SERVICE & INSTRUCTION
OWNER’S MANUAL
DECK OVENS
SRPO-48G
SRPO-60G
SRPO-72G
IMPORTANT INSTRUCTIONS FOR OVEN
INSTALLATION, OPERATION AND
MAINTENANCE
MVP GROUP LLC, 12000 BISCAYNE BLVD., SUITE 108, MIAMI, FL 33181
TEL: 786-600-7554 FAX: 786-661-4100
MVP GROUP CORP, 5659 ROYALMOUNT, MONTREAL, QC CANADA H4P 2P9
TEL: 514-737-9701 FAX: 514-342-3854
WWW.MVPGROUPCORP.COM
PARTS BREAKDOWN FOR THE MODELS SRPO-48G / SRPO-60G / SRPO-72G
NO
PART #
DESCRIPTION
NO
PART #
DESCRIPTION
1
SIE-TEF005
S/S SQUARE BUSHING FOR HINGE
14
SIE-E200CH
DOOR CHAIN
2
SIE-TEF349
DOOR DRUM
14
SIE-E300CH
DOOR CHAIN
3
SIE-TEF257
DOOR ASSEMBLY FOR SPRO-48G
15
SIE-F272-L
DOOR HINGE LEFT SIDE
3
SIE-TEF259
DOOR ASSEMBLY FOR SPRO-60G
15
SIE-F272-R
DOOR HING RIGHT SIDE
3
SIE-TEF261
DOOR ASSEMBLY FOR SPRO-72G
16
SIE-P12
PAINTED LEGS 12"
4
SIE-CA200SP
DOOR SPRING
16
SIE-018
PAINTED LEGS 18"
5
SIE-RBKNOB
KNOB FOR THERMOSTAT
16
SIE-P24
PAINTED LEGS 24"
6
SIE-TE44
ORIFICE FOR BURNER (NATURAL)
16
SIE-P30
PAINTED LEGS 30"
7
SIE-TE55
ORIFICE FOR BURNER (PROPANE)
16
SIE-P36
PAINTED LEGS 36"
8
SIE-ML247
CARRY OVER TUBE ( MODEL SRPO-48G)
16
SIE-SS12
STAINLESS STEEL LEGS 12"
8
SIE-ML248
CARRY OVER TUBE ( MODEL SRPO-60G)
16
SIE-SS18
STAINLESS STEEL LEGS 18"
8
SIE-ML249
CARRY OVER TUBE ( MODEL SRPO-72G)
16
SIE-SS24
STAINLESS STEEL LEGS 24"
9
SIE-RB4200503
THERMOSTAT
16
SIE-SS30
STAINLESS STEEL LEGS 30"
10
SIE RB7000BGOR12
GAS VALVE
16
SIE-SS36
STAINLESS STEEL LEGS 36"
11
SIE-RB44348
THERMOCOUPLE
16
SIE-PC5
CASTERS 5"/SET
12
SIE-RB5CH1
PILOT
17
SIE-FD282A
FLUE DEFLECTOR
13
SIE-P47N
ORIFICE FOR CARRY OVER # 58 (NG) /SRPO-48G
18
SIE-DH291A
DRAFT HOOD
13
SIE-P48N
ORIFICE FOR CARRY OVER # 55 (NG) /SRPO-60G
19
SIE-ST1236112
HEARTH STONE 12"X36"X1.5"
13
SIE-P49N
ORIFICE FOR CARRY OVER # 53 (NG)/SRPO-72G
19
SIE-ST2436112
HEARTH STONE 24"X36"X1.5"
13
SIE-P47P
ORIFICE FOR CARRY OVER # 72 (LP) /SRPO48G
13
SIE-P48P
ORIFICE FOR CARRY OVER # 68 (LP) /SRPO-60G
13
SIE-P49P
ORIFICE FOR CARRY OVER # 65 (LP) /SRPO-72G
11
