PD8-JAE
DEHUMIDIFIER
USER MANUAL
3
SAFETY INFORMATION
1. Please read the manual before using this product for
the first time. Store the unit carefully to prevent
electrical leaks or fires that could cause injury.
2. Do not expose this product to water or other liquids.
3. Do not use the product if the power cord or unit is
damaged or broken.
4. If you need to repair the product, please contact a
professional service agent. Improper repairs can be
dangerous.
5. Always disconnect the appliance from the power supply
before moving or cleaning it. If you plan to leave the
product unused for an extended period of time, also
disconnect it from the power supply.
6.
Operate the product only with the specified electricity
voltage.
7. This product is intended for household use only and
should be used for its designed purpose.
4
8. Do not place any objects on the product.
9. Clean the water tank before moving the product to
avoid water leakage.
10.
Do not incline the product, or the leaking water may
damage the product.Do not tilt the product, or water
may leak and damage the appliance.
11.This appliance can be used by children aged 8 years
and older. If a person has reduced physical, sensory, or
mental capabilities or lacks experience or knowledge,
they should receive supervision or instruction on how
to use the appliance safely and understand the hazards
involved. Children should not play with the appliance or
attempt to clean or maintain it without supervision.
12.Keep the product at least 50 cm away from walls or
other barriers.
13.
Please follow your country's wiring laws when installing
the appliance.
5
OPERATING INSTRUCTION
1. Air outlet
2. Front housing
3. Power switch
4. Water tank handle
5. Unit handle
6. Air Inlet
7. Water tank
8. Water tank stopper
9. Float
10. Water tank cover
6
ASSEMBLE
1. First, follow direction to put the cover into the water tank . see below
2. Please make sure the cover is placed flat on the water tank and the
“FRONT” arrow mark faces to the front, otherwise the appliance won't be
able to use see below picture
7
CONTROL PANEL
3. Finally follow direction to assemble the body and the water tank to
get the compact dehumidifier. see below image
OPERATING INSTRUCTION
1. POWER
Press the key to turn “on” or “off”, and the relating indicating light may follow
the instruction to illuminate or extinguish. (When the indoor humidity
reaches the setting value, the compressor will stop operating, then the
operating indicator will flash)
8
2. FAN SPEED
Press the key to choose high speed (HI) or low speed (LOW), and the
relating indicating light may follow the instruction to illuminate or extinguish.
3. TIMER
a. Press the key to set the time you need. (1 to 24 hours)
b. When setting timer in stand-by mode, the unit will be turned on
automatically; when setting timer in operating mode, the unit will be turned
off automatically.
c. If pressing the power key to turn off the unit before the timer finishes
counting down, the setting timer will be canceled.
d. While the timer is in used, the indicating light illuminates; if not, then the
indicating light extinguishes.
e. After setting the timer by 5 seconds, the display may switch back to
show the ambient humidity. (Press once again to show the set turning-off
time.)
4. HUMIDITY SETTING
Press the key to set the relative humidity you need. (From
continuous dehumidification [CO] to relative humidity 30%, 40%,
50%, 60%, 70%, 80%,comfort mode [AU], and back to continuous
dehumidification [CO]. The first time you electrify the unit, the unit is
set to be continuous dehumidification [CO].
When ambient humidity is lower than setting humidity by 3%,
compressor will stop automatically, and return working until the
ambient humidity is higher than setting humidity by 3%.
COMFORT MODE [AU]
a. When the ambient temperature is lower than 5 , compressor stops
working.
b. When the ambient temperature is between 5 and 20 , the setting
9
WARNING
humidity defaults to 60%.
c. When the ambient temperature is between 20 and 27 , the setting
humidity defaults to 55%.
d. When the ambient temperature is higher than 27 , the setting humidity
defaults to 50%.
WATER FULL
When the water tank is full, the indicating light illuminates and the unit stops
working. Please empty the water tank and press the power to restart the
unit.
DEFROST
When the unit is defrosting, the indicating light illuminates. The compressor
stops working but the motor keeps operating to defrost.
1. Do not set the humidity level higher than the room's current humidity.
2. Empty the water tank when the "tank full" light turns on. After
replacing the tank, press the power button to restart the unit.
3. If the product shuts down unexpectedly, wait at least 3 minutes
before restarting to avoid damaging the compressor.
4. The applicable operating temperature of the unit is 5-32 .
5. If the dehumidifier is unable to start (the indicating light remain extinguish),
or shuts down accidentally, please make sure whether the plug is connected
firmly to the power supply. If the plug and power supply are in normal
condition, please wait for 10 minutes before restarting the unit (it takes 10
minutes to reposition).
After taking above actions, if the unit remains inactive, please contact us.
10
6. When the dehumidifier is operating, it’s normal that the working
compressor causes heat and increase the ambient temperature.
7. When the unit is frosting, the indicating light illuminates. The
compressor stops working but the motor keeps operating to defrost.
8. The unit shows the ambient humidity when it’s operating. If the ambient
humidity is higher than RH 95%, the display shows “HI”. If the ambient
humidity is lower than RH 35%, the display shows “LO”.
9. Unplug the dehumidifier if the unit may be left unused for a long time.
USAGE OF WATER TANK
When dehumidifying, the condensing water may be drained to water
tank. And the unit will stop working with indicating light illuminates (red light)
when the water tank is full of water, please pour out the water that time.
1. Disconnect the appliance from power supply.
2. Follow direction , lift the body to remove it
from the water tank (see the left picture)
3. Carry the water tank by handle to pour out the
water.
4. Put the water tank back and assemble the
body on the water tank.
5. Connect the power source and press power to
turn on the unit.
11
FILTER REMOVAL
1. Before removing the filter, please make
sure the power is cut off.
2. Follow direction to pull out the filter.
3. Wash the filter with cool water (cooler
than 40 ) every two weeks, and put filter
back after it air-dried naturally.
MAINTENANCE INSTRUCTION
1. The unit is not allowed to be placed on soft or uneven surface, or the
unit may cause noise, vibration, water or electricity leakage when
operating.
2. Never insert any slim rod or hard stuff into the unit to damage the
machine.
3. Please disconnect the power cord to the power supply when you turn
off the unit or intend to leave the unit unused for long time.
12
SPECIFICATIONS
4. In order to improve the performance of dehumidifier, please keep at a
distance from barriers which may block the air.
5.
Please wash the filter with cool water (cooler than 40 , neither
gasoline nor alcohol) every two weeks, and put filter back after it
air-dried naturally.
Model
Specification
PD8-JAE
Power Source
120V 60Hz
Rated Power (104 ,35%RH)
150W
Total Input Rated Current (104 ,35%RH)
1.38A
Rated Capacity (65 ,60%RH)
8 Pints/Day
Rated Capacity (86 ,80%RH)
25 Pints/Day
IEF (65 ,60%RH)
1.57 Liters/kWh
Motor FLA
0.35A
Motor Compressor
RLA:1.36A LRA:7.0A
Refrigerant
R134a / 3.46oz 98g
Maximum Allowable Pressure
2.5MPa
Maximum Operating Pressure High
1.3MPa
Maximum Operating Pressure Low
0.5MPa
Dimension(mm)
290W x 240D x 414H
Applicable temperature
9
5 -32
13
(CE) N842/2006:
R134a is a kind of fluorinated greenhouse gases covered by
the Kyoto Protocol.
Its total global warming potential (GWP) is 1430.
This marking indicates that this product should not be
disposed with other household wastes throughout the EU.
To prevent possible hazards to the environment or human
health from uncontrolled waste disposal, please recycle it to
prove the sustainable reuse of material resources. Please
ask return and collection systems or contact the retailer
where the product was purchased to return your used
device, they can recycle products safely.
