HURFS56 - HURFS66
ScootKid 3-Wheel Kids Scooter
Child & Toddler Toy Scooter with Built-in LED Wheel Lights,
Fold-Out Comfort Seat (Ages 1+)
www.PyleUSA.com
2
Wear protective gear when riding
Adult supervision for assembly and use
GENERAL
We can rest assured that you have acquired a high quality product and also we
offer you an excellent after-sales service. Before you convince yourself of the
unique driving experience offered by your new scooter, please read the attached
instructions carefully. They include these instructions in a safe place so that you can
refer to them in the future. Please kindly note that the product specifications
subject to change without notice, thanks for your kind attention.
Have fun with your new scooter!
Important Instructions and Warnings
IMPORTANT: Before you allow your child to use our scooter, please read the
operating safety instructions carefully firstly, and ensure that the steering rod is
fully engaged and all the screws are tight. Also ensure that the wheels have been
correctly secured and that they show no signs of wear.
IMPORTANT: Undoing the axle screws several times will reduce the effect of the
screw securing product.This means that the screws may come loose by themselves.
You should therefore always check the screws regularly and use the scooter after
tightening the screws.
WARNING:
• Adult required, this product contains small parts while unassembled.
• The toy needs to be used with caution, since skill if required to avoid falls or
collisions causing injury to the user or third parties.
• The wearing of helmets protective equipment for elbows, knees, wrists and
palms as well as shoes with flat rubber soles is recommended.
• Close quick-action lock securely and ensure that it is correctly positioned.
• Do not ride down slopes.
• Child must be supervised.
• Brake can become hot.
• Maximum permissible weight: 50 kg.
www.PyleUSA.com
3
OPERATING SAFETY INSTRUCTIONS
• Child should practice first to gain control of the scooter. We recommend that you
practice your scooter on a traffic-free car park or on open asphalt play areas.
• Ensure that your child always wears a helmet, wrist, elbow and knee pads, as well
as shoes with rubber soles. Not to be used in traffic 60 kgs max.
• Ensure that your child does not attempt any experiments or risky maneuvers with
it. Riding style should always be adjusted to the personal skill of the rider.
• Ensure that your child does not travel at speeds exceeding 5 km/h.
• Ensure that your child does not ride on roads, paths or other places with motor
vehicle traffic.
• Ensure that your child does not make any modifications or alterations to your
scooter which would put your safety at risk. If you do, the guarantee is expired.
• Ensure that your child does not ride the scooter in the dark or at night. Only one
child may ride on the scooter.
• Ensure that your child does not ride down any steep hills. The brake is not designed
to decelerate from high downhill speeds. Always look ahead while you ride so that
you can quickly stop at any time. The brake can get hot with prolonged use.
Avoid skin contact.
• The brake pad becomes hot when it is used. Make sure that your child does not
keep the brake on for a long period of time. Explain to your child that direct skin
contact may cause burns.
• The scooter must not be used on wet, oil, sandy, icy, rough or uneven surfaces.
Never use the scooter in wet conditions.
• Kerbstones and cobblestone pavements affect your balance. It Is better to get off.
Even lowered kerbstones can knock you off balance.
• Watch out for longitudinal and transverse grooves in the asphalt! The narrow
wheels may get stuck In tram ralls and manhole covers, for example and lock up.
• Some metal parts may corrode after a certain time, especially when used near the
sea of left outdoors to often.
• The scooter may not be used on public roads. When boarding on pedestrian
walking areas, keep to the correct side according to the rules of the road as much
as possible. Watch out for Pedestrians, Wheelchair users, Cyclists, Rollerblade and
Animals. Always observe traffic rules and regulations.
• Load capacity is up to 50 kg body weight for the scooter.
www.PyleUSA.com
4
• Scooter for 3+ years old
• Always take care not to risk injuring fingers when folding and unfolding scooter.
• Explain to your child the risks of using the scooter as how to use it. Supervise your
child while they are using the scooter. HAVE FUN WITH YOUR NEW SCOOTER!
PLAY INSTRUCTIONS
Hold on to the ends of the T-Bar or Ring Bar with your hand. You steer the board
through the slightest of weight displacements. To get under way, you stand with
one leg (the foot approx at 45° angle to the direction of travel) on the board and
push yourself off using the other leg. If you stand with your right leg on the board,
you can use left leg to accelerate. If you stand with your left leg on the board, you
can use right leg to accelerate. After gaining momentum you stand with your legs
apart on the board, so that both feet are approx at 45° angle to the direction of
travel. Enjoy your scooter!
WARNING:
Do not attempt or do stunts, tricks or rider/roll backwards on your scooter. It is not
made to withstand abuse from misuse, such as jumping, curb grinding or any other
type of stunts. Racing, stunt riding or other maneuvers, such as trying to ride
backwards, also enhance risk of loss of control, or may cause uncontrolled rider
actions or reactions. Aggressive riding reduces your ability to maneuver and control.
Take necessary precautions and practice in a safe area.
BRAKE
The brake is a friction brake and only designed for reduction
of speed on flat surfaces -avoid going downhill. Brake at low
speed by gently pushing your foot, resting far back on the
board, against the back wheel plate.You need to push harder
if you are traveling faster. Be careful however: if you push the
brake too hard and slow down too abruptly, you may risk of
falling. It is best to practice how to use brake at walking speed.
Attentlon: The brake and protection plate can get very hot.
www.PyleUSA.com
5
HURFS56 - HURFS66: Age : 3+year (Recommend)
Handle Grip
Non-Welding
Stronger Plastic Collar
Clamp
TPR Seat
Non-Slip Deck
Rear Brake
Rear PU
Wheel
Chassis
Front PU Wheel
Adjustable T-Bar
Handle/Steering Rod
Fixing Sleeve
Lower Mudguard
Lean to Steer
Mechanism
TPR Seat
Handle/Steering
Rod
Fixing Sleeve
Scooter Body
Allen Key
www.PyleUSA.com
6
SCOOTER ASSEMBLY
WARNING: Keep the kids in a safe distance while assembling the scooter to
avoid accidental injuries.
H
B
C
A
M T S
Push Red Button (M), Handlebar (T), Fixing Sleeve (S), as shown
in Figure A.
Scooter Hole (H), as shown in Figure B.
Press Red Push Button (M). Insert the Handlebar (T) with the flat
side backwards in Scooter Hole (H), as shown in Figure C. Until
you hear "click" sound to ensure HandIebar (T) securely locked
in Scooter Body.
Pull the Fixing Sleeve downward to strengthen stability of the
Handlebar (T) and Scooter Body, as shown in Figure D.
D
E
F
Adjustable T-Bar handlebar with 3 heights to
accompany child's development, as shown in
Figure E.
Finish the Scooter Assembly and adjust Height as shown in
Figure F.
www.PyleUSA.com
7
SCOOTER DISASSEMBLE
WARNING: Keep the kids in a safe distance while disassembling the scooter to
avoid accidental injuries.
SEAT ASSEMBLY
WARNING: Keep the kids in a safe distance while assembling the scooter to
avoid accidental injuries.
A
Scooter as shown in Figure A
Pull the fixing sleeve upward as shown in
Figure B & C.
Press Red Switch with one hand and using the other hand
to pull handlebar to separate the Handlebar and Scooters body
as shown in Figure D.
Finish disassembling the Scooter as shown in Figure E.
B
D
E
C
Scooter as shown in Figure A
A
www.PyleUSA.com
8
Fix firmly with the screw with one hand.
SEAT DISASSEMBLY FIRST METHOD
WARNING: Keep the kids in a safe distance while disassembling the scooter to
avoid accidental injuries.
B
C
D
E
F
Adjustable seat housing with 3 heights to accompany child's
development.
Fold the seat housing
Press red push button. Insert the handlebar with the flat side
backwards in scooter hole
Finish as shown in Figure F.
A
Scooter as shown in Figure A.
www.PyleUSA.com
9
SEAT DISASSEMBLY SECOND METHOD
B
Fold the seat housing up as shown in Figure B.
A
Scooter as shown in Figure A.
Press the red button, remove the handlebar from the hole on
the scooter
B
D
Press the red button, insert the sleeve and handlebar into the
scooter
E
Finish as shown in Figure E
C
Loose the screw, press red button and remove the sleeve and
seat housing.
www.PyleUSA.com
10
Adjust the T-Bar according to childs height. Tighten the Collar
Clamp to ensure T-Bar after adjustrnent, as shown in Figure B
Lowest: 680MM as shown in Figure C
Second: 730MM as shown in Figure D
Third: 810MM as shown in Figure E
Highest: 890MM as shown in Figure F
A
Loosen the lever of the Collar Clamp as shown in Figure A
B
C
D
E
F
HEIGHT ADJUSTMENT
WARNING: Tighten the Collar Clamp to secure T-Bar after adjustment.
www.PyleUSA.com
11
MAINTENANCE INSTRUCTIONS
Change Wheel
The wheels wear down with time and can be damaged if overly used on rough
surfaces. The back wheel on which the brake is applied is particularly affected after
several hours of braking. In the interests of safety, they should be checked regularly
and changed if necessary.
Change Deck
1. Loosen the 6 screws (A) as shown on the picture (arrows).
2. Remove deck and tighten the screw (A).
3. Check for tight fit after you have traveled about 5km with the new board.
Remove or Change collar clamp
1. Loosen the 2 screws (E) and (F) as shown on the picture( arrows).
2. Pull the collar clamp upwards and remove it.
3. Tighten the screws (E) and (F).
Left Wheel
Turn the Allen Key counter-clockwise to loosen the
screw
Right Wheel
Turn the Allen Key clockwise to loosen the screw
A A A
A A A
E F
www.PyleUSA.com
12
SAFETY TIPS
The scooter is a new fun piece of product which is safe when used carefully and
correctly. However, as with any sporting product, a small risk cannot be excluded
and we recommend that you protect hand joints, elbows and knees from bumps
and grazes. A helmet will also contribute to your safety. To ensure you do not slip it
is best if you wear shoes with a rough sole. You should always adjust your speed
according to your ability and the conditions and when in doubt, dismount if there
is a risk of unseen traffic.
WARRANTY ITEMS
Six months warranty covering defects in material and workmanship is provided for
the scooter starting from the date of purchase. During the warranty period, we will
inspect and decide that the problem has been caused by a defect in material or
workmanship, your scooter will either be repaired or replaced with an identical or
equivalent scooter. If you need repair or replace, please directly contact your local
seller or distributor.
The warranty shall not Include damage caused by:
1. This warranty only applies to initial purchasers.
2. Improper attempts at repair or modifications the scooter.
3. External inlluences (eg. impact against curb stones, rails, obstacles on road, etc.)
4. Improper usage, usage for purposes other than those intended, negligent
handling or normal wear and tear.
No person, seller, distributor shall be allowed to modify or to supplement the
terms and conditions of this limited warranty.
www.PyleUSA.com
13
HURFS56 - HURFS66
ScootKid 3-Wheel Kids Scooter
Child & Toddler Toy Scooter with Built-in LED Wheel Lights,
Fold-Out Comfort Seat (Ages 1+)
Features:
• Mini Kick Scooter Fun
• 3-Wheel Tricycle ‘Trike’ Style
• Sit or Stand Kick Scooter Design
• Lightweight, Compact & Portable
• Convenient Fold-Out Child Comfort Seat
• Multi-Color LED Wheel Lights Illuminate When Rolling
• Seat is Removable for Standard Scooter Riding
• Unique Foot Rest & Seat for Cruising
• Adjustable T-Bar Handlebar Height
• Anti-Slip Wide Floor Foot-Base Deck
• Multi-Wheeled Scooter Stability
• Long Lasting, Super Smooth Gliding Wheels
• Easy Maneuvering Lean-to-Steer Technology
• Lab Tested & Safety Certified
• Indoor/Outdoor Use
• Suitable for Ages 1+
• Fun for Kids: Small Children & Young Toddlers
Technical Specs:
• Handlebar Height Setting: 25.5’’, 27.5’’, 31.0’’, 34.0’’ -inches
• Wheel Size Diameter: 120mm Front, 80mm Rear
• Construction Material: Aluminum Metal, Engineered ABS
• Wheel Type / Wheel Material: Engineered Polyurethane
• Recommended Age: 1 Year and Up
• Weight Capacity: Up to 132 lbs. (Seat Capacity: 45 lbs.)
