SLE 3231TCS
EN User Manual LED TV
1. COAXIAL/DIGITAL AUDIO OUT: coaxial
audio output
2. AV IN: AV input
3. COMPONENT IN: input YPbPr
CI: input CI
4. HEADPHONE:
6. RF IN (S2)/ANTENNA IN (S2): connection
to the antenna or to the cable television
system, LNB for satellite
7. HDMI2: connection of a device with HDMI
output
8. HDMI1: connection of a device with HDMI
output
9. USB: connection of a USB mash drive for
playback of supported multi media content
5. RF IN/ANTENNA IN: connection to the
antenna or to the cable television system
3
2
1
7
4
5
6
8
9
COMMON INTERFACE(CI+)
HDMI2
HDMI1
ARC
RF IN
DVB-T2
RF IN
DVB-S2
Mini YPbPr
IN
Mini AV
IN
SLE 3231TCS
732 x 190 x 478
732 x 88 x 433
Product Information Sheet
COMMISSION DELEGATED REGULATION (EU) 2019/2013 with regard to energy labelling of
electronic displays
Parameter Parameter or value and
precision
Unit
1. Supplier's name or trademark. SENCOR
Supplier's address. -
2. DŽĚĞůŝĚĞŶƟĮĞƌ SLE 3231TCS
3. Energy Efficiency Class for Standard Dynamic Range
(SDR)
E
4. On mode power demand in SDR 27,0 W
5. Energy Efficiency Class for High Dynamic Range
(HDR)
n.a.
6. On mode power demand in HDR, if implemented n.a. W
7. Off mode, power demand, if applicable 0,0 W
8. Standby mode power demand, if applicable 0,3 W
9. Networked standby mode power demand, if applic-
able
n.a. W
10. Electronic display category Television
11. Size ratio 16 : 9
12. Screen resolution 1 366 x 768 pixels
13. Screen diagonal 80,0 cm
14. Screen diagonal 32 inches
15. Visible screen area 27,3 dm²
16. Panel technology used LED LCD
17. ƵƚŽŵĂƟĐƌŝŐŚƚŶĞƐƐŽŶƚƌŽů;ͿĂǀĂŝůĂďůĞ No
18. Voice recognition sensor available No
19. Room presence sensor available No
20. Image refresh frequency rate (default) 60 Hz
21. DŝŶŝŵƵŵŐƵĂƌĂŶƚĞĞĚĂǀĂŝůĂďŝůŝƚLJŽĨƐŽŌǁĂƌĞĂŶĚ
firmware updates (from the date of end of the
placement on the market)
8 Years
22. Minimum guaranteed availability of spare parts
(from the date of end of the placement on the mar-
ket)
7 Years
23. Minimum guaranteed product support 8 Years
DŝŶŝŵƵŵĚƵƌĂƟŽŶŽĨƚŚĞŐĞŶĞƌĂůŐƵĂƌĂŶƚĞĞŽīĞƌĞĚ
by the supplier
2 Years
24. Power supply type Internal
External power supply (non standardized and included in the product box)25.
i -
ii Input voltage - V
iii Output voltage - V
26. External standardised power supply (or suitable one if not included in the product box)
i -
ii Required output voltage - V
iii Required delivered current (minimum) - A
iv Required current frequency - Hz
EN
Warranty conditions
Warranty card is not apart of the device packaging.
This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty
is limited to the following conditions. Warranty is referred only to the customer goods using for common
domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or
at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when
the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify
the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.
In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim
application till the date of taking over the product by end-user, or the date the end-user is obligated to take it
over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed
following documents: receipt, certificate of warranty, certificate of installation.
This warranty is void especially if apply as follows:
Defects which were put on sale.
Wear-out or damage caused by common use.
The product was damaged by unprofessional or wrong installation, used in contrary to the applicable
instruction manual, used in contrary to legal enactment and common process of use or used for another
purpose which has been designed for.
The product was damaged by uncared-for or insufficient maintenance.
The product was damaged by dirt, accident of force majeure (natural disaster, fire, and flood).
Defects on functionality caused by low duality of signal, electromagnetic field interference etc.
The product was mechanically damaged (e.g. broken button, fall).
Damage caused by use of unsuitable media, fillings, expendable supplies (batteries) or by unsuitable
working conditions (e.g. high temperatures, high humidity, quakes).
Repair, modification or other failure action to the product by unauthorized person.
End-user did not prove enough his right to claim (time and place of purchase).
Data on presented documents differs from data on products.
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the
serial number or the warranty seal has been damaged).
Manufacturer:
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic
Visit www.sencor.com for detailed information about authorized service centers.
The original version of the instructions is in the Czech language, other language versions are made by the
appropriate translation.
FAST ČR, a.s., USanitasu 1621, Říčany CZ-251 01
