EN
1
APPLIANCE
PRODUCT DESCRIPTION
DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A HOTPOINT ARISTON
PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.hotpoint.eu/register
You can download the Safety Instructions and the
User
Manual, by visiting our website
docs.hotpoint.eu and
following the Instructions on the back of this booklet.
CONTROL PANEL
Before using the appliance carefully read Safety Instructions guide.
1. Upper rack
2. Cutlery rack
3. Foldable aps
4. Upper rack height adjuster
5. Upper spray arm
6. Lower rack
7. Space Zone support
8. Lower spray arm
9. Filter Assembly
10. Salt reservoir
11. Detergent and Rinse Aid dispensers
12. Rating plate
13. Control panel
1
4
5
6
11
13
7
8
9
2
3
0000 000 00000
Service:
12
10
1 2 3 4 5 6 7 8 9 10
11 12 13
1. On-O/Reset button with indicator light
2. Program selection button
3. Salt rell indicator light
4. Rinse Aid rell indicator light
5. Program number and delay time indicator
6. Tablet indicator light
7. Display
8. Zone Wash 3D indicator lights
9. Zone Wash 3D button
10. Delay button
11. Short Time button with indicator light
12. Extra Dry button with indicator light
13. Start/Pause button with indicator light / Tab
