FRONT VIEW
RIGHT SIDE VIEW
TOP VIEW
SPEC SHEET OUTLINE
ITEM # 33568
DESCRIPTION -
30" DOUBLE DOORS
WWW.BULLBBQ.COM
NOTES:
1)
ALL DIMENSIONS ARE IN INCH UNITS
2)
REFER TO PERSPECTIVE VIEW FOR INSTALLATION CUTOUT DIMENSIONS.
3)
REFER TO TOP OF PAGE FOR PART INFORMATION
4)
PAGES 2 - 4 FOR WARRANTY POLICY
PERSPECTIVE VIEW
WITH INSTALLATION
CUT OUT DIMENSIONS
REPLACEMENT PARTS LIST
DWG ITEM #
PART #
DESCRIPTION
QTY
1
55524
SS
DOOR HANDLE
2
2 16515
HANDLE SET SCREW
2 SETS
3 16548
DOOR MAGNET
4
19
1
16
OUTSIDE
EDGE
33
21
15
16
30
1
2
OUTSIDE EDGE
v.2021.10.19.
1
1
4
INSIDE OF FLANGE
TO CENTER LINE OF SLOT
(Typ.)
1
7
8
ID
19
9
16
"
31"
1
15
16
OD
