturer: Yamaha Corporation 10-1, Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650, Japan
Importer (European Union): Yamaha Music Europe GmbH Siemensstrasse 22-34, 25462 Rellingen, Germany
Importer (United Kingdom): Yamaha Music Europe GmbH (UK) Sherbourne Drive, Tilbrook, Milton Keynes, MK7 8BL, United Kingdom
CANADA
Yamaha Canada Music Ltd.
135 Milner Avenue, Toronto, Ontario,
M1S 3R1, Canada
Tel: +1-416-298-1311
U.S.A.
Yamaha Corporation of America
6600 Orangethorpe Avenue, Buena Park, CA 90620,
U.S.A.
Tel: +1-714-522-9011
MEXICO
Yamaha de México, S.A. de C.V.
Av. Insurgentes Sur 1647 Piso 9, Col. San José
Insurgentes, Delegación Benito Juárez, CDMX,
C.P. 03900, México
Tel: +52-55-5804-0600
BRAZIL
Yamaha Musical do Brasil Ltda.
Praça Professor José Lannes, 40, Cjs 21 e 22, Brooklin
Paulista Novo CEP 04571-100 – São Paulo – SP,
Brazil
Tel: +55-11-3704-1377
ARGENTINA
Yamaha Music Latin America, S.A.,
Sucursal Argentina
Olga Cossettini 1553, Piso 4 Norte,
Madero Este-C1107CEK,
Buenos Aires, Argentina
Tel: +54-11-4119-7000
PANAMA AND OTHER LATIN
AMERICAN/CARIBBEAN REGIONS
Yamaha Music Latin America, S.A.
Edif. Torre Banco General, Piso 7, Urbanización
Marbella, Calle 47 y Aquilino de la Guardia,
Ciudad de Panamá, República de Panamá
Tel: +507-269-5311
THE UNITED KINGDOM/IRELAND
Yamaha Music Europe GmbH (UK)
Sherbourne Drive, Tilbrook, Milton Keynes,
MK7 8BL, U.K.
Tel: +44-1908-366700
GERMANY
Yamaha Music Europe GmbH
Siemensstrasse 22-34, 25462 Rellingen, Germany
Tel: +49-4101-303-0
SWITZERLAND/LIECHTENSTEIN
Yamaha Music Europe GmbH, Branch
Switzerland in Thalwil
Seestrasse 18a, 8800 Thalwil, Switzerland
Tel: +41-44-3878080
AUSTRIA/BULGARIA/
CZECH REPUBLIC/HUNGARY/
ROMANIA/SLOVAKIA/SLOVENIA
Yamaha Music Europe GmbH
Branch Austria
Schleiergasse 20, 1100 Wien, Austria
Tel: +43-1-60203900
POLAND
Yamaha Music Europe GmbH
Sp.z o.o. Oddział w Polsce
ul. Wielicka 52, 02-657 Warszawa, Poland
Tel: +48-22-880-08-88
MALTA
Olimpus Music Ltd.
Valletta Road, Mosta MST9010, Malta
Tel: +356-2133-2093
NETHERLANDS/BELGIUM/
LUXEMBOURG
Yamaha Music Europe Branch Benelux
Clarissenhof 5b, 4133 AB Vianen, The Netherlands
Tel: +31-347-358040
FRANCE
Ya m a h a M u s i c E u ro p e
7 rue Ambroise Croizat, Zone d'activités de Pariest,
77183 Croissy-Beaubourg, France
Tel: +33-1-6461-4000
ITALY
Yamaha Music Europe GmbH, Branch Italy
Via Tinelli N.67/69 20855 Gerno di Lesmo (MB),
Italy
Tel: +39-039-9065-1
SPAIN/PORTUGAL
Yamaha Music Europe GmbH Ibérica, Sucursal
en España
Ctra. de la Coruña km. 17,200, 28231
Las Rozas de Madrid, Spain
Tel: +34-91-639-88-88
GREECE
Philippos Nakas S.A. The Music House
19th klm. Leof. Lavriou 190 02 Peania – Attiki,
Greece
Tel: +30-210-6686168
SWEDEN/FINLAND/ICELAND
Yamaha Music Europe GmbH Germany filial
Scandinavia
JA Wettergrensgata 1, 400 43 Göteborg, Sweden
Tel: +46-31-89-34-00
DENMARK
Yamaha Music Denmark,
Fillial of Yamaha Music Europe GmbH, Tyskland
Generatorvej 8C, ST. TH. , 2860 Søborg, Denmark
Tel: +45-44-92-49-00
NORWAY
Yamaha Music Europe GmbH Germany -
Norwegian Branch
Grini Næringspark 1, 1332 Østerås, Norway
Tel: +47-6716-7800
CYPRUS
Yamaha Music Europe GmbH
Siemensstrasse 22-34, 25462 Rellingen, Germany
Tel: +49-4101-303-0
RUSSIA
Yamaha Music (Russia) LLC.
Room 37, entrance 7, bld. 7, Kievskaya street,
Moscow, 121059, Russia
Tel: +7-495-626-5005
OTHER EUROPEAN REGIONS
Yamaha Music Europe GmbH
Siemensstrasse 22-34, 25462 Rellingen, Germany
Tel: +49-4101-3030
Ya m a h a M u s i c G u l f F Z E
JAFZA-16, Office 512, P.O.Box 17328,
Jebel Ali FZE, Dubai, UAE
Tel: +971-4-801-1500
TURKEY
Yamaha Music Europe GmbH
Merkezi Almanya Türkiye İstanbul Şubesi
Mor Sumbul Sokak Varyap Meridian Business
1.Blok No:1 113-114-115
Bati Atasehir Istanbul, Turkey
Tel: +90-216-275-7960
OTHER REGIONS
Ya m a h a M u s i c G u l f F Z E
JAFZA-16, Office 512, P.O.Box 17328,
Jebel Ali FZE, Dubai, UAE
Tel: +971-4-801-1500
THE PEOPLE’S REPUBLIC OF CHINA
Yamaha Music & Electronics (China) Co.,Ltd.
2F, Yunhedasha, 1818 Xinzha-lu, Jingan-qu,
Shanghai, China
Tel: +86-400-051-7700
INDIA
Yamaha Music India Private Limited
P-401, JMD Megapolis, Sector-48, Sohna Road,
Gurugram-122018, Haryana, India
Tel: +91-124-485-3300
INDONESIA
PT Yamaha Musik Indonesia Distributor
Yamaha Music Center Bldg. Jalan Jend. Gatot
Subroto Kav. 4, Jakarta 12930, Indonesia
Tel: +62-21-520-2577
KOREA
Yamaha Music Korea Ltd.
11F, Prudential Tower, 298, Gangnam-daero,
Gangnam-gu, Seoul, 06253, Korea
Tel: +82-2-3467-3300
MALAYSIA
Yamaha Music (Malaysia) Sdn. Bhd.
No.8, Jalan Perbandaran, Kelana Jaya, 47301
Petaling Jaya, Selangor, Malaysia
Tel: +60-3-78030900
SINGAPORE
Yamaha Music (Asia) Private Limited
Block 202 Hougang Street 21, #02-00,
Singapore 530202, Singapore
Tel: +65-6740-9200
TAIWAN
Yamaha Music & Electronics Taiwan Co.,Ltd.
2F., No.1, Yuandong Rd., Banqiao Dist.,
New Taipei City 22063, Taiwan (R.O.C.)
Tel: +886-2-7741-8888
THAILAND
Siam Music Yamaha Co., Ltd.
3, 4, 15, 16th Fl., Siam Motors Building,
891/1 Rama 1 Road, Wangmai,
Pathumwan, Bangkok 10330, Thailand
Tel: +66-2215-2622
VIETNAM
Yamaha Music Vietnam Company Limited
15th Floor, Nam A Bank Tower, 201-203 Cach
Mang Thang Tam St., Ward 4, Dist.3,
Ho Chi Minh City, Vietnam
Tel: +84-8-3818-1122
OTHER ASIAN REGIONS
http://asia.yamaha.com/
AUSTRALIA
Yamaha Music Australia Pty. Ltd.
Level 1, 80 Market Street, South Melbourne,
VIC 3205, Australia
Tel: +61-3-9693-5111
REGIONS AND TRUST TERRITORIES
IN PACIFIC OCEAN
http://asia.yamaha.com/
NORTH AMERICA
CENTRAL & SOUTH AMERICA
EUROPE
AFRICA
MIDDLE EAST
ASIA
OCEANIA
PA57
Manual Development Group
© 2022 Yamaha Corporation
Published 05/2022
2022年5月 发行
IPEI-A0
VFA9430
Yamaha Downloads
https://download.yamaha.com/
Yamaha Pro Audio global website
https://www.yamahaproaudio.com/
〒430-8650 静岡県浜松市中区中沢町10-1
雅马哈乐器音响（中国）投资有限公司
上海市静安区新闸路 1818 号云和大厦 2 楼
客户服务热线：4000517700
公司网址：https://www.yamaha.com.cn
制造商： 雅马哈株式会社
制造商地址： 日本静冈县滨松市中区中泽町 10-1
进口商： 雅马哈乐器音响（中国）投资有限公司
进口商地址： 上海市静安区新闸路 1818 号云和大厦 2 楼
原产地： 印度尼西亚
⺐想㸔蜘ꮠ嗞罇♸僘⪞
:".")".64*$&-&$530/*$45"*8"/$0-5%
IUUQTUXZBNBIBDPN
竭⪞于䄬冎噛ⶆ鸞典饟 谝 嗻
㲙僜㵬稘
