41366 41367 41369 41657
Nominal Length of Light Set 32' 44' 68' 92'
Color of Cord Black
Color of Puck Lights Black
Number of Lights 6 12 24 36
Nominal Wattage 5W 10W 20W 30W
Nominal Power Factor 0.83
Operating Temperature -20 °C ~ +50 °C
Operating Humidity 10% - 90% RH
Operating Voltage 120V
Frequency 60Hz
Number of Mounting Stakes 6 12 24 36
Distance from Power Plug to Controller 2'
Distance from Controller to First Puck 20'
Distance Between Pucks 2'
Nominal CRI 81
Nominal R9 7
Nominal Lumens per Puck 40
Nominal Efcacy 48 Lumens per Watt
Lifetime 50,000 hour LED life
Landscapes
www.byjasco.com
1
PRODUCT SPECIFICATIONS
Design Features
· Pairable long-range wireless remote controls multiple lights
and all features
· Weatherproof for year-round permanent outdoor installations
· Flexible 2ft. spacing
· Burial-grade cable
· Multiple mounting options for up or down lighting
· Selectable white light in warm, soft, or day
· Any 2 color combinations and preset color and effect modes
· Dimmable
· This Jasco product is warrantied for 3 years with a limited-lifetime
replacement warranty on Enbrighten LED light source only
Enbrighten Mini LED
Color-Changing Landscape Lights
continued...
Mount the controller within an appropriate distance for the polarized plug to reach the
GFCI protected receptacle. The controller can be mounted using the keyholes on the
rear of the controller or the keyhole ear tabs. Do not lay the controller directly on the
ground or where standing water may accumulate.
Do not pull cord tight, leave
slack in loop to prevent
strain on controller.
41366 41367 41369 41657
CCT 2200 K
Power Cord to Controller 2 Conductor 18 AWG - SJTW
Low Voltage Direct Burial Cord 3 Conductor 22 AWG - Direct Burial
RF Frequency 2.4 GHz
RF Distance 100' In Open Air Applications
Batteries 2 AAA batteries
Estimated Yearly Energy Cost
(Based on 4 hours per day at $0.11 per kwh)
$0.80 $1.60 $3.21 $4.82
www.byjasco.com
2
PRODUCT SPECIFICATIONS
Ground Mounting
Multiple Mounting Options
Mount lights facing up, down or
stake into the ground
Bottom View
Keyhole to t #4
pan head screws
Burial-grade cable
Keyholes
to fit #6
pan head
screws
2in. / 5cm
3.5 inch stake
2 inch light
www.byjasco.com
3
PRODUCT SPECIFICATIONS
26898
myTouchSmart
Outdoor/Indoor
Plug-in Timer
41431
myTouchSmart
In-Wall Digital
Timer
33861
myTouchSmart
Sunsmart™
In-wall Digital
Timer
14291
myTouchSmart
Outdoor/Indoor
Wi- Smart Plug
Additional Stakes
Visit enbrightenme.com
or call 1-800-654-8483
Related Products
Product Spacing
2’ 2’ 2’ 2’
2’
2’
20’
Includes 22 foot lead wire and 2 foot spacing between lights
*Amount of lights depends on the model number
Flexible spacing up to 2ft.
Hide excess cable under mulch or soil
Sets timer
to turn off
Landscape
Lights in 2
or 4 hours
10 step dimming
on solid colors,
does not work
on modes
Fades
through
colors
*Keep remote inside
when not being used
Turn lights
on and off
Select
color of
Landscape
Lights
Strobes
through colors
PRODUCT SPECIFICATIONS
Remote FeaturesFlexible Spacing
