75cm Curved Glass Wall Canopy Rangehood
TR50275
GENERAL
Installation
Wall-Mounted
Size
75 cm
Material
Stainless Steel & Tempered Glass
Color
Silver
Control Design
Touch Control Panel
SPECIFICATIONS
Fan Speed
3-speed
Exhaust Air Power
750 CFM
Lighting
1.5w LED Lamp x 2
Filter
5 layers Aluminium Filer
Flue
Stainless Steel 500 + 500 mm Flue
Pipe
150mm*1.5m length PVC Pipe
AVAILABLE ACCESSORIES
Filter
Flue
POWER / RATINGS
Voltage Rating
220–240 V~ 50/ 60 Hz
Power Cord
1.5m cable with 3 pin Plug
DIMENSIONS
Product Dim. (H x W x D)
540-1020 x 750 x 500 mm
Product Weight
17 kg
Packed Dim. (H x W x D)
850 x 395 x 540 mm
Package Weight
19 kg
KEY FEATURES
6 mm Thickness Curved Tempered Glass
0.7 Mm Thickness Stainless Steel
Touch Control Panel
Aluminium Washable Filter
750CBM/H Airflow
Australian Power Plug
2 Bright Multi Bulb LED Light
Powerful 3-Speed Exhaust Motor
Air duct Diameter: 150mm
NOTE TO THE INSTALLER: Dimensions, specifications and drawings not to scale and to assist as a guide only. Trinity Appliances reserves the absolute and unrestricted right to change product materials and specifications,
at any time, without notice. Physical product measurements of actual product must be taken prior to installation and making a cutout. Proper installation is the responsibility of the installer.
Product failure due to improper installation is not covered under the Product Warranty.
1 3 0 0 6 1 5 0 0 1 | t r i n i t y a p p l i a n c e s . c o m . a u
© 2021 Trinity Appliances
75cm Curved Glass Wall Canopy Rangehood
TR50275
Product Dimensions
Height: 540-1020mm
Width: 750mm
Depth: 500mm
