Safety information
Warning
This means that there are high risks of death or serious injury.
Caution
This means that there are high risks of material damage or personal injury.
Caution
Warning
Household use only
Thank you very much for buying this SHARP product. Before using your SHARP
from it.
This refrigerator is for household only, with ambient temperature between +5°C and +43°C.
The refrigerator should not be subjected to temperatures of -10°C or below for a long period
of time.
Ŷ
Ŷ
Ŷ
Pull out the plug if the refrigerator is not used for a long
time.
If the flexible supply cord is damaged, it must be replaced
by service agent approved by SHARP in order to avoid
a hazard.
Do not store flammable sprays, such as spray paint in
the refrigerator.
Do not damage the refrigerant circuit.
Do not allow any sharp objects to have contact with
the refrigeration system. The refrigeration system
behind and inside the refrigerator contains refrigerant.
Leaking refrigerant can ignite and may damage the eyes.
Do not use mechanical devices or other means to
accelerate the defrosting process. (This refrigerator
has an automatic defrosting system.)
Do not use flammable sprays, such as spray paint near
the refrigerator.
In the case of failure of the refrigeration system, do not
touch the wall socket and use open flames.Open the
window and air out the room. Then ask a service agent
approved by SHARP for service.
This refrigerator contains flammable refrigerant (R600a:
isobutane) and insulation blowing gas (cyclopentane).
Observe the following rules to prevent ignition and
explosion.
Make sure to protect the power cord from being
damaged during installation or moving. If the power plug
or cord is loose, do not insert the power plug.
Do not place multiple portable socket-outlets or portable
power supplies at the rear of the refrigerator.
Connect the power plug into the wall socket firmly and
directly. Do not use an extension cord or adapter plug.
Connect the power plug to the socket with the required
rated voltage.
Disconnect from the main electricity supply by removing
the main plug from the socket.Do not remove by pulling
the power cord.
Do not install the refrigerator in a damp or wet location.
It may cause the damage to the insulation or electrical
leak. Dew may also appear on the outer cabinet and
it causes rust.
The refrigerator should be installed flatly and firmly on
the floor.
Do not store volatile and flammable materials such
as ether, petrol, propane gas, aerosol cans, adhesive
agents and pure alcohol etc. These materials are easy
to explode.
Do not store temperature-sensitive products such as
pharmaceutical products in the refrigerator.
There are high risks of changes in product quality.
Do not attempt to change or modify this refrigerator.
This may result in fire, electric shock or injury.
Do not place any object on the top of refrigerator.
If the object falls down from the top, it may cause injury.
This appliance can be used by children aged from 8
years or above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way or understanding the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be done by children without
supervision.
refrigerator, please read this operation manual to ensure that you gain the maximum benefit
Fire marks means this refrigerator has risk of fire accident.
Ŷ Do not hit the glass doors hard.
Otherwise, they may break and cause physical injury.
3
ENGLISH
Care and Cleaning
Ŷ
Ŷ
Trouble
Ŷ
Ŷ
Disposal
Ŷ
Ŷ
Transportation
Ŷ
When you install or move your refrigerator, use curing
mat to protect the floor from being damaged.
Ŷ
Caution
In use
Ŷ
Ŷ
Ŷ
Do not use other than potable water to make ice cubes.
Ŷ
Ŷ
Ŷ
Carry the refrigerator securely.
If you lift up the refrigerator improperly, it may cause
injury.
Unplug the refrigerator first to prevent electric shock.
Do not splash water directly on the outer cabinet or the
interior. This may lead to rusting and deterioration of
the electrical insulation.
If you smell something burnt, pull out the power plug
immediately. Then ask a service agent approved by
SHARP for service.
In case of gas leak, ventilate the area by opening window.
Do not touch the refrigerator or the powersocket.
Ensure that the refrigerator presents no danger to
children while being stored for disposal. (e.g. remove
the magnetic door seals to prevent child entrapment.)
This refrigerator should be disposed appropriately.
Take the refrigerator to a professional recycling plant
for flammable refrigerant and insulation blowing gases.
Do not touch foods or metal containers in the freezer
compartment with wet hands. This may cause frostbite.
Do not place bottled drinks and cans in the freezer
compartment.
Do not open or close the door when other people put
a hand near the door. There is a risk that the other
people may get their fingers caught in the door.
Do not put oversized object in the pockets of the door.
If the object falls down from the pockets, it may cause
injury.
Make sure to handle the glass shelves with care to
install or uninstall. If you drop the glass shelves, it may
break or cause injury.
Installation
4
Installation
Free standing typeFree standing type
1
Keep adequate ventilation space around the refrigerator.
Overall space required in use
100mm
or more
50mm
or more
50mm
or more
1030 mm
1380mm
816 mm
1012 mm
2
Use the two front the adjustable feet to place the
refrigerator flatly and firmly on the floor.
Adjustable foot
3
(2 pcs.)
Connect the appliance via a correctly installed socket.
Note
Position your refrigerator so that the plug is accessible.
Before using your refrigerator
The figure shows the
minimum required space
for installing the refrigerator.
The amount of space
around the refrigerator
affects the amount of
power consumption.
Insufficient spacing will
decrease cooling efficiency
and increase energy consumption.
This may reduce the life of the unit and void warranty.
If using the refrigerator in the smaller space
dimension than figured, it may cause temperature
rise in the unit, loud noise and failure.
The space between the rear of the refrigerator and
the wall should be 50
mm or more.
Keep your refrigerator out of direct sunlight and do not
place next to heat generating appliance.
Do not place your refrigerator directly on the ground.
Insert suitable stand such as wooden board under the
refrigerator.
Clean the inside parts with a cloth soaked in warm water.
If soapy water is used, wipe it off thoroughly with water.
5
ENGLISH
1.
Installation
Door pocket
(4 pcs)
2. Refrigerator shelf
(3 pcs)
3. Crisper shelf
5. Bottle pocket
13
.
Crisper zone
6. Freezer tray
(2pcs)
7. Freezer Drawer
(4 pcs)
8. Adjustable foot
(2 pcs)
9. LED light
Egg holder
Description
14. Control panel
Deodorizing unit
Deodorizing catalyst is installed on the routes of cold air.
There is no need to operate and clean.
(2 pcs)
Plasmacluster indicator
4.
10.
The indicator lights up when you
open the refrigerator door after
setting “Plasmacluster”.
Fresh zone
11.
Chiller zone temperature control
12
.
Humidity adjustment
Large
Small
Twist ice maker
Following parts are included with shipment in the
freezer drawer.
How to make ice cubes
3RXUWKHZDWHULQWRWKH twist ice maker
Water level
As for the details, refer to chapter
“Operation”.
As for the details, refer to chapter
“Operation”.
5
1
1
5
6
7
3
4
9
10
11
13
12
8
8
2
Door alarm
The alarm stops after close all doors.
When the refrigerator or freezer door is left open for
over 1 minute, the alarm sounds 5 times (Beep beep
beep beep beep ).
If you do not close the door, the alarm sounds every
30 seconds.
When ice cubes are made,
turn the lever clockwise to
put the ice into the ice
cube box.
15. Vertical bar
15
Frigure 1
Frigure 2
7KHYHUWLFDOEDULVLQ
correct position, the door
FDQEHFORVHG
7KHYHUWLFDOEDULVQRWLQ
correct position, the door
FDQQRWEHFORVHG\RXVKRXOG
reposit it as Figure 1.
7KHUHLVWKHKHDWHULQVLGHWKHEDU<RXPD\IHHO
WKHKHDWEXW\RXFDQVWRUHIRRGVQRUPDOO\
14
6
Free standing type
Installation
Free standing type
Operation
Note
Function
Default setting
Plasmacluster
OFF
Express freezing
Setting temperature indication
Compartment Default setting
Refrigerator
compartment
5°C
Freezer compartment -18°C
Energy saving
Vacation mode
Control panel lock
-
Control panel is locked automatically 25 seconds
after the last key operation (Mode icon
lights up on the display after the beep ).
Lock / Unlock control panel
Controlling temperature of Refrigerator compartment
Controlling temperature of Freezer compartment
Mode icon
Control panel lock
The temperature that indicated on
the control panel is not the exact
temperature inside.
The icon of running mode lights up
on the display.
Plasmacluster setting
Mode select
Controlling temperature
The refrigerator controls its temperature automatically. You can adjust the temperature as below if you need.
Refrigerator compartment
The temperature is adjustable between -14°C and -22°C
in step of 1°C
The temperature is adjustable between 2°C and 8°C
in step of 1°C
(This setting is valid except for Energy saving and
Vacation mode.)
(This setting is valid except for Energy saving and
Express freezing mode.)
How to operate
1
2
Press
(5 sec.)
button and select temperature.
Flashing
Freezer compartment
How to operate
1
2
Press
(5 sec.)
button and select temperature.
Flashing
(Selected temperature
lights up.)
(Selected temperature
lights up .)
If you want to lock the control panel,press
button for 3 seconds or more right after the mode
icons (selected temperatures) light up.
Press button for 3 seconds or more again to
unlock.
When you press one of the keys, the display
lights up.
All modes are off initially.
When there is no key operation for approximately
2 minutes, the display turns off.
(Temperature changes each time you press
the button.)
(Temperature changes each time you press
the button.)
7
ENGLISH
Energy saving
Vacation mode
Note
%LQGE
or
button, mode icon
If you press
flashes 3 times.(Indicated temperature cannot be
changed.)
Temperature setting is not accepted during this mode.
Freezer compartment :
Refrigerator compartment :
-14°C 〜
-22°C
17°C (Unadjustable)
(Adjustable)
How to operate
1
2
Tips for saving energy
Install the refrigerator in a well-ventilated area and keep
the space to ventilate.
Keep your refrigerator out of direct sunlight and do not
place it next to heat generating appliance.
Avoid opening the door as much as possible.
Hot food should be cooled before storing.
Place the food evenly on the shelves to allow the cool
air to circulate efficiently.
Flashing
Select the mode icon.
(5 sec.)
(The icon lights up.)
Follow steps 1 to 2 again to turn off this mode
(the mode icon turns off) .
How to operate
1
2
Flashing
Select the mode icon.
(5 sec.)
Follow steps 1 to 2 again to turn off this mode
(the mode icon turns off) .
For hygienic reasons, do not put foods in the
refrigerator compartment while this mode is ON.
(The icon lights up.)
2
Use this mode to switch the appliance to energy-saving
operation.
Use this mode when going on a trip or leaving the house
for a long time.
The temperature setting of this refrigerator is
adjusted according to the ambient temperature.
Suitable temperature settings show up on the display.
Cancel this mode if you feel the beverages are not
cooled enough or ice making takes longer time.
(
)
Temperature setting for refrigerator compartment is
not accepted during this mode.(Temperature is changed
to
17°C automatically . )
Temperature setting during this mode is as follows.
button, mode icon
If you press
flashes 3 times.(Indicated temperature cannot be
changed.)
(
)
8
How to operate
1
2
Flashing
(5 sec.)
Follow steps 1 to 2 again to turn off this mode
(the mode icon turns off) .
Plasmacluster
mold
fungus
Express freezing
Note
Large food cannot be frozen in a single operation.
This mode is to freeze food quickly not to lose its flavor.
Freezer compartment :
Refrigerator compartment:
2°C 〜8°C
-25°C (Unadjustable)
(Adjustable)
This mode ends automatically 50 hours later
after setting.
button, mode icon
If you press
flashes 3 times. (Indicated temperature cannot be
changed. )
Note
The indicator (blue) in
the refrigerator turns on.
How to operate
1
2
Press
Follow steps 1 to 2 again to turn off this mode
(the mode icon turns off) .
button for 3 seconds or more.
Select the mode icon.
(The icon lights up.)
(The icon lights up.)
2
Avoid opening the door as much as possible
during operation of this mode.
The operating sound may become louder than usual
while this mode is ON but it is normal.
There may be a slight odor in the refrigerator. This is the
smell of ozone generated by the ionizer. The amount
of ozone is minimum and quickly decomposes in the
refrigerator.
(
)
Temperature setting for freezer compartment is
not accepted during this mode.(Temperature is changed
to
-25°C automatically . )
Temperature setting during this mode is as follows.
The ionizer inside your refrigerator releases clusters
of ions which are collective masses of positive and
negative ions,into the refrigerator compartment.
These icon clusters inactivate airbone mold fungus.
Beep
9
ENGLISH
Fresh zone temperature control
Temperature of the fresh zone can be adjusted
according to the type of storage food.
Knob
Humidity adjustment for crisper zone
Humidity of the crisper zone can be adjusted.
Knob
Humidity
Low
High
Fresh
Crisper
Care and cleaning
Important
To prevent cracks on inside surfaces and plastic
components, follow these tips.
Cleaning
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Note
For hygienic reasons, make sure to do following
things regularly.
Switching off your refrigerator
1. Remove all food.
2. Remove the power plug from the socket.
3. Clean and dry the interior thoroughly.
4. Keep all the doors open slightly for a few days to dry.
Defrosting
When the compartment light is blown
Contact the service agent approved by SHARP
to replace the light. The light is not to be replaced other
than by qualified service personnel.
Defrosting is automatically operated by a unique energy
saving system.
Wipe out food oil adhered to plastic parts.
Some household chemicals may cause damage, so use
only diluted washing-up liquid (soapy water).
If undiluted detergent is used or soapy water is not
wiped off thoroughly, it may result in cracks of plastic
parts.
Remove the accessories (e.g. shelves) from the cabinet
and the door. Wash them by warm soapy dishwashing
water. After that, rinse them in clean water and dry.
Clean the inside with a cloth soaked in warm soapy
dLVKZDVKLQJ water.Then, use cold water to wipe off
soapy water thoroughly.
If the refrigerator needs to be switched off for an
extended period, the following steps should be
taken to reduce the growth of mold:
Wipe the exterior with a soft cloth each time it gets dirty.
Clean the magnetic door seal with a toothbrush and
warm soapy dishwashing water.
Wipe the control panel with a dry cloth.
Do not use hot water, household cleaning powders,
creams or spray-on cleaning products, or any other
cleaning products such as mineral turpentine,
methylated spirits, thinners, petrol etc. These may
damage your refrigerator and may void any warranty.
If the power supply is disconnected, please wait at least
5 minutes before re-connecting power.
The glass shelves are heavy. Hold them firmly when
you remove the shelves from the cabinet and carry.
Do not drop objects inside the refrigerator or strike the
inner wall. This may cause cracks to inner surface.
When the knob is placed at the “Crisper” position,
you can use the chiller zone as a crisper. It is suitable
for maintaining the appropriate temperature and humidity
for fruits and vegetables.
When the knob is placed at the “Fresh” position,
it is suitable for short-term storage of fish or other fresh
food. This is the best way to keep freshness.
In this case, it is recommended to set the refrigerator
temperature below 4°C and usethe food within 3 days.
It is suitable for vegetables when the knob is placed
on the right.
It is suitable for fruits when the knob is placed
on the left.
Installation
Control panel
10
IN
OUT
Fruit / Vegetables
Dairy Products & Eggs
Meats / Fish / Poultry
* Notes for fresh food:
- Fresh food (securely wrapped) should be stored in
other stored foods.
For best freezing
Advice for preventing dew or frost
inside the refrigerator
Note
Storing food
limited time to prevent spoilage and badly affecting
You can choose
the purpose of use
of this zone.
Fruits, Vegetables
Bottles etc.
Frozen foods
(Small size)
Frozen foods
(Big size)
Dairy products
Eggs etc.
Bottles etc.
Meat, Fish, Poultry
or
Vegetables , Fruits
Small foods
Juice etc.
Dairy products
Eggs etc.
Small foods
Juice etc.
Do not place food directly
in front of cold air outlet.
This may lead to the food
freezing.
Refrigeration reduces the rate of food spoilage.
Ensure that the food is of the freshest possible quality to maximize the shelf life of perishable foods.
The following is a general guide to help promote longer food storage.
Fruit and vegetables should be loosely enclosed in a
plastic material e.g. wrap, bags (do not seal) and placed
in the Fruit and vegetable crisper to minimize moisture loss.
Most dairy products have their best-before date on
the outer packaging which informs the recommended
temperature and shelf life of the foods.
Eggs should be stored in the Egg tray.
Place on a plate or a dish and cover with paper or
plastic wrap.
For larger cuts or meat, fish, or poultry, place to
the rear of theshelves.
Ensure all cooked food is wrapped securely or placed in
an airtight container
Quality of foods should be fresh.
Freeze smallquantities of food at a time in order to
freeze them quickly.
Food should be properly sealed or covered tightly.
Place foods in the freezer evenly.
Label bags or containers to keep an invenory of freezing
food.
Keep the door securely closed. If the food falls down,
it may cause a gap between the cabinet and the door.
Move it back to the shelf or the pocket.
Food with high-moisture should be stored in airtight
container or sealed tightly.
Evenly place the food on the
shelves to allow the cooling air
to circulate efficiently.
Hot foods should be cooled
before storing. Storing
hot foods inceases the
temperature in the unit and
risk of food spoilage.
Opening the door for long
periods can cause a
significant increase of the
temperature in the
compartments of the
appliance.
Do not block the outlet
and inlet of the cool air
circulating circuit with foods
or containers;otherwise
the food is not be evenly
cooled tKURXJKRXW the
refrigerator.
11
If you still require service
Refer to your nearest service agent approved by SHARP.
ENGLISH
Before calling for service, check the following points.
Problem Solution / Situation
The outside of the cabinet is
hot when touched.
It is normal. This is because of the hot pipe is in the cabinet in order to prevent dew
generation
Refrigerator makes loud
noise.
Following sounds are normal.
The compressor makes loud noise when its operation starts.
-- Sound becomes quieter after a while.
The compressor makes loud noise once a day.
-- Operating sound is made immediately after automatic defrost operation of the cooling
unit.
Sound of (gurgling sound,
zzing sound).
time).
Cracking or crunching sound, squeaking sound
-- It is caused by expansion and contraction of inner walls and internal parts during
cooling.
Frost or dew appears inside
or outside the refrigerator.
This may occur in one of the following cases. Use a wet cloth for wiping frost and a dry
cloth for wiping dew.
When the ambient humidity is high.
When the door is frequently opened and closed.
When food containing plenty of moisture are stored. (Wrapping is required.)
The food in the refrigerator
compartment are frozen.
Is the refrigerator temperature control set at 2°C for a long time?
-- Change the temperature control to 5°C or warmer.
Is the freezer temperature control set at -22°C for a long time?
-- Change the temperature control to -18°C or warmer.
If ambient temperature is low, food may freeze even if the refrigerator compartment is
set at 8°C.
Odors in the compartment. Wrapping is required for the food with strong odors.
Deodorizing unit cannot remove all odors.
Door alarm does not stop. The alarm stops after close the door.
Before you call for service
It is caused by refrigerant flowing in pipes (sound may become louder from time to
flowing
fluid
Error indicator(
appears on the display.
)
Make sure to contact service agent approved by SHARP.
The control panel does not
work.
This may occur in one of the following cases.
Operate time is not enough for the keys to work.
The panel or your finger is soiled with dripping, oil and etc.
When you touch the panel with gloved hand, adhesive bandage on your finger, nail or
objects.
Sticker or tape is affixed on the keys.
Touch position is slightly off from the keys.
Control panel is locked automatically 25 seconds after the last key operation.
Press button for 3 seconds or more to unlock.
SHARP CORPORATION
%LQGE
CK6$31$
