Operation Guide W-CLO.I
1
MA1507-EA
A sticker is affi xed to the display of this clock when you purchase it. Be sure to remove the sticker
before using the clock.
Depending on the clock model, the confi guration of your clock may differ somewhat from that shown
in the illustration.
TO START CLOCK
Insert a battery into battery compartment (
1
) with polarity as indicated.
TO SET TIME
Turn the hour/minute adjuster (
2
) in either direction.
TO ADJUST SECONDS
Remove the battery to stop the second hand at 12 o’clock position. Replace the battery at a time signal
to restart the second hand on the correct second.
The start of second hand may be delayed depending on the timing of your switch operation.
REPLACING THE BATTERY
Low battery power is indicated when timekeeping slows or stops completely. Should either of these
symptoms occur, replace the battery immediately. Do not leave a low or dead battery in the clock.
1. Remove the old battery.
2. Load a new battery, making sure that its positive (+) and negative (–) ends are facing correctly.
Loading a battery incorrectly can cause it to burst and damage the clock.
Battery precautions
Keep batteries out of the reach of small children. If a battery is accidentally swallowed, contact your
physician immediately.
Be sure to load the battery with its positive (+) and negative (–) ends facing correctly.
Never charge the battery.
Should a battery ever leak while in the clock, wipe out the fl uid with a cloth, taking care not to let any
get onto your skin.
Replace the battery at least once a year, even if the current battery is working normally.
SPECIFICATIONS
Accuracy at normal temperature : ±20 seconds a month
Battery life : Approx. 1 year
Battery : One AA size battery (Type : LR6)
Ambient temperature range : –10°C to 50°C (14°F to 122°F)
<Type 1>
<Type 2>
