Tripp Lite SRW6UWG SmartRack 6U Low-Profile Switch-Depth Wall-Mount Mini Rack Enclosure

OWNER'S MANUAL

For SRW6UWG. Series: Series AG-00E9
Also, The document are for others Tripp Lite models: SRW**U*

PDF File Manual, 36 pages, Read Online | Download pdf file

SRW6UWG photo
Table of Contents
1. Important Safety Instructions 2
2. Overview 2
3. Feature Identification 3
4. Enclosure Installation 4
4.1 Preparation 4
4.2 Unpacking 4
4.3 Ground Connection 4
5. Enclosure Configuration 5
5.1 Door Locks 5
5.2 Cable Access & Management 5
5.3 Reversing the Enclosure 5
5.4 Mounting Rails 6
5.5 Adjusting Mounting Rail Depth 6
6. Wall Mounting the Enclosure 6
7. Equipment Installation 7
7.1 Installing or Removing Cage Nuts 7
7.2 Alternate Mounting: 8
Tapped Hole Mounting Rail
8. Storage and Service 9
9. Warranty and Product Registration 9
Español 10
Français 19
 28
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $50 value!
www.tripplite.com/warranty
Non-Swinging Wall-Mounted
SmartRack
®
Enclosures
Applies to Model Series: SRWxxU
(Agency Series Number: AG-00E9)
Owner’s Manual
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2015 Tripp Lite. All trademarks are the sole property of their respective owners.
