Operation Guide 5335
E-9
5. Use B to move the World City hand to the city that matches your current
location (time zone).
x Holding down B moves the hand at high speed.
x For information about time zones, see the City List on page E-15.
Example: TOKYO
30
Align the hand with the
center of the city name.
E-8
3. Use B to move the alarm hands to the same setting as the main hands.
x The alarm time does not distinguish between a.m. and p.m.
x Holding down B moves the hands at high speed.
30
10:08
4. Hold down A for about two seconds.
x This will cause the World City hand to make one revolution.
E-7
x When setting the minute hand, move it four or fi ve minutes past the desired
setting, and then back it up.
Example: To set a time of 10:08 p.m.
30
E-6
Adjusting the Time Setting
Perform the procedure below whenever the position of any of the hands is incorrect.
Important!
x When setting the time, be sure to set the position of all of the hands. If you change
the position of only one hand, the other hands will still be incorrect.
1. Just as the second hand reaches 12 o’clock, pull out the crown to the
second click.
x This will stop the second hand.
2. Rotate the crown to set the main hour and minute hands.
x Take care that you set the correct AM or PM time. Watch the day indicator when
the hour hand passes 12 o’clock. If the day indicator changes, it means you just
passed midnight.
x Set the hands to a time that is a few minutes past* the actual current time.
* Since you will re-start timekeeping in step 8 of this procedure, you should allow
a few minutes to perform the other steps before that.
E-5
Indicators and Crown Operation
30
Second hand
Day indicator
Click 2
Main hour hand
Main minute hand
Crown
Click 1
World Time hands (24-hour)
World City hand
Alarm hands (12-hour)
World Time
x Shows the current time in the selected
World City.
Alarm
x Shows alarm time setting when alarm is
on, current time when alarm is off.
E-4
If normal hand movement does not re-start after the battery
is replaced. ................................................................................... E-22
Specifi cations ................................................................................... E-23
E-3
Contents
Before Using the Watch for the First Time .......................................... E-2
Indicators and Crown Operation ......................................................... E-5
Adjusting the Time Setting ................................................................. E-6
To change the day indicator setting ............................................................E-12
World Time ....................................................................................... E-13
Using the Alarm ................................................................................ E-17
To set an alarm time and turn on the alarm .................................................E-18
To cancel a previously set alarm .................................................................E-20
To test the alarm ........................................................................................E-20
Low Battery Alert ............................................................................. E-21
E-2
Before Using the Watch for the First Time
Crown Operations
Some water-resistant models (100meters, 200meters)
have a screw-in crown. When you need to perform a crown
operation, rotate it towards you to unscrew it. Then pull
the crown out. Avoid applying undue force when pulling.
The watch loses its water resistance while the crown is
unscrewed. After performing a crown operation, fully screw
the crown back in.
Crown
Loosen
If your watch has a rotary bezel...
You can rotate the bezel to align its
▼
mark with
the minute hand. Then you will be able to tell how
much time has elapsed since aligning the
▼
mark.
Start
Elapsed time
Current
E-1
ENGLISH
x Your watch may differ somewhat from the one shown in the illustration.
MA1403-EA
© 2014 CASIO COMPUTER CO., LTD.
